| Ref | Part Number | Description |
|---|
| 1 |
710-0347 |
HEX SCREW 3/8-16 x 1.75 GR5 Price: $4.39 |
| 2 |
710-0376 |
SCREW 5/16-18 x 1.0 GR5 Price: $3.66 |
| 3 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 4 |
710-05339A |
SCREW 5/16-24 x .750 GR5 Price: $3.70 |
| 5 |
710-06303 |
SCREW 5/16-24 x 1.88 GR8 Not Available Price: |
| 6 |
710-0759 |
SCREW 5/16-18 x .625 GR5 Not Available Price: |
| 7 |
711-06112 |
BELT KEEPER ROD .25 x 1.585 Price: $3.74 |
| 8 |
712-0291 |
Hex Lock Nut, 1/4-20 This part replaces 912-0291. Price: $3.93 |
| 9 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 10 |
712-04064 |
FLANGE LOCK NUT Price: $3.64 |
| 11 |
712-04065 |
NUT Price: $3.68 |
| 12 |
717-05249 |
DOG CLUTCH Price: $46.09 |
| 13 |
727-05134 |
DAMPNER CYLINDER This part replaces 727-05021. Price: $64.90 |
| 14 |
732-05150A |
EXTENSION SPRING 2.675" Price: $3.70 |
| 15 |
736-04117 |
FLAT WASHER 1.0 OD:.331 ID Price: $2.85 |
| 16 |
736-0505 |
FLAT WASHER Price: $5.65 |
| 17 |
738-0137A |
Shoulder Screw, .340 x .285,1/4-20 This part replaces 938-0137A. Price: $9.83 |
| 18 |
738-04419A |
SHOULDER SCREW Price: $3.61 |
| 19 |
738-05034 |
SHOULDER BOLT .395 DIA x .56 LG Price: $6.57 |
| 20 |
747-06506 |
ROD HOOK Price: $5.52 |
| 21 |
748-0234 |
SHOULDER SPACER Price: $3.86 |
| 22 |
750-06352 |
SPACER Not Available Price: |
| 23 |
954-05070 |
V-BELT 4L x 27 Price: $21.39 |
| 24 |
756-0117 |
IDLER PULLEY Price: $21.01 |
| 25 |
756-05103 |
HALF PULLEY 3.4 DIA Not Available Price: |
| 26 |
756-05118 |
HALF PULLEY 2.6 DIA Not Available Price: |
| 27 |
787-03297-0637 |
PTO CABLE BRACKET Price: $5.52 |
| 28 |
787-03656 |
DRIVE ACTUATOR IDLER BRACKET Not Available Price: |
