| Ref | Part Number | Description |
|---|
| 1 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 1 |
532121006 |
LEVER ROD LT Price: $24.99 |
| 2 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 2 |
532177535 |
SHAFT ASM, LIFT This part replaces 532159187. Price: $55.99 |
| 3 |
322-10 |
SCREW-HH Price: $0.70 |
| 3 |
532159189 |
LEVER ASSY-LIFT RH Price: $79.99 |
| 4 |
32105-21 |
SCREW-HH Price: $1.09 |
| 4 |
812000022 |
E-RING Price: $3.99 |
| 5 |
819292016 |
Washer 29/32 x 1-1/4 x 16 Ga. Price: $6.99 |
| 6 |
29-6162 |
SWITCH-MICRO Price: $107.13 |
| 6 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 874780624. Price: $6.99 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 7 |
75-4130 |
PLATE-SWITCH Price: $13.26 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 8 |
76-9430-03 |
SPRING-EXTENTION This part replaces 76-9430. Price: $28.14 |
| 9 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 9 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532122364. Price: $5.99 |
| 10 |
322-7 |
SCREW-HH Price: $0.89 |
| 10 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 11 |
251-259 |
BEARING-BALL Price: $13.67 |
| 11 |
532145543 |
LINK ASSY This part replaces 532146704. Price: $17.99 |
| 12 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 12 |
75-5470 |
SPACER-BEARING Price: $3.06 |
| 13 |
32144-22 |
SCREW Price: $0.75 |
| 13 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 14 |
532169865 |
BEARING.PIVOT.LIFT This part replaces 532140302. Price: $5.99 |
| 15 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 15 |
75-4080-03 |
PLATE-TRACTION ASM This part replaces 75-4080. Price: $56.27 |
| 16 |
532123994 |
SPRING This part replaces 532124687. Price: $57.46 |
| 16 |
85-9900-03 |
PLATE-ANCHOR, SPRING This part replaces 85-9900. Price: $21.09 |
| 17 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 17 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 18 |
532143363 |
BRACKET Price: $3.99 |
| 19 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 19 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 20 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 20 |
532005328 |
BOLT Price: $2.99 |
| 21 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 21 |
75-4090 |
DISCONTINUED Price: Call Us |
| 22 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 22 |
532127218 |
FRONT LINK Price: $14.99 |
| 23 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 23 |
76-8640 |
STUD-TRACTION Price: $23.60 |
| 24 |
3296-9 |
NUT-HEX Price: $0.25 |
| 24 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 25 |
532175689 |
TRUNNION This part replaces 532130171. Price: $3.99 |
| 25 |
75-4100-03 |
CONTROL-PUMP This part replaces 75-4100. Price: $198.81 |
| 26 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 26 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 27 |
85-9910 |
EYEBOLT Price: $28.77 |
| 29 |
532150233 |
TRUNNION Price: $9.99 |
| 30 |
532110807 |
NUT T Price: $3.99 |
| 31 |
819131016 |
WASHER Price: $2.99 |
| 32 |
532137150 |
SPRING.COMP.INF.H Price: $4.99 |
| 33 |
596917601 |
Pins This part replaces 876020308. Price: $1.99 |
| 34 |
532137167 |
ROD.LIFT.ADJUSTABLE Price: $5.99 |
| 35 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 38 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 39 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 40 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 41 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 42 |
819112410 |
WASHER Price: $3.99 |
| 43 |
532123934 |
HEIGHT INDICATOR Price: $2.99 |
| 70 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
