| Ref | Part Number | Description |
|---|
| 1 |
112-5969 |
LIFT SHAFT ASM Price: $37.24 |
| 2 |
112-0650 |
NUT-LOCK, FLANGE Price: $3.42 |
| 3 |
112-0668 |
NUT-LOCK, FLANGE Price: $3.38 |
| 4 |
112-0459 |
DISCONTINUED Price: Call Us |
| 5 |
112-0568 |
PIN-COTTER Price: $3.63 |
| 6 |
112-0586 |
RING-E Price: $3.63 |
| 7 |
112-0585 |
DISCONTINUED Price: Call Us |
| 8 |
112-0477 |
SPRING-TORSION Price: $3.63 |
| 9 |
112-0443 |
BOLT-SHOULDER Price: $5.65 |
| 10 |
110-9889 |
SWITCH-SEAT Price: $38.12 |
| 11 |
112-0669 |
BOLT-SHOULDER Price: $4.34 |
| 12 |
112-0347 |
BEARING-FLANGE Price: $8.02 |
| 13 |
112-0374 |
CABLE-LIFT Price: $19.12 |
| 14 |
112-5970 |
DISCONTINUED Price: Call Us |
| 15 |
112-0502 |
PULLEY-ROLLER Price: $5.96 |
| 16 |
119-8471 |
ARM-LIFT, RH This part replaces 112-6259. Price: $20.50 |
| 17 |
119-8472 |
ARM-LIFT, LH This part replaces 112-6260. Price: $20.50 |
| 18 |
112-0373 |
SCREW-HH Price: $3.50 |
| 19 |
112-0524 |
SCREW-HWHTF Price: $3.48 |
| 20 |
112-6070 |
SCREW-TAP Price: $3.24 |
| 21 |
112-0509 |
SCREW-TAP Price: $5.11 |
| 22 |
112-6226 |
COVER-LIFT, LEVER Price: $22.52 |
| 23 |
112-6261 |
COVER-SHAFT (W/CUP HOLDER) Price: $31.61 |
| 25 |
112-0582 |
WASHER-FLAT Price: $3.52 |
| 26 |
112-6292 |
FENDER WITH DECAL Price: $338.44 |
| 27 |
112-0629 |
BRACKET-ADJUSTING, LIFT Price: $24.27 |
| 29 |
112-0409 |
KNOB Price: $5.04 |
| 32 |
112-0575 |
BOLT-SHOULDER Price: $3.52 |
| 35 |
112-6214 |
BRACKET-MOUNT, SEAT Price: $61.65 |
| 36 |
112-0549 |
CLIP-RATCHET, FASTENER Price: $3.50 |
| 37 |
112-0540 |
PAD-FOOT, RH Price: $23.37 |
| 38 |
112-0545 |
PAD-FOOT, LH Price: $23.47 |
| 39 |
112-6231 |
SEAT Price: $225.65 |
| 40 |
112-6216 |
BRACKET-KNOB, ADJUSTMENT Price: $4.67 |
| 41 |
112-0511 |
NUT-LOCK, FLANGE Price: $3.38 |
| 42 |
112-6217 |
BRACKET-PIVOT, SEAT Price: $14.85 |
| 43 |
112-3733 |
SPACER Price: $3.52 |
| 44 |
112-3732 |
GROMMET Price: $9.09 |
