Trowel Plate Assembly
Parts (16)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 121-8052-03 | BEAM-HITCH Price: $136.83 |
| 2 | 121-8056-03 | MOUNT-GROOMER Price: $186.23 |
| 3 | 283-57 | PIN-CLEVIS Price: $1.15 |
| 4 | 302-59 | PLUG-THREADED Price: $5.86 |
| 5 | 127-0369 | BUSHING Price: $6.53 |
| 6 | 127-0360 | SPACER Price: $30.77 |
| 7 | 328-5 | SCREW-HH Price: $3.60 |
| 8 | 3296-51 | NUT-LOCK, NI Price: $3.23 |
| 9 | 116-6639 | PIN-COTTER, LOCKING Price: $0.89 |
| 10 | 125-6488-03 | BRACKET-GROOMER, UPPER Price: $38.08 |
| 11 | 3234-4 | SCREW-HHF Price: $0.50 |
| 12 | 104-7201 | NUT-HF Price: $0.69 |
| 13 | 3229-2 | SCREW-CARR Price: $2.89 |
| 14 | 612503 | SPACER Price: $3.49 |
| 15 | 130-1874 | TROWEL-.50 THK Price: $191.02 |
| 16 | 125-6489-03 | BRACKET-GROOMER, LOWER Price: $35.35 |
