| Ref | Part Number | Description |
|---|
| 1 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 1 |
493260 |
CYLINDER ASSY Price: Call Us |
| 2 |
293708 |
BUSHING, CYLINDER Price: Call Us |
| 2 |
76-9790 |
FOAM-TANK, FUEL Price: $10.89 |
| 3 |
299819 |
SEAL, OIL Price: Call Us |
| 3 |
74-5580 |
DISCONTINUED Price: Call Us |
| 4 |
493279 |
SUMP, ENGINE Price: Call Us |
| 4 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 5 |
214368 |
HEAD, CYLINDER Price: Call Us |
| 5 |
76-6600 |
PIPE-STAND Price: $70.58 |
| 6 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 7 |
272916 |
GASKET, CYLINDER HEAD Price: Call Us |
| 7 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 8 |
46-6560 |
BUSHING Price: $2.94 |
| 8 |
495786 |
BREATHER, VALVE CHAMBER Price: Call Us |
| 9 |
106-1018 |
BRACKET-COVER This part replaces 82-3660. Price: $12.55 |
| 9 |
272481 |
GASKET, VALVE COVER Price: Call Us |
| 9A |
272238 |
GASKET, BAFFLE PLATE Price: Call Us |
| 10 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 10 |
94650 |
SCREW Price: Call Us |
| 11 |
231933 |
TUBE, BREATHER Price: Call Us |
| 11 |
68-6150 |
BREATHER Price: $27.22 |
| 12 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 12 |
272198 |
GASKET, CRANKCASE Price: Call Us |
| 13 |
76-8780 |
DECAL-CAUTION, FUEL Price: $7.93 |
| 13 |
94547 |
SCREW, CYLINDER HEAD Price: Call Us |
| 14 |
323-4 |
SCREW-HH Price: $1.02 |
| 15 |
354-95 |
FITTING-STRAIGHT Price: $6.75 |
| 15 |
94880 |
PLUG, OIL DRAIN, FLUSH Price: Call Us |
| 16 |
354-94 |
FITTING-FEMALE, BARBED Price: $9.70 |
| 16 |
498566 |
CRANKSHAFT Price: Call Us |
| 16 |
94388 |
TIMING GEAR KEY Price: Call Us |
| 17 |
74-9122 |
HOSE-OVERFLOW, RADIATOR Price: $20.47 |
| 18 |
240-6 |
GROMMET-RUBBER Price: $15.80 |
| 19 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 20 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 20 |
399781 |
SEAL, OIL Price: Call Us |
| 21 |
323-7 |
SCREW-HH Price: $0.65 |
| 22 |
110-4107 |
HOSE-FUEL This part replaces 63-7622. Price: $7.77 |
| 22 |
94220 |
SCREW, HEX HEAD Price: Call Us |
| 22 |
94612 |
SCREW, HEX HEAD Price: Call Us |
| 23 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 23 |
492177 |
FLYWHEEL Price: Call Us |
| 24 |
222698 |
KEY, FLYWHEEL Price: Call Us |
| 24 |
94-5614-03 |
BRACKET-METER, HOUR Price: $9.64 |
| 25 |
499429 |
PISTON ASSEMBLY Price: Call Us |
| 25 |
76-6590-03 |
Plate-Fuel Tank Price: Call Us |
| 26 |
108-3280 |
HOSE-FUEL This part replaces 63-7626. Price: $5.28 |
| 26 |
499425 |
RING SET, PISTON, STANDARD SIZE Price: Call Us |
| 27 |
263190 |
LOCK, PISTON PIN Price: Call Us |
| 27 |
32148-9 |
NUT-CLINCH Price: $2.65 |
| 28 |
499423 |
PIN, PISTON, STANDARD SIZE Price: Call Us |
| 28 |
62-7650 |
GASKET Price: $4.28 |
| 29 |
106-1014 |
SENDER-FUEL This part replaces 74-5860. Price: $246.39 |
| 29 |
499424 |
ROD, CONNECTING Price: Call Us |
| 30 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 31 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 32 |
321-3 |
SCREW-HH Price: $0.28 |
| 32 |
94699 |
SCREW Price: Call Us |
| 33 |
262651 |
VALVE, EXHAUST Price: Call Us |
| 33 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 34 |
262652 |
VALVE, INTAKE Price: Call Us |
| 34 |
70-1480 |
RELAY Price: $105.19 |
| 35 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 35 |
262224 |
SPRING, VALVE Price: Call Us |
| 36 |
76-5300 |
DISCONTINUED Price: Call Us |
| 40 |
93312 |
RETAINER, VALVE SPRING Price: Call Us |
| 45 |
262204 |
TAPPET, VALVE Price: Call Us |
| 46 |
498275 |
GEAR, CAM Price: Call Us |
| 47 |
493737 |
SLINGER, OIL Price: Call Us |
| 51 |
272199 |
GASKET, INTAKE ELBOW Price: Call Us |
| 54 |
94526 |
SCREW, HEX HEAD Price: Call Us |
| 55 |
497442 |
HOUSING, REWIND STARTER Price: Call Us |
| 56 |
498144 |
PULLEY, REWIND STARTER Price: Call Us |
| 58 |
280399 |
ROPE, REWIND STARTER (CUT TO 88-5/8) Price: Call Us |
| 60 |
281434 |
GRIP, STARTER ROPE Price: Call Us |
| 65 |
94696 |
SCREW Price: Call Us |
| 81 |
223664 |
LOCK, MUFFLER SCREW Price: Call Us |
| 95 |
94098 |
SCREW, THROTTLE Price: Call Us |
| 104 |
231371 |
PIN, FLOAT HINGE Price: Call Us |
| 110 |
PARTS |
IMAGE REFER TO PARTS IMAGE Price: Call Us PARTS IMAGE |
| 117 |
494870 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 121 |
498260 |
CARBURETOR KIT Price: Call Us |
| 124 |
94840 |
SCREW Price: Call Us |
| 125 |
498170 |
CARBURETOR Price: Call Us |
| 127 |
PARTS |
IMAGE REFER TO PARTS IMAGE Price: Call Us PARTS IMAGE |
| 130 |
224908 |
VALVE, THROTTLE Price: Call Us |
| 131 |
493267 |
SHAFT, THROTTLE Price: Call Us |
| 133 |
398187 |
FLOAT, CARBURETOR Price: Call Us |
| 134 |
398188 |
VALVE, INLET Price: Call Us |
| 137 |
PARTS |
IMAGE REFER TO PARTS IMAGE Price: Call Us PARTS IMAGE |
| 163 |
272653 |
GASKET AIR CLEANER Price: Call Us |
| 187 |
298049 |
LINE, FUEL Price: Call Us |
| 188 |
398540 |
SCREW, HEX HEAD Price: Call Us |
| 188A |
94644 |
SCREW, HEX HEAD Price: Call Us |
| 202 |
262579 |
LINK, GOVERNOR Price: Call Us |
| 209 |
263044 |
SPRING, GOVERNOR Price: Call Us |
| 227 |
492349 |
LEVER, GOVERNOR Price: Call Us |
| 230 |
67072 |
WASHER, THRUST Price: Call Us |
| 258 |
94512 |
SCREW, HEX HEAD Price: Call Us |
| 284 |
94511 |
SCREW, HEX HEAD Price: Call Us |
| 300 |
497838 |
MUFFLER, EXHAUST Price: Call Us |
| 304 |
493293 |
HOUSING, BLOWER Price: Call Us |
| 305 |
94744 |
SCREW, SEMS Price: Call Us |
| 306 |
224324 |
SHIELD, CYLINDER Price: Call Us |
| 307 |
94515 |
SCREW HEX HD Price: Call Us |
| 332 |
94877 |
NUT, FLYWHEEL Price: Call Us |
| 333 |
802574 |
ARMATURE, MAGNETO Price: Call Us |
| 334 |
94731 |
SCREW, SEMS Price: Call Us |
| 337 |
802592 |
PLUG, SPARK Price: Call Us |
| 356 |
497833 |
WIRE GROUND Price: Call Us |
| 358 |
497316 |
GASKET SET Price: Call Us |
| 363 |
19069 |
PULLEY, FLYWHEEL Price: Call Us |
| 383 |
89838 |
WRENCH SPARK PLUG Price: Call Us |
| 387 |
496115 |
PRIMER, CARBURETOR Price: Call Us |
| 447 |
95013 |
SCREW, HEX Price: Call Us |
| 455 |
225121 |
CUP, STARTER Price: Call Us |
| 456 |
281503 |
RETAINER, STARTER Price: Call Us |
| 459 |
281505 |
PAWL, RATCHET Price: Call Us |
| 461 |
94943 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 515 |
263073 |
SPRING, RETAINER Price: Call Us |
| 523 |
495264 |
CAP W/DIPSTICK, OIL FILTER Price: Call Us |
| 524 |
280393 |
SEAL, FILLER TUBE Price: Call Us |
| 525 |
495265 |
TUBE, OIL FILLER Price: Call Us |
| 529 |
281299 |
GROMMET, BREATHER Price: Call Us |
| 562 |
94852 |
BOLT, GOVERNOR LEVER Price: Call Us |
| 572 |
224328 |
BAFFLE, CYLINDER Price: Call Us |
| 592 |
231082 |
NUT, HEX Price: Call Us |
| 601 |
93053 |
CLAMP, HOSE, GREEN Price: Call Us |
| 605 |
225103 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 606 |
224815 |
STRAP, BRKT Price: Call Us |
| 608 |
497680 |
STARTER, REWIND Price: Call Us |
| 608 |
94908 |
NUT, HEX Price: Call Us |
| 613 |
94231 |
SCREW, HEX HEAD Price: Call Us |
| 615 |
94474 |
FASTENER Price: Call Us |
| 616 |
263175 |
CRANK, GOVERNOR Price: Call Us |
| 617 |
270344 |
SEAL, FUEL INTAKE TUBE Price: Call Us |
| 620 |
497203 |
BRACKET, CARBURETOR Price: Call Us |
| 621 |
396847 |
SWITCH, STOP Price: Call Us |
| 625 |
497465 |
TUBE, FUEL INTAKE Price: Call Us |
| 634 |
PARTS |
IMAGE REFER TO PARTS IMAGE Price: Call Us PARTS IMAGE |
| 635 |
66538 |
ELBOW, SPARK PLUG Price: Call Us |
| 670 |
280512 |
SPACER, FUEL TANK Price: Call Us |
| 670A |
493823 |
SPACER, BRACKET Price: Call Us |
| 741 |
262598 |
GEAR, TIMING Price: Call Us |
| 842 |
280966 |
SEAL, O-RING Price: Call Us |
| 843 |
272616 |
SLEEVE, LEVER Price: Call Us |
| 847 |
495263 |
TUBE ASSEMBLY, OIL Price: Call Us |
| 851 |
493880 |
TERMINAL, IGNITION CABLE Price: Call Us |
| 869 |
213512 |
SEAT, INTAKE VALVE Price: Call Us |
| 870 |
213513 |
SEAT, EXHAUST VALVE Price: Call Us |
| 871 |
262001 |
GUIDE, EXHAUST VALVE Price: Call Us |
| 871 |
63709 |
GUIDE, INTAKE VALVE Price: Call Us |
| 922 |
262640 |
SPRING, BRAKE Price: Call Us |
| 923 |
493442 |
BRAKE ASSEMBLY Price: Call Us |
| 925 |
281145 |
COVER, LINKAGE Price: Call Us |
| 930 |
281136 |
GUARD FINGER Price: Call Us |
| 957 |
397974 |
CAP, FUEL TANK Price: Call Us |
| 966 |
496116 |
BASE AIR CLEANER Price: Call Us |
| 967 |
491588 |
SUB= 3364 Price: Call Us |
| 968 |
281340 |
COVER AIR CLEANER Price: Call Us |
| 969 |
94872 |
SCREW Price: Call Us |
| 971 |
94873 |
SCREW Price: Call Us |
| 971A |
94749 |
SCREW, HEX HEAD Price: Call Us |
| 972 |
495224 |
TANK ASSY FUEL Price: Call Us |
| 975 |
493640 |
BOWL, FLOAT Price: Call Us |
| 977 |
498261 |
CARBURETOR GASKET SET Price: Call Us |
| 1036 |
499341 |
LABEL KIT, EMISSION Price: Call Us |
| 1095 |
498258 |
GASKET SET, VALVE OVERHAUL Price: Call Us |
| 2500 |
12J802-2916 |
ENGINE Price: Call Us |
| 498827 |
SHORTBLOCK |
Price: Call Us 498827 |
