| Ref | Part Number | Description |
|---|
| 1 |
21-3600 |
FOAM-SUPPORT, TANK Price: $25.75 |
| 1 |
603000558 |
LOCKNUT, M6-1.00 NYLON INSERT Price: $1.99 |
| 2 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 2 |
603000773 |
SEAT HOLDER BASE Price: $24.99 |
| 3 |
32104-96 |
SCREW-HH Price: $5.59 |
| 3 |
603001049 |
PAN, CENTER, CLOSEOUT Price: $74.99 |
| 4 |
37-9550 |
STRAP-TANK, FUEL Price: $46.74 |
| 4 |
603001585 |
BRKT, SEATBELT, BOLT-ON Price: $24.99 |
| 5 |
603001673 |
WASHER, HARD, M10, ZN-NI/BLK Price: $1.99 |
| 5 |
62-7650 |
GASKET Price: $4.28 |
| 6 |
62-6840 |
FUEL LEVEL SENDER Price: $114.30 |
| 7 |
32144-53 |
SCREW-SHWH, THREAD FORMING Price: $3.19 |
| 7 |
603003464 |
COVER, CENTER CONSOLE Price: $279.99 |
| 8 |
353-536 |
DISCONTINUED Price: Call Us |
| 8 |
603000695 |
SCREW, TUFLOK PANEL, 1/4 Price: $1.99 |
| 9 |
2412-6 |
CLAMP-HOSE Price: $4.57 |
| 9 |
603003475 |
NUT, FLANGED, M10 X 1.5, BLACK Price: $2.99 |
| 10 |
110-3257 |
HOSE-FUEL This part replaces 63-7630. Price: $17.26 |
| 11 |
55-3574 |
GAS CAP ASM Price: $15.94 |
| 11 |
603000125 |
HINGE PLATE Price: $8.99 |
| 12 |
43-9110 |
GAS TANK ASM Price: $439.33 |
| 12 |
603000736 |
RIVET, 1/4 X .438 BLIND Price: $6.99 |
| 13 |
21-3610 |
FOAM-SUPPORT, TANK Price: $20.11 |
| 13 |
603000774 |
SCREW, 6M-1.00 X 10MM HEX HEAD Price: $2.99 |
| 14 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 14 |
603000777 |
SEAT HOLDER CUP Price: $29.99 |
| 15 |
603000875 |
BOLT - FLANGED HD, M8 X 30.0 Price: $2.99 |
| 16 |
603001298 |
NUT FLG, M8 X 1.25 MECH DEF Price: $1.99 |
| 17 |
603001093 |
PAN, SEAT, DRIVER ASM Price: $229.99 |
| 18 |
603001102 |
DECAL, WARNING HOT SURFACE Price: $3.99 |
| 19 |
603001137 |
ADJUSTER, FORE/AFT Price: $64.99 |
| 20 |
603001138 |
ADJUSTER, SLIDER Price: $49.99 |
| 21 |
2412-96 |
CLAMP-R Price: $3.46 |
| 21 |
603001145 |
WASHER, BELL Price: $5.99 |
| 22 |
110-0462 |
HOSE-FUEL This part replaces 92-1662. Price: $3.76 |
| 22 |
603004080 |
SEAT, BUCKET, BLACK Price: $349.99 |
| 23 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 23 |
603000058 |
LOCKWASHER, 1/4 HELICAL SPLIT Price: $1.99 |
| 24 |
22-7810 |
SPACER Price: $16.90 |
| 25 |
321-6 |
SCREW-HH Price: $0.25 |
| 25 |
603000125 |
HINGE PLATE Price: $8.99 |
| 26 |
42-6080 |
SHIM-AXLE Price: $29.45 |
| 26 |
603000579 |
SCREW, M8-125 X 22 HEX GR.8.8 Price: $2.99 |
| 27 |
603000184 |
LOCKWASH Price: $1.99 |
| 27 |
86-9600-03 |
AXLE ASM This part replaces 86-9600. Price: $3,784.17 |
| 28 |
231-101 |
TIRE (23X8.5-12) 4-PLY TURF SAVER Price: $147.85 |
| 28 |
603000689 |
PAN, SEAT - PASSENGER Price: $89.99 |
| 29 |
217-117 |
WHEEL Price: $164.56 |
| 29 |
603000736 |
RIVET, 1/4 X .438 BLIND Price: $6.99 |
| 30 |
23-7270 |
NUT-LUG Price: $10.37 |
| 30 |
603000774 |
SCREW, 6M-1.00 X 10MM HEX HEAD Price: $2.99 |
| 31 |
5108 |
VALVE This part replaces 232-31. Price: $6.29 |
| 31 |
603000777 |
SEAT HOLDER CUP Price: $29.99 |
| 32 |
32144-67 |
SCREW Price: $2.87 |
| 32 |
603001102 |
DECAL, WARNING HOT SURFACE Price: $3.99 |
| 33 |
32128-20 |
NUT-HF Price: $0.99 |
| 33 |
603004080 |
SEAT, BUCKET, BLACK Price: $349.99 |
| 34 |
603000058 |
LOCKWASHER, 1/4 HELICAL SPLIT Price: $1.99 |
| 35 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 35 |
603000054 |
WASHER 1/4 FLAT Price: $1.99 |
| 36 |
2811-9 |
FITTING-ELBOW-90 Price: $15.86 |
| 37 |
289-37 |
NIPPLE-PIPE Price: $21.68 |
| 38 |
23-5180 |
DIPSTICK ASM Price: $69.61 |
| 40 |
68-9760 |
DISCONTINUED Price: Call Us |
| 41 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 42 |
3219-14 |
NUT-HEX Price: $0.25 |
| 43 |
108-3831 |
FILTER-FUEL This part replaces 18-1520. Price: $10.09 |
| 44 |
110-6184 |
HOSE-FUEL This part replaces 92-1661. Price: $49.59 |
