| Ref | Part Number | Description |
|---|
| 1 |
32128-23 |
NUT-HF Price: $1.51 |
| 1 |
532140064 |
SPRING-MOWER CLUTCH Price: $14.99 |
| 2 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 3 |
32153-5 |
NUT-HEX Price: $1.59 |
| 3 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 4 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 4 |
531165101 |
SERVICE KIT BRAKE ASSEMBLY BRA This part replaces 532130840. Price: $6.99 |
| 5 |
47-3800-01 |
STRAP-LOCKING This part replaces 47-3800. Price: $156.60 |
| 5 |
532131251 |
IDLER BELT GUIDE Price: $3.99 |
| 6 |
325-14 |
SCREW-HH Price: $2.64 |
| 6 |
532121316 |
PULLEY.IDLER.FLAT.MOWER.BLK.PT Price: $44.99 |
| 7 |
32128-20 |
NUT-HF Price: $0.99 |
| 7 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 8 |
47-3480-03 |
SMV BRKT This part replaces 47-3480. Price: $36.01 |
| 8 |
596134901 |
GSPH This part replaces 819131410. Price: $2.99 |
| 9 |
38--6200 |
Socket-Slow Moving Veh. Price: Call Us |
| 9 |
532140092 |
IDLER ARM ASSY This part replaces 532127744. Price: $8.78 |
| 10 |
3230-1 |
BOLT-CARR This part replaces 3230-20. Price: $1.49 |
| 10 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 11 |
3-2196-01 |
SHEAVE This part replaces 3-2196. Price: $141.72 |
| 11 |
532130841 |
BRAKE ROD Price: $24.99 |
| 12 |
3-0136-01 |
CHAIN KEEPER ASM This part replaces 3-0136. Price: $51.92 |
| 12 |
532127356 |
BRKT LIFT REAR Price: $3.99 |
| 13 |
325-18 |
SCREW-HH Price: $3.19 |
| 13 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 14 |
20-4390 |
SPACER Price: $12.54 |
| 14 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 15 |
47-3990 |
DECAL Price: $19.68 |
| 15 |
532127357 |
BRKT LIFT REAR LH Price: $4.99 |
| 16 |
115-4947-01 |
HYDRAULIC CYLINDER ASM (10.69 STROKE) This part replaces 22-7520. Price: $880.23 |
| 16 |
532153298 |
BELT KEEPER This part replaces 532140093. Price: $11.99 |
| 17 |
322-3 |
SCREW-HH Price: $0.79 |
| 17 |
532128508 |
MOWER LINK STABILIZER Price: $41.84 |
| 18 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 18 |
532128511 |
PIN GROOVE Price: $2.99 |
| 19 |
37-2760-01 |
PIN-LIFT, BAIL This part replaces 37-2760. Price: $89.10 |
| 19 |
532127380 |
BRKT LINK STABILIIZER Price: $7.99 |
| 20 |
532140101 |
BLADE.36".MULCH Price: $19.99 |
| 20 |
8-1280-01 |
REAR CROSS CHANNEL ASM This part replaces 8-1280. Price: $998.35 |
| 21 |
3296-50 |
NUT-LOCK, NI Price: $2.68 |
| 21 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 22 |
47-3840 |
ELBOW-ORIFICE (.094) Price: $37.03 |
| 22 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 23 |
49-8170 |
SPACER Price: $27.34 |
| 23 |
532850857 |
BLADE BOLT Price: $3.99 |
| 24 |
3290-216 |
WASHER Price: $3.83 |
| 24 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532140329. Price: $6.99 |
| 25 |
3234-22 |
SCREW-HHF Price: $2.69 |
| 25 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $3.99 |
| 26 |
325-6 |
SCREW-HH Price: $1.42 |
| 26 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 27 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 27 |
532174082 |
DECK SVCX1 KIT MOWER.36.LR This part replaces 532129983. Price: $119.99 |
| 28 |
3-0144 |
SHAFT Price: $53.89 |
| 28 |
532173434 |
MANDREL PULLEY This part replaces 532129207. Price: $14.99 |
| 29 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $7.99 |
| 29 |
65-2710 |
PLATE-INFORMATION Price: $19.40 |
| 30 |
3290-274 |
RIVET-POP Price: $0.25 |
| 30 |
532136631 |
BRACKET ASM DEFLECTOR Price: $9.99 |
| 31 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 32 |
532122051 |
SUPT,IDLER ARM Price: $4.99 |
| 33 |
532175029 |
SHIELD.DEFL.MWR.36" This part replaces 532131560. Price: $24.99 |
| 34 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532130758. Price: $5.99 |
| 35 |
596987401 |
Nuts This part replaces 532125004. Price: $2.99 |
| 36 |
593885101 |
Rods This part replaces 532121980. Price: $5.99 |
| 37 |
532123713 |
SPRING TORSION Price: $6.99 |
| 38 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 40 |
532110452 |
NUT PUSH M Price: $2.99 |
| 41 |
532131264 |
BELT Price: $34.99 |
| 42 |
596040101 |
Washers This part replaces 819171616. Price: $2.99 |
| 43 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 44 |
532140608 |
KEEPER LH Price: $22.99 |
| 45 |
532110485 |
BEARING Price: $11.99 |
| 46 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 47 |
532129895 |
BEARING.BALL.#6204.(MANDREL) Price: $9.99 |
| 48 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 49 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 55 |
810071000 |
LOCKWASHER #10 Price: $3.99 |
| 56 |
596039001 |
Screws This part replaces 871161010. Price: $2.99 |
| 57 |
596580801 |
Bolts This part replaces 874930516. Price: $2.99 |
| 58 |
596040501 |
Hardware This part replaces 532063124. Price: $2.99 |
| 59 |
532133841 |
ACORN NUT Price: $2.99 |
| 60 |
532140102 |
MULCH.COVER.36" Price: $46.99 |
| 61 |
819061216 |
WASHER Price: $3.99 |
| 532130794 |
KIT.MANDREL.ASM.3.BOLT |
Price: $49.99 532130794 |
| 532156866 |
DECK |
ASM SVCX 36" HI PERF This part replaces 532140979. Price: $599.99 532156866 |
