| Ref | Part Number | Description |
|---|
| 1 |
139-2651 |
CYLINDER, HYD This part replaces 99-4263. Price: $671.34 |
| 2 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 2 |
576701302 |
PLATE FLOOR PAN ORANGE Price: $109.99 |
| 3 |
522738904 |
BUMPER.REAR.W/DECALS This part replaces 522738902. Price: $149.99 |
| 3 |
93-2255 |
HYD HOSE ASM Price: $52.69 |
| 4 |
576701402 |
PLATE.SKID.GRAY Price: $199.99 |
| 4 |
93-2256 |
HYD HOSE ASM Price: $52.48 |
| 5 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 5 |
574433003 |
GUARD, REAR W/DECALS This part replaces 574433002. Price: $449.99 |
| 6 |
574215702 |
PLATE, FOOT REST, OR Price: $99.99 |
| 6 |
94-8198 |
PIN Price: $31.05 |
| 7 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 8 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 9 |
283-68 |
PIN-CLEVIS Price: $11.26 |
| 9 |
576701702 |
COVER, CENTER BLK Price: $84.99 |
| 10 |
510083201 |
MOUNT, F/F INSERT Price: $4.99 |
| 11 |
576453602 |
MOUNT TANK BLK Price: $17.99 |
| 11 |
99-4115 |
FRONT LIFT FRAME ASM Price: $384.07 |
| 12 |
33096-00 |
WASHER-FLAT Price: $1.76 |
| 12 |
510040302 |
Brackets This part replaces 510040301. Price: $12.99 |
| 13 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 14 |
525612802 |
Screws This part replaces 525612801. Price: $2.99 |
| 15 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 15 |
574233802 |
Hardware This part replaces 574233801. Price: $2.99 |
| 16 |
596241601 |
Bolts This part replaces 539131780. Price: $1.99 |
| 16 |
99-4201 |
TUBE-SPACER Price: $10.91 |
| 17 |
596030701 |
Screws This part replaces 539990858. Price: $2.99 |
| 17 |
99-4258 |
RH LINK BRACKET ASM Price: $51.12 |
| 18 |
525544002 |
Bolts This part replaces 525544001. Price: $3.99 |
| 18 |
99-4260 |
LH LINK BRACKET ASM Price: $51.12 |
| 19 |
595901401 |
Bolts This part replaces 539100145. Price: $2.99 |
| 20 |
593337201 |
SCREW HEXAGON HEAD WITH COLLAR This part replaces 539113226. Price: $2.99 |
| 21 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 21 |
99-4213 |
RH LIFT ARM ASM Price: $303.22 |
| 22 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 22 |
99-4212 |
LH LIFT ARM ASM Price: $303.22 |
| 23 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 23 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 24 |
596565001 |
Washers This part replaces 539109600. Price: $2.99 |
| 24 |
93-2254 |
HYD HOSE ASM Price: $65.17 |
| 25 |
596582301 |
Washers This part replaces 539990055. Price: $2.99 |
| 26 |
325-6 |
SCREW-HH Price: $1.42 |
| 26 |
594977401 |
Nuts This part replaces 539111028. Price: $1.99 |
| 27 |
3218-5 |
NUT-JAM Price: $0.27 |
| 27 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 28 |
93-2384 |
SPACER-CARRIER Price: $9.09 |
| 31 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 34 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 35 |
74-3730 |
SPACER-SPINDLE, REAR Price: $5.06 |
| 38 |
32144-69 |
SCREW-HWHTF Price: $1.58 |
| 39 |
325-4 |
SCREW-HH Price: $0.95 |
| 40 |
325-14 |
SCREW-HH Price: $2.64 |
| 41 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 42 |
3250-17 |
SCREW-PPH Price: $1.76 |
| 43 |
99-4111-01 |
PLATE-TRANSPORT, 1 AND 3 Price: $49.03 |
| 44 |
99-4112-01 |
PLATE-TRANSPORT, 2 Price: $47.73 |
| 51 |
99-4225 |
PAD-WEAR Price: $10.18 |
