| Ref | Part Number | Description |
|---|
| 1 |
32140-79 |
Screw Price: Call Us |
| 1 |
530057893 |
Knob-Choke Price: $3.99 |
| 2 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 2 |
530057908 |
Spring-Ign. Switch Price: $2.99 |
| 3 |
3-8608 |
DISCONTINUED Price: Call Us |
| 3 |
530057891 |
Lever-Ign. Switch Price: $4.99 |
| 4 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 4 |
530016080 |
Screw Price: $1.99 |
| 5 |
3217-6 |
NUT-HEX Price: $1.19 |
| 5 |
530071888 |
Kit-Trigger/Lockout Price: $6.99 |
| 6 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 7 |
3217-7 |
NUT-HEX Price: $0.28 |
| 8 |
5-3915 |
DISCONTINUED Price: Call Us |
| 8 |
530095646 |
Assy-Fuel Pickup This part replaces 530095649. Price: $2.99 |
| 9 |
38-7330 |
SHIELD WASHER Price: $6.11 |
| 9 |
530023877 |
Fitting-Fuel line Price: $1.99 |
| 10 |
27-5560 |
DISCONTINUED Price: Call Us |
| 10 |
530071945 |
Kit-Clutch Washer Price: $3.99 |
| 11 |
530057905 |
Assy-Clutch Drum 3/8" Price: $14.99 |
| 11 |
6-9960 |
DISCONTINUED Price: Call Us |
| 12 |
5-1675 |
DISCONTINUE Price: Call Us |
| 12 |
530071945 |
Kit-Clutch Washer Price: $3.99 |
| 13 |
5-3998 |
DISCONTINUED Price: Call Us |
| 13 |
530057907 |
Assy-Clutch Price: $6.99 |
| 14 |
5-4000 |
DISCONTINUED Price: Call Us |
| 14 |
530016419 |
Washer-Large Clutch Price: $1.99 |
| 15 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 15 |
580940901 |
FUEL CAP ASSY This part replaces 530047192. Price: $3.99 |
| 16 |
3272-13 |
PIN-COTTER This part replaces 3272-14. Price: $0.25 |
| 16 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 17 |
5-2723 |
DISCONTINUED Price: Call Us |
| 17 |
530015922 |
Nut-"U" type speed Price: $1.99 |
| 18 |
38-6930 |
DISCONTINUED Price: Call Us |
| 18 |
530071905 |
KIT This part replaces 530057937. Price: $37.99 |
| 19 |
530057911 |
Shield-Heat Price: $2.99 |
| 19 |
8-5149 |
DISCONTINUED Price: Call Us |
| 20 |
38-6890 |
DISCONTINUED Price: Call Us |
| 20 |
530015127 |
Washer-Flywheel Price: $1.99 |
| 21 |
5-4033 |
DISCONTINUED Price: Call Us |
| 21 |
530016134 |
Nut-Flywheel Price: $1.99 |
| 22 |
5-3942 |
DISCONTINUED Price: Call Us |
| 22 |
530015920 |
Screw Price: $1.99 |
| 23 |
3-8623 |
DISCONTINUED Price: Call Us |
| 23 |
530057890 |
Pulley-Starter Price: $5.99 |
| 24 |
5-1618 |
DISCONTINUED Price: Call Us |
| 24 |
545008013 |
Kit-Starter Spring This part replaces 530042095. Price: $3.99 |
| 25 |
3218-7 |
NUT-JAM Price: $3.86 |
| 25 |
579372001 |
FAN HOUSING This part replaces 530058810. Price: $9.99 |
| 26 |
3253-9 |
WASHER-LOCK Price: $1.02 |
| 26 |
530056402 |
Handle-Starter Price: $2.99 |
| 27 |
3-8635 |
DISCONTINUED Price: Call Us |
| 27 |
530069232 |
Kit-Rope Price: $3.99 |
| 28 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 28 |
530016432 |
Screw Price: $1.99 |
| 29 |
42-4130 |
DISCONTINUED Price: Call Us |
| 29 |
530016080 |
Screw Price: $1.99 |
| 30 |
5-2932 |
DISCONTINUED Price: Call Us |
| 30 |
530058786 |
Assy-Oil Vent Price: $2.99 |
| 31 |
42-4120 |
PIVOT FRAME BOLT Price: $80.02 |
| 31 |
530057236 |
Assy-Oil Cap w/ret. Price: $5.99 |
| 32 |
3219-3 |
NUT-HEX Price: $0.34 |
| 32 |
530057897 |
Handguard Price: $7.99 |
| 33 |
38-7780 |
DISCONTINUED Price: Call Us |
| 33 |
530016416 |
Spring-Handguard Price: $1.99 |
| 34 |
38-7790 |
DISCONTINUED Price: Call Us |
| 35 |
38-6820 |
DISCONTINUED Price: Call Us |
| 35 |
530071893 |
Kit-Chainbrake Price: $17.99 |
| 36 |
40-8060 |
DISCONTINUED Price: Call Us |
| 36 |
530016432 |
Screw Price: $1.99 |
| 37 |
38-9510 |
DISCONTINUED Price: Call Us |
| 37 |
530016133 |
Bolt-Bar Price: $1.99 |
| 38 |
323-6 |
SCREW-HH Price: $0.66 |
| 38 |
530057910 |
Plate-Bar Price: $1.99 |
| 39 |
3290-414 |
WASHER-BELLEVILLE Price: $1.97 |
| 39 |
530015917 |
Nut-Bar Price: $0.99 |
| 40 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 41 |
29-3910 |
DISCONTINUED Price: Call Us |
| 42 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 42 |
530015826 |
Pin-Bar Adjust Price: $1.99 |
| 43 |
5-1703 |
DISCONTINUED Price: Call Us |
| 43 |
530038593 |
Retainer-Bar Adjust Price: $0.99 |
| 44 |
119-4151 |
SCREW-BEDKNIFE This part replaces 3-6462. Price: $0.41 |
| 44 |
581562301 |
P/PP CHN 18" 62DL 3/8 .050 This part replaces 952051338. Price: $19.99 |
| 45 |
38-7420 |
BEDKNIFE, RM Price: $72.14 |
| 45 |
952044418 |
Accy-18" Bar Price: $30.95 |
| 46 |
5-4048 |
DISCONTINUED Price: Call Us |
| 47 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 47 |
530016432 |
Screw Price: $1.99 |
| 48 |
323-7 |
SCREW-HH Price: $0.65 |
| 48 |
530057888 |
Handle-Front Price: $14.99 |
| 49 |
3245-35 |
SCREW-SET, HSH Price: $0.41 |
| 50 |
5-3824 |
DISCONTINUED Price: Call Us |
| 50 |
530057924 |
Assy-Oil Pick Up Price: $2.99 |
| 51 |
38-7410 |
DISCONTINUED Price: Call Us |
| 51 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 52 |
38-7800 |
DISCONTINUED Price: Call Us |
| 52 |
581071401 |
OIL PUMP ASSY SAS This part replaces 530057931. Price: $5.99 |
| 53 |
5-2186 |
REEL BEARING Price: $45.95 |
| 54 |
5-3838 |
DISCONTINUED Price: Call Us |
| 55 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 56 |
253-121 |
DISCONTINUED Price: Call Us |
| 57 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 58 |
3296-45 |
NUT-HEX Price: $3.79 |
| 59 |
3220-3 |
NUT-HJ Price: $0.28 |
| 60 |
38-7730 |
DISCONTINUED Price: Call Us |
| 61 |
3290-255 |
PIN-COTTER, HAIR Price: $7.89 |
| 62 |
5-3837 |
DISCONTINUED Price: Call Us |
| 63 |
38-6880 |
DISCONTINUED Price: Call Us |
| 64 |
322-10 |
SCREW-HH Price: $0.70 |
| 65 |
2-1590 |
DISCONTINUED Price: Call Us |
| 66 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 67 |
322-2 |
SCREW-HH Price: $0.69 |
| 68 |
3-9381 |
DISCONTINUED Price: Call Us |
