| Ref | Part Number | Description |
|---|
| 1 |
120-6272 |
HYD MOTOR ASM This part replaces 98-9999. Price: $846.73 |
| 1 |
132779 |
CHOKE CONTROL Price: Call Us |
| 2 |
19131316 |
WASHER Price: Call Us |
| 2 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 3 |
104-0067 |
HYD HOSE ASM Price: $166.60 |
| 3 |
11050600 |
LOCKWASHER Price: Call Us |
| 4 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 4 |
73610600 |
SUB= 7810H Price: Call Us |
| 5 |
132773 |
SUB= 133439 Price: Call Us |
| 5 |
94-4918 |
TUBE ASM Price: $90.86 |
| 6 |
104-0058 |
HYD HOSE ASM Price: $119.67 |
| 6 |
17720410 |
SCREW LT Price: Call Us |
| 7 |
422707 |
ENGINE B&S 18HP Price: Call Us |
| 8 |
100-3714 |
DRAIN TUBE ASM Price: $94.53 |
| 8 |
13280336 |
PIPE NIPPLE LT Price: Call Us |
| 9 |
104-0068 |
HYD HOSE ASM Price: $208.45 |
| 9 |
13200300 |
ELBOW Price: Call Us |
| 10 |
2751R |
CLIP T Price: Call Us |
| 10 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 11 |
108373X |
MUFFLER HYT Price: Call Us |
| 11 |
340-70 |
NUT-LOCK Price: $2.10 |
| 12 |
100229L |
EXHAUST TUBE T Price: Call Us |
| 12 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 13 |
69-8930 |
WASHER Price: $0.81 |
| 13 |
8545J |
SUB= 272250 Price: Call Us |
| 14 |
240-5 |
GROMMET Price: $13.66 |
| 14 |
74780412 |
SUB= 74780414 Price: Call Us |
| 15 |
10040400 |
LOCKWASHER Price: Call Us |
| 15 |
69-8960 |
SPACER Price: $5.29 |
| 16 |
104-0057 |
HYD HOSE ASM Price: $174.49 |
| 16 |
17490624 |
SCREW LT Price: Call Us |
| 17 |
73510600 |
NUT Price: Call Us |
| 17 |
93-9151 |
FITTING-HYD Price: $40.90 |
| 18 |
11050600 |
LOCKWASHER Price: Call Us |
| 18 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 19 |
123190X |
SHIELD HEAT FRT Price: Call Us |
| 20 |
104-0028 |
GUIDE-HOSE Price: $46.21 |
| 20 |
74760612 |
SUB= 74780612 Price: Call Us |
| 21 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 21 |
73680600 |
SUB= 73690600 Price: Call Us |
| 22 |
104-0094 |
TUBE ASM Price: $101.62 |
| 22 |
109740X |
REAR BAFFLE T Price: Call Us |
| 23 |
104-0092 |
TUBE ASM Price: $67.18 |
| 24 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 25 |
132922 |
SPARK ARREST KIT Price: Call Us |
| 26 |
127813 |
SUB= 141291 Price: Call Us |
| 26 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 27 |
100-3713 |
FITTING-HYD, 90 DEG Price: $63.97 |
| 27 |
123487X |
HOSE CLAMP Price: Call Us |
| 28 |
104-0063 |
HYD HOSE ASM Price: $99.52 |
| 28 |
136360 |
STRAP ASM. F.TANK Price: Call Us |
| 29 |
104-0069 |
HYD HOSE ASM Price: $164.25 |
| 29 |
123549X |
SUB= 158990 Price: Call Us |
| 30 |
104-0064 |
HYD HOSE ASM Price: $107.98 |
| 31 |
105-4011-03 |
WEIGHT-END This part replaces 94-4347-03. Price: $80.71 |
| 31 |
17490608 |
SCREW LT Price: Call Us |
| 32 |
93-9783 |
O-RING Price: $2.30 |
| 33 |
5277J |
SUB= 8543R Price: Call Us |
| 33 |
93-8717 |
PLUG-PIPE Price: $7.50 |
| 34 |
108-6716 |
GAUGE-BAR This part replaces 98-1851. Price: $93.45 |
| 35 |
123650X |
STUD.1/4.TURN Price: Call Us |
| 35 |
32122-54 |
SCREW-HEAD, TRUSS Price: $2.51 |
| 36 |
133746 |
HEAT SHIELD Price: Call Us |
| 36 |
32103-3 |
NUT-WING Price: $1.22 |
| 37 |
105838X |
RETAINER LT Price: Call Us |
