| Ref | Part Number | Description |
|---|
| 1 |
304-46 |
DRAINCOCK Price: $7.55 |
| 1 |
532186093 |
WHEEL.STEERING.LEGND2.GRY This part replaces 532193943. Price: $89.99 |
| 2 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
32128-44 |
NUT Price: $2.69 |
| 4 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532194743. Price: $14.99 |
| 5 |
119-2028 |
RADIATOR AND OIL COOLER ASM Price: $1,787.22 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532194744. Price: $19.99 |
| 6 |
121-3556-0P |
SHROUD-FAN, UPPER This part replaces 121-3556-03. Price: $127.39 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
121-3552-0P |
SHROUD-FAN, LOWER This part replaces 121-3552-03. Price: $184.71 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 10 |
120-3530-0P |
BRACKET-RADIATOR, BOTTOM This part replaces 120-3530-03. Price: $78.45 |
| 13 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
121-3557-0P |
BRACKET-RESEVOIR This part replaces 121-3557-03. Price: $26.66 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
95-8702-0P |
SHIELD-RADIATOR, LOWER This part replaces 95-8702-03. Price: $47.95 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 21 |
99-3497 |
MAGNET Price: $20.22 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
121-3558 |
HOSE-RADIATOR, UPPER Price: $46.41 |
| 24 |
121-3574 |
HOSE-RADIATOR, LOWER Price: $45.90 |
| 25 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 26 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 26 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 27 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 28 |
92-7536 |
HOSE-HYD Price: $196.76 |
| 33 |
99-7435 |
RELAY Price: $32.43 |
| 34 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 35 |
109-0274 |
HOSE-FUEL Price: $12.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 37 |
121-3609 |
TUBE-HYD Price: $143.00 |
| 38 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 40 |
108-0638 |
BOTTLE-OVERFLOW This part replaces 104-9318. Price: $33.20 |
| 41 |
93-6681 |
DECAL-WARNING, FAN Price: $11.51 |
| 42 |
32128-20 |
NUT-HF Price: $0.99 |
| 43 |
120-3529-03 |
BRACKET-RADIATOR, TOP Price: $62.39 |
| 44 |
120-3531-0P |
BRACKET-RADIATOR, LH This part replaces 120-3531-03. Price: $54.92 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532197636 |
SPACER.BRACE.AXLE (2 2) Price: $5.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
