Mower Frame Assembly
Parts (56)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 67-4360 | PULLEY Price: $42.99 |
| 2 | 67-4410 | V-BELT Price: $29.31 |
| 3 | 67-2330 | BOLT Price: $2.25 |
| 4 | 67-4400 | BOLT Price: $3.16 |
| 5 | 67-2600 | BOLT Price: $2.41 |
| 6 | 67-4380 | WATER PUMP Price: $508.44 |
| 7 | 67-4390 | GASKET Price: $5.58 |
| 8 | 67-4350 | OIL PRESSURE SWITCH ASM Price: $49.17 |
| 9 | 67-2610 | BOLT Price: $3.64 |
| 506505401 | 506505401 | SPACER Price: $3.99 |
| 506532701 | 506532701 | PULLEY Price: $39.99 |
| 506558302 | 506558302 | BOLT Price: $3.99 |
| 506563801 | 506563801 | ROLLER Price: $29.99 |
| 506597401 | 506597401 | BOLT Price: $5.99 |
| 506679101 | 506679101 | LIFT LEVER ASSY Price: $140.91 |
| 506679102 | 506679102 | Lever Lift Assy Price: $92.74 |
| 506755401 | 506755401 | Price: $164.53 |
| 506760701 | 506760701 | Price: Call Us |
| 506770701 | 506770701 | Price: $51.58 |
| 506790001 | 506790001 | WIRE,CPL Price: $21.05 |
| 506823401 | 506823401 | PAWL Price: $20.10 |
| 506837501 | 506837501 | Price: $12.65 |
| 506837601 | 506837601 | SPRING Price: $27.99 |
| 506837701 | 506837701 | SCREW Price: $8.99 |
| 506837801 | 506837801 | SUPPORT WHEEL Price: $54.99 |
| 506837901 | 506837901 | BUSHING Price: $8.99 |
| 506841101 | 506841101 | Price: $7.80 |
| 506841102 | 506841102 | SPRING Price: $5.99 |
| 506870101 | 506870101 | Price: $6.62 |
| 506871701 | 506871701 | Price: $59.60 |
| 506871702 | 506871702 | Price: $61.36 |
| 506872601 | 506966802 | FRAME This part replaces 506872601. Price: $400.66 |
| 506873101 | 506966801 | FRAME This part replaces 506873101. Price: $268.87 |
| 506873201 | 506873201 | Rail Price: $36.11 |
| 506874101 | 506874101 | SPACER Price: $4.49 |
| 506889701 | 506889701 | SPACER Price: $5.25 |
| 506895801 | 506895801 | BOLT Price: $6.99 |
| 725238251 | 725238251 | SCREW Price: $3.99 |
| 725245351 | 725245371 | SCREW This part replaces 725245351. Price: $4.99 |
| 725245751 | 725245751 | SCREW Price: $4.99 |
| 725645101 | 725645101 | SCREW Price: $2.99 |
| 731211601 | 731211601 | Price: Call Us |
| 731231801 | 731231801 | NUT Price: $3.99 |
| 731232051 | 731232001 | Nut This part replaces 731232051. Price: $3.99 |
| 732211801 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 732212201 | 732212201 | Price: $2.67 |
| 734116401 | 734116401 | WASHER BRB 8.4X17 Price: $5.99 |
| 734116441 | 734116441 | SPACER Price: $3.99 |
| 734117201 | 596134901 | GSPH This part replaces 734117201. Price: $2.99 |
| 734117701 | 734117701 | Price: Call Us |
| 734118201 | 734118201 | WASHER Price: $4.99 |
| 735311020 | 735311020 | C-WASHER Price: $2.99 |
| 735311220 | 735311220 | RETAINING RING Price: $2.99 |
| 735311700 | 735311700 | RETAINING RING SGA 15 Price: $2.99 |
| 735313810 | 735313810 | RETAINING RING Price: $2.99 |
| 738210401 | 738210401 | Price: Call Us |
