| Ref | Part Number | Description |
|---|
| 1 |
127-3107 |
GASKET-MANIFOLD, INTAKE Price: $21.63 |
| 2 |
127-3135 |
INTAKE MANIFOLD ASM Price: $518.40 |
| 3 |
127-3134 |
MANIFOLD-INTAKE Price: $263.05 |
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 581056301. Price: $5.99 |
| 4 |
127-3180 |
STUD Price: $3.41 |
| 5 |
127-3031 |
SENSOR-TEMP, AIR Price: $1,039.57 |
| 5 |
585529804 |
DASH Price: $29.99 |
| 6 |
125-7220 |
BOLT Price: $4.99 |
| 7 |
127-3152 |
DUCT-SUCTION Price: $220.31 |
| 8 |
127-3096 |
JOINT-RUBBER Price: $332.63 |
| 9 |
127-3153 |
JOINT-RUBBER Price: $108.13 |
| 10 |
125-7189 |
CLAMP-HOSE Price: $4.61 |
| 11 |
127-3170 |
CLAMP-HOSE Price: $23.69 |
| 12 |
125-7190 |
CLAMP-HOSE Price: $12.29 |
| 13 |
127-3171 |
CLAMP-HOSE Price: $6.48 |
| 14 |
127-3034 |
GASKET-COLLECTOR Price: $9.66 |
| 14 |
532441267 |
HOOD.HUSQVARNA.LT.ORANGE Price: $79.99 |
| 15 |
127-3093 |
INTAKE COLLECTOR ASM Price: $584.00 |
| 15 |
532406664 |
LENS.HUSQVARNA LT.LH This part replaces 532441428. Price: $14.99 |
| 16 |
127-3092 |
COLLECTOR-INTAKE Price: $203.81 |
| 17 |
127-3139 |
VALVE-REED Price: $187.29 |
| 18 |
127-3080 |
JOINT-HOSE Price: $52.33 |
| 18 |
584382301 |
GRILLE.SVC.HUSQVARNA.L This part replaces 532441368. Price: $54.99 |
| 19 |
127-3081 |
JOINT-HOSE Price: $79.17 |
| 20 |
127-3166 |
WASHER-SEAL Price: $6.77 |
| 21 |
127-3168 |
SCREW Price: $2.67 |
| 22 |
127-3181 |
STUD Price: $3.97 |
| 23 |
127-3045 |
SPACER-VALVE, E G R Price: $34.81 |
| 24 |
127-3046 |
GASKET-E G R Price: $4.88 |
| 25 |
125-7220 |
BOLT Price: $4.99 |
| 25 |
532406663 |
LENS.HUSQVARNA LT.RH This part replaces 532441427. Price: $14.99 |
| 26 |
127-3178 |
BOLT Price: Call Us |
| 27 |
127-3182 |
STUD Price: $2.86 |
| 28 |
125-7229 |
NUT Price: $3.12 |
| 29 |
127-3035 |
BEND-INLET Price: Call Us |
| 30 |
127-3036 |
BODY-THROTTLE Price: $1,205.87 |
| 31 |
127-3037 |
GASKET-THROTTLE Price: $2.87 |
| 32 |
125-7209 |
BOLT Price: $2.74 |
| 33 |
125-7211 |
BOLT Price: $3.48 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532447253. Price: $59.99 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
532441266 |
FENDER.TLT.FS.W/CUPHLD.ORANGE Price: $179.99 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 125 |
581684801 |
CLIP.FUEL.LINE Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 146 |
581857901 |
BOLT.RDHD.SHT.SQNK.3/8-16X5/8 Price: $3.99 |
| 150 |
532407537 |
DUCT.AIR. Price: $34.99 |
| 151 |
532407807 |
BRACKET PIVOT Price: $27.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 175 |
532199472 |
CROSSMEMBER Price: $24.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195228 |
BUSHING STEERING Price: $4.99 |
| 180 |
579841501 |
KITS.CHASSIS.WELD.SERVICE This part replaces 532195457. Price: $219.99 |
| 182 |
532407176 |
DASH.LOWER.PREDATOR LT Price: $69.99 |
| 183 |
595305701 |
Screws This part replaces 874520520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 191 |
583358401 |
INSERT.REFLECTIVE.RH. This part replaces 532416501. Price: $11.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 199 |
532413485 |
PLATE.DECK.LIFT.HUSQ.LT Price: $9.99 |
| 202 |
532441342 |
VENT.SIDE.HUSQVARNA.LT.RT Price: $11.99 |
| 203 |
532406671 |
VENT SIDE HOOD This part replaces 532441343. Price: $8.99 |
| 204 |
532441375 |
SUBASM.TOP.VENT.HUSQ.LT Price: $17.99 |
| 205 |
532441344 |
SKIRT.SIDE.HUSQVARNA.LT.RT Price: $11.99 |
| 206 |
532441345 |
SKIRT.SIDE.HUSQVARNA.LT.LEFT Price: $11.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532407881 |
TRIM.HUSQ LT.668 This part replaces 532441374. Price: $19.99 |
| 239 |
532404883 |
IS ITO Price: $5.99 |
| 282 |
532414110 |
CLIP.RETAINER.CONSOLE.LT.HUSQ Price: $2.99 |
| 283 |
532439151 |
CONSOLE.ASM.LFT.RSF.HUSQ.LT This part replaces 532442039. Price: $37.99 |
| 284 |
532439150 |
CONSOLE.SHFT.PDL.CNTRL.HUSQ.LT This part replaces 532439823. Price: $39.99 |
| 285 |
532416315 |
CONSOLE INSERT RH Price: $14.99 |
| 286 |
532416317 |
CONSOLE.INSRT.LH.HUSQ.LT.BLACK Price: $11.99 |
| 287 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 297 |
532406665 |
INSERT REFLECTIVE Price: $6.99 |
| 306 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
