| Ref | Part Number | Description |
|---|
| 1 |
04265400 |
BLADE, MOWER 14.83 (.188 THK) Price: $21.95 |
| 2 |
06445700 |
WSHR-BLVL .669X1.535X.138 Price: $4.45 |
| 3 |
06500920 |
NUT-STD .625-18 ZCC This part replaces 06500630. Price: $1.95 |
| 4 |
07056800 |
BLT-SHLDR .38-16X2.50 HWH G5 Price: $6.45 |
| 5 |
06500822 |
NUT-LK-TOP-FLG .38-16 ZC120 This part replaces 06542000. Price: $0.95 |
| 6 |
03905600 |
ANTI-SCALP WHEEL - 5X OS Price: $14.95 |
| 7 |
06700220 |
PIN, BOWTIE .091X1.875 ZCC This part replaces 06700201. Price: $2.45 |
| 8 |
04073053 |
BRKT-DISCHARGE CHUTE MOUNT 42" Price: $25.45 |
| 9 |
04375900 |
CHUTE, DISCHARGE - MOLDED Price: $78.95 |
| 10 |
08300515 |
SPRING-TORSION Price: $30.95 |
| 11 |
00475800 |
PIN, 5/16 X 5.80" Price: $8.45 |
| 12 |
06700222 |
PIN, HAIR #213 .08X1.19 ZCC This part replaces 06713500. Price: $0.45 |
| 13 |
03977400 |
WMT-DISCHARGE CHUTE MT. STRAP Price: Call Us |
| 14 |
03902200 |
BELT COVER - LH 42" Price: $25.45 |
| 15 |
03902100 |
BELT COVER - RH 42" Price: $24.45 |
| 16 |
07400122 |
SCR-TAP .25-20X.50 HWH ZCC This part replaces 07400034. Price: $0.45 |
| 17 |
07400131 |
SCR,TAP .25-20X.75 HWH TR ZCC This part replaces 07414200. Price: $0.95 |
| 18 |
03957853 |
BAFFLE, REAR (42) Price: $47.95 |
| 19 |
04395453 |
WLDMT-BAFFLE, DISCHARGE 42" Price: $56.45 |
| 20 |
06500904 |
NUT-LK-TOP-FLG .312-18 GF ZCC This part replaces 06543100. Price: $0.95 |
| 21 |
05901904 |
BLT, HEX .31-18X.50 GR5 ZCC This part replaces 05947200. Price: $1.45 |
| 22 |
06200309 |
BLT, RHSSN.31-18X.750 G5 ZCC This part replaces 06220800. Price: $2.45 |
| 23 |
04377600 |
WIREFORM- DRAG LINK This part replaces 04377667. Price: $21.45 |
| 24 |
04424900 |
STRAP- DRAG LINK This part replaces 04424951. Price: $17.95 |
| 25 |
04847351 |
GUARD, 42" ZOOM/ZT CE BELT Price: $16.95 |
| 26 |
07400104 |
SCR-TAP .25-20X.50 LGHWH TR YZ Price: Call Us |
