| Ref | Part Number | Description |
|---|
| 1 |
532199298 |
DECK.SVC.54".5GWB.GREY This part replaces 532403125. Price: $449.99 |
| 1 |
603-0671 |
BRAKE SHAFT ASSEMBLY Not Available Price: |
| 2 |
603-0672A |
FWD/REV SHAFT ASSEMBLY Not Available This part replaces 603-0672. Price: |
| 3 |
603-0673A |
PEDAL MOUNTING LINK ASSEMBLY Not Available Price: |
| 4 |
603-0674A |
PEDAL BEARING PLATE Not Available Price: |
| 4 |
93-4278 |
PIN-DOWEL Price: $3.65 |
| 5 |
603-0678 |
BRAKE LINK ASSEMBLY (LH) Not Available Price: |
| 6 |
532196066 |
COVER.MANDREL.LH.54"20 Price: $22.99 |
| 6 |
603-0679A |
BRAKE LINK ASSEMBLY Not Available Price: |
| 7 |
532197181 |
COVER.MANDREL.RH.54.20 Price: $27.99 |
| 7 |
603-0680 |
BRAKE LINK ASSEMBLY (RH) Not Available Price: |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 532174365. Price: $6.99 |
| 8 |
603-0749 |
DIFF LOCK SHAFT ASSEMBLY Not Available Price: |
| 9 |
603-0770 |
PTO SELECT LINK ASSEMBLY Not Available Price: |
| 9 |
93-4280 |
COUPLING Price: $180.40 |
| 10 |
703-05183-0637 |
SWITCH BRACKET (POWDER BLACK) This part replaces 703-05183. Price: $37.04 |
| 11 |
703-3541 |
DIFF PIVOT BRACKET Not Available Price: |
| 12 |
596274401 |
Rods This part replaces 532400337. Price: $9.99 |
| 12 |
703-3571A |
HANDLE-PT Not Available Price: |
| 13 |
597023501 |
MANDRELS This part replaces 532187291. Price: $24.99 |
| 13 |
703-3575 |
LINK-DIFF LOCK PIV Not Available Price: |
| 13 |
93-4279 |
PLATE-DISTANCE Price: $438.47 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 14 |
703-3582 |
DIFF ACTUATOR BRACKET Not Available Price: |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 15 |
703-4099-0637 |
REVERSE SWITCH BRACKET Not Available This part replaces 703-4099. Price: |
| 16 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 16 |
710-0599 |
Screw, Hex Wash Hd Tapp 1/4-20 x .5 Price: $3.86 |
| 17 |
710-0642 |
Screw, Hex Wash Hd Tapp 1/4-20 x .75 Price: $4.05 |
| 17 |
93-4283 |
BOLT Price: $55.59 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 18 |
710-1260A |
Screw, Hex Wash Hd Tapp 5/16-18 x .75 Price: $3.34 |
| 18 |
93-4282 |
BLOCK-VALVE Price: $371.58 |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 19 |
710-0654A |
Screw, Hex Wash Hd Tapp 3/8-16 x 1.0 Price: $3.75 |
| 19 |
93-4277 |
DISCONTINUED Price: Call Us |
| 20 |
711-0415 |
Pin, Clevis, 3/8 x 1.75 Price: $4.04 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 21 |
911-0723A |
FERRULE 3/8-24 x .375 x 1.31 LG Not Available This part replaces 711-0723A. Price: |
| 22 |
711-1362 |
FERRULE .385 x .25 Not Available Price: |
| 22 |
93-4281 |
PIN-DOWEL Price: $10.71 |
| 23 |
711-3397 |
FERRULE 3/8-24 Not Available Price: |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 24 |
712-0239 |
Nut, Hex Lock, 1/2-20 Price: $5.01 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 25 |
712-0379 |
Nut, Hex Flange Lock, 3/8-24 Price: $4.02 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 27 |
532187257 |
DEFLECTOR.BLACK.54" This part replaces 532188938. Price: $64.99 |
| 27 |
712-0711 |
Nut, Hex Jam, 3/8-24 Price: $3.90 |
| 28 |
912-3027 |
Nut, Hex Flange Lock 1/4-20 This part replaces 712-3027. Price: $3.85 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 29 |
712-3077 |
HEX NUT M8X1.25 GR8.8 Not Available Price: |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 30 |
913-3000 |
CHAIN LINK Not Available This part replaces 713-3000. Price: |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 31 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 32 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 32 |
714-0147 |
Pin, Internal Cotter Price: $4.20 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 33 |
714-3020 |
Pin, Internal Cotter Price: $3.90 |
| 34 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 34 |
925-3164A |
Switch, Interlock This part replaces 725-3164A. Price: $37.67 |
| 36 |
927-04033 |
DAMPER CYLINDER FW This part replaces 727-04033. Price: $137.79 |
| 37 |
731-3296 |
BRAKE FOOT PEDAL Not Available Price: |
| 38 |
731-3299A |
FWD/REV FOOT PEDAL Not Available Price: |
| 39 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 39 |
731-3320 |
DIFF LOCK PEDAL Not Available Price: |
| 40 |
731-3321 |
Grip, Handle Price: $18.83 |
| 41 |
732-0324 |
Spring, Compression Not Available Price: |
| 42 |
932-0756A |
Spring, Torsion This part replaces 732-0756A. Price: $12.90 |
| 43 |
531169301 |
SERVICE KIT ARM.IDLER This part replaces 532196065. Price: $9.99 |
| 43 |
732-0859A |
SPRING Not Available This part replaces 732-0859. Price: |
| 44 |
732-3065 |
Spring, Compression Price: $3.22 |
| 45 |
732-3117 |
Spring, Switch Actuator Price: $7.01 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 46 |
732-3118 |
Spring, Extension Price: $8.78 |
| 47 |
587686701 |
BELT.DECK.DRIVE.BELT.54 This part replaces 532196103. Price: $54.99 |
| 47 |
736-0173 |
Washer, Flat, .28 x .74 x .063 Price: $3.76 |
| 48 |
736-0185 |
Washer, Flat, .375 x .738 x .063 Price: $3.43 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 49 |
736-0232 |
Washer, Wave, .53 x .78 x .013 Price: $4.02 |
| 50 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 50 |
736-3019 |
Washer, Flat, .53 x .1.06 x .134 Price: $5.45 |
| 51 |
736-3069 |
FLAT WASHER .531IDX.875ODX. Not Available Price: |
| 52 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 52 |
738-0509 |
SHOULDER SCREW .498 DI Not Available Price: |
| 53 |
738-0533 |
SCREW:SHLDR:0.498X1.630:3/8-16 This part replaces 7380533. Price: $7.42 |
| 54 |
938-0689 |
Screw, Shoulder, 3/8-24 x 1/2 x .180 This part replaces 738-0689. Price: $7.87 |
| 55 |
741-0491 |
Bearing, Nylon. .50 ID x .341 Price: $4.39 |
| 56 |
941-0598 |
Hex Flange Bearing, .752 This part replaces 741-0598. Price: $11.91 |
| 57 |
941-3073 |
Bearing, Flng., .375 x .580 x .250 This part replaces 741-3073. Price: $4.66 |
| 58 |
531168601 |
SERVICE KIT BAFFLE.RIGHT.54" This part replaces 532187342. Price: $12.99 |
| 58 |
741-3074 |
Bearing, Flange .626 x .938 x .344 Price: $4.22 |
| 59 |
531168701 |
SERVICE KIT BAFFLE.LEFT.54" BA This part replaces 532187344. Price: $19.99 |
| 59 |
741-3084 |
Bearing, Flange .751 x 1.125 x .375 Price: $4.55 |
| 60 |
531168801 |
SERVICE KIT BAFFLE BAFFLE CENT This part replaces 532187607. Price: $19.99 |
| 60 |
747-3396 |
HYDRO CONTROL ROD Not Available Price: |
| 61 |
747-3399A |
BRAKE ROD (LH) Not Available This part replaces 747-3399. Price: |
| 62 |
747-3400 |
BRAKE ROD (RH) Not Available Price: |
| 63 |
747-3414 |
PTO CONTROL ROD Not Available Price: |
| 64 |
747-3428 |
DIFF LOCK CONTROL ROD Not Available Price: |
| 97 |
532178515 |
WASHER Price: $5.99 |
| 98 |
547878302 |
SPRING BELT TENSIONER BLACK This part replaces 532196105. Price: $5.99 |
| 113 |
596435701 |
Bolts This part replaces 872110508. Price: $2.99 |
| 114 |
532187556 |
ROD TENSION RELIEF Price: $17.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 120 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 122 |
532187557 |
BUSHING.RELIEF.TENSION Price: $7.99 |
| 185 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 187 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 188 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 189 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 190 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 192 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $7.99 |
| 194 |
874490736 |
BOLT.HEX.WASHER.HEAD.7/16-24X This part replaces 872140716. Price: $9.99 |
| 196 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
