| Ref | Part Number | Description |
|---|
| 1 |
3290-384 |
PIN-LYNCH Price: $18.43 |
| 1 |
532424073 |
SEAT.TH153.PMGRY.ARMRST.HUSQVA Price: $449.99 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 2 |
94-5830 |
SUSPENSION W A This part replaces 54-0800. Price: $934.90 |
| 3 |
323-9 |
SCREW-HH Price: $1.29 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 4 |
62-6980 |
SHIM-CARRIER Price: $10.00 |
| 5 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 6 |
3235-21 |
SCREW W/PATCH Price: $6.42 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
74-0340 |
CUSHION-RUBBER Price: $4.39 |
| 9 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 10 |
325-19 |
SCREW-HH Price: $2.57 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 11 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 12 |
62-5580 |
BEARING-OUTSIDE Price: $6.58 |
| 13 |
68-8980 |
SPANNER-TIRE Price: $8.72 |
| 14 |
3217-6 |
NUT-HEX Price: $1.19 |
| 15 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 16 |
68-8930 |
MALE WHEEL HALF Price: $14.99 |
| 17 |
62-5570 |
BEARING-ROLLER Price: $18.63 |
| 18 |
68-8950 |
TUBE-INNER (W/VALVE) Price: $26.99 |
| 19 |
68-8960 |
TIRE Price: $63.99 |
| 20 |
68-8920 |
FEMALE WHEEL HALF Price: $14.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 21 |
68-8940 |
HUB-CENTER Price: $29.99 |
| 22 |
54-8890 |
WHEEL BOLT Price: $0.47 |
| 23 |
302-61 |
FITTING-GREASE Price: $10.99 |
| 24 |
32153-5 |
NUT-HEX Price: $1.59 |
| 25 |
68-8900-01 |
FRONT CASTOR FORK ASM This part replaces 68-8900. Price: $108.04 |
| 26 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 27 |
94-1291 |
BUSHING This part replaces 28-9290. Price: $10.99 |
| 28 |
74-0940 |
DECAL-HOC, RH Price: Call Us |
| 29 |
68-8360 |
DECAL-HOC, LH Price: $21.99 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 40 |
595088102 |
Handles This part replaces 532425919. Price: $4.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
