| Ref | Part Number | Description |
|---|
| 1 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 1 |
530038403 |
Limiter Cap Price: $1.99 |
| 1 |
631030 |
SHAFT & LEV Price: Call Us |
| 2 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 2 |
631045 |
RET SPRING Price: Call Us |
| 3 |
631621 |
SHUTTER Price: $1.20 |
| 3 |
68-6710 |
ROLLER Price: $59.98 |
| 4 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
68-6840 |
SHAFT-ROLLER Price: $64.07 |
| 6 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 119-4776. Price: $589.65 |
| 6 |
630953 |
PUMP ELEMENT Price: $6.03 |
| 7 |
631268 |
SHAFT & LEV Price: Call Us |
| 8 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 8 |
631048 |
SPRING Price: Call Us |
| 9 |
3269-24 |
RIVET Price: $1.79 |
| 9 |
630758 |
SHUTTER Price: $1.20 |
| 10 |
630748 |
WELCH PLUG Price: $1.17 |
| 10 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 11 |
108-1908 |
SPACER-IDLER Price: $23.93 |
| 11 |
650569 |
SCREW Price: Call Us |
| 12 |
3233-34 |
SCREW-CARR Price: $7.98 |
| 12 |
631505 |
INLET NEEDLE Price: Call Us |
| 13 |
107-4788 |
BELT-HEX Price: $178.28 |
| 13 |
631506 |
SPRING Price: Call Us |
| 14 |
140-5847 |
PULLEY-IDLER This part replaces 01-268-0160. Price: $98.46 |
| 14 |
632019A |
FLOAT This part replaces 631023. Price: $5.85 |
| 15 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 15 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 16 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 16 |
631949 |
FLOAT BOWL This part replaces 631332. Price: $5.16 |
| 17 |
108-1926 |
WASHER Price: $5.30 |
| 17 |
27136A |
DRAIN ASSY Price: $5.96 |
| 18 |
108-1921 |
SPRING-TORSION Price: $28.33 |
| 18 |
27554 |
GASKET Price: $1.05 |
| 19 |
140-7078 |
IDLER ARM ASM This part replaces 108-1930. Price: $49.85 |
| 19 |
631553 |
SCREEN Price: Call Us |
| 20 |
632259A |
GASKET This part replaces 631554. Price: Call Us |
| 21 |
32120-84 |
RING-SNAP, EXTERNAL Price: $0.61 |
| 21 |
631334A |
GASKET This part replaces 631334. Price: $2.25 |
| 22 |
3296-45 |
NUT-HEX Price: $3.79 |
| 23 |
108-1924 |
SPACER-IDLER Price: $11.13 |
| 24 |
108-1993 |
SCREW-HSBH Price: $3.66 |
| 24A |
631271 |
IDLE SCREW Price: Call Us |
| 25 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 25 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 26 |
111-5429 |
PAD-BUMPER Price: $3.00 |
| 26 |
631555 |
VALVE Price: Call Us |
| 27 |
632338 |
VALVE COVER This part replaces 631633. Price: Call Us |
| 29 |
139-1035 |
SINGLE DRIVING SPINDLE ASM This part replaces 119-4547. Price: $986.94 |
| 29 |
631335 |
LEAD SHOT Price: Call Us |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 30 |
650699 |
SCREW Price: $1.17 |
