| Ref | Part Number | Description |
|---|
| 1 |
32128-39 |
NUT-HHF Price: $0.70 |
| 1 |
539107433 |
DECK W/DECALS 52" HUS WSL Price: $3,149.99 |
| 2 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 3 |
104-1051-03 |
PLATE-SPINDLE Price: $59.54 |
| 3 |
539104421 |
PULLEY 52" DECK Price: $60.99 |
| 4 |
138-1227 |
DECK CHAMBER ASM Price: $1,421.40 |
| 4 |
539100341 |
BLADE OEM 18" Price: $19.99 |
| 5 |
237-161 |
O-RING Price: $6.06 |
| 5 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 6 |
121-3666 |
SPINDLE ASM This part replaces 138-6932. Price: $391.32 |
| 6 |
539102643 |
ANTI-SCALP ROLLER Price: $8.99 |
| 7 |
539102698 |
BUSHING Price: $29.99 |
| 8 |
108-7395-03 |
BLADE-COMBO, 22IN Price: $29.99 |
| 8 |
114-0434-03 |
BLADE-HIGH LIFT, 22IN Price: $40.07 |
| 8 |
114-0435-03 |
BLADE-ATOMIC, 22IN Price: $40.07 |
| 8 |
117-0209-03 |
BLADE-ANGLE SAIL, 22IN Price: $38.49 |
| 8 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 9 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 9 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 10 |
510201201 |
BELT, DECK IZ/MIDMAX ONLY This part replaces 539106884. Price: $89.99 |
| 10 |
92-5816 |
BOLT-BLADE Price: $4.93 |
| 11 |
108-7409-01 |
BAFFLE-MULCHING Price: $123.78 |
| 11 |
539102754 |
HCS 3/8C X 3 1/2 Price: $3.99 |
| 12 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 13 |
539107312 |
DISCHARGE CHUTE ORANGE Price: $349.99 |
| 14 |
539106448 |
BELT SHIELD Price: $59.99 |
| 15 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 16 |
539101995 |
KEY 1/4 SQ X 1 1/8 Price: $2.99 |
| 17 |
594722002 |
LIFT This part replaces 539102641. Price: $4.99 |
| 18 |
539105192 |
DECK SPRING Price: $13.99 |
| 19 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 20 |
539103258 |
IDLER PULLEY (TALL) Price: $44.99 |
| 21 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 22 |
596577901 |
Nuts This part replaces 539102582. Price: $2.99 |
| 23 |
539102612 |
SCREW 3/8C X 2 3/4 HEX CAP Price: $4.99 |
| 24 |
539990839 |
NUT 7/16C CENTERLOCK Price: $2.99 |
| 25 |
539103299 |
HCS 5/8F X 1 1/4 Price: $5.99 |
| 26 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 27 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 28 |
539100141 |
HCS 7/16F X 1 1/2 Price: $7.99 |
| 29 |
539106449 |
BELT SHIELD Price: $50.99 |
| 30 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 32 |
596770301 |
Washers This part replaces 539103303. Price: $4.99 |
| 33 |
539105453 |
CENTER BAFFLE - 52" Price: $54.99 |
| 34 |
539105457 |
MAIN BAFFLE 52" Price: $219.99 |
| 35 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 36 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 37 |
594944601 |
Bolts This part replaces 539101175. Price: $2.99 |
| 38 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 39 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 41 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 42 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 43 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 44 |
539103230 |
IDLER ARM Price: $159.99 |
| 45 |
539103427 |
PIVOT BUSHING Price: $7.99 |
| 46 |
596437501 |
Washers This part replaces 539102243. Price: $8.99 |
| 47 |
539107411 |
HOUSING ASSEMBLY Price: $349.99 |
| 48 |
539104402 |
SPINDLE Price: $64.99 |
| 49 |
539107272 |
COMBO SPACER Price: $2.99 |
| 50 |
539102244 |
BUSHING.MACHINE.18.GAUGE Price: $4.99 |
| 51 |
539115279 |
BEARING-ECC LOCK W/COLLAR This part replaces 539102677. Price: $30.99 |
| 52 |
539102676 |
SPACER Price: $8.99 |
| 53 |
539104852 |
HOUSING, DIE CAST Price: $64.99 |
