| Ref | Part Number | Description |
|---|
| 1 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 2 |
123583X |
Key Price: Call Us |
| 2 |
69-5510 |
HOSE ASM Price: $77.25 |
| 3 |
323-6 |
SCREW-HH Price: $0.66 |
| 4 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 5 |
71-2590 |
SHAFT-PIVOT Price: $228.41 |
| 6 |
69-7960-01 |
SUPPORT-AXLE Price: $461.54 |
| 7 |
98-1452 |
WASHER-THRUST Price: $0.94 |
| 8 |
100-3364-01 |
REAR AXLE ASM Price: $951.06 |
| 10 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 11 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 12 |
100-3362 |
CAP-SPINDLE Price: $44.10 |
| 13 |
100-4196 |
RING-RETAINING Price: $1.90 |
| 15 |
19131316 |
Washer 13/32 x 13/16 x 16 Ga. Price: Call Us |
| 16 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 17 |
100-3358-03 |
SPINDLE-WHEEL, LH Price: $781.90 |
| 17 |
100-3359-03 |
SPINDLE-WHEEL, RH Price: $781.90 |
| 17 |
197296 |
Spring, Brake Price: Call Us |
| 18 |
106-6895-03 |
BALL JOINT ASM Price: $258.08 |
| 19 |
23-7270 |
NUT-LUG Price: $10.37 |
| 20 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 21 |
100-3769 |
PROTECTOR-BEARING Price: $41.94 |
| 22 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
| 23 |
3220-7 |
NUT-JAM Price: $4.09 |
| 24 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 25 |
69-9870 |
WIDE WHEEL AND 6-PLY TIRE ASM Price: $513.71 |
| 26 |
199679 |
Spring Return Cruise Price: Call Us |
| 26 |
254-92 |
CONE-BEARING, OUTER Price: $15.84 |
| 27 |
117-8969 |
HUB ASM This part replaces 69-2960-03. Price: $336.24 |
| 28 |
254-106 |
CONE-BEARING, TAPERED Price: $19.51 |
| 29 |
408391 |
Rod, Brake Price: Call Us |
| 29 |
69-2980 |
SEAL Price: $33.94 |
| 30 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 31 |
132-1308 |
HYD CYLINDER ASM This part replaces 98-0661. Price: $813.52 |
| 32 |
32136-13 |
NUT-SHH Price: $2.85 |
| 33 |
100-6116 |
SCREW-HHF Price: $6.41 |
| 33 |
12000001 |
Ring E Price: Call Us |
| 34 |
32128-23 |
NUT-HF Price: $1.51 |
| 35 |
197722 |
Rod, Brake, Park Price: Call Us |
| 35 |
3290-216 |
WASHER Price: $3.83 |
| 36 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 37 |
110-6143-01 |
TIE ROD ASM This part replaces 3-3710-01. Price: $513.93 |
| 37 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 38 |
340-70 |
NUT-LOCK Price: $2.10 |
| 39 |
95-6487-03 |
BRACKET-HOSE Price: $87.30 |
| 40 |
69-6010 |
TUBE-HYD Price: $162.05 |
| 41 |
69-6020 |
TUBE-HYD Price: $138.98 |
| 42 |
100-3809 |
CAP-PROTECTOR, BEARING Price: $6.39 |
| 42 |
8883R |
Cover, Foot Pedal Price: Call Us |
| 43 |
32152-5 |
NUT-HEX Price: $0.54 |
| 44 |
3210-7 |
SCREW-HH Price: $0.61 |
| 49 |
72110614 |
Bolt Price: Call Us |
| 50 |
194327 |
Pulley Idler Flat Price: Call Us |
| 51 |
73900600 |
Lock Nut 3/8-16 Price: Call Us |
| 52 |
194326 |
Idler V-Groove 910" Offset Price: Call Us |
| 56 |
125907 |
V-Belt, Drive Price: Call Us |
| 64 |
197865 |
Shaft Asm. Pedal Brake Control Price: Call Us |
| 73 |
74490544 |
Bolt 5/16-18 Gr. 5 Price: Call Us |
| 80 |
408393 |
Strap Torque Price: Call Us |
| 92 |
74760520 |
Bolt Fin Hex 5/16-18 unc x 1.25 Price: Call Us |
| 99 |
408418 |
Rod Asm Bypass Spring Price: Call Us |
| 114 |
73800500 |
Nut Lock 5/16-18 unc Price: Call Us |
| 116 |
73900500 |
Nut Lock Hex Flange 5/16-18 Price: Call Us |
| 121 |
175611 |
Bracket Strap Torque Price: Call Us |
| 122 |
72010520 |
Bolt 5/16-18 x 2.50 Price: Call Us |
| 125 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 153 |
4497H |
Retainer Spring Price: Call Us |
| 159 |
76020412 |
Pin Cotter 1/8 x 3/4 Price: Call Us |
| 160 |
169484 |
Retainer Clip Price: Call Us |
| 161 |
105709X |
Spring, Return, Clutch Price: Call Us |
| 162 |
408784 |
Adapter Transaxle Price: Call Us |
| 163 |
413322 |
Rod Pedal Control Price: Call Us |
| 166 |
197290 |
Nut Push .625 Price: Call Us |
| 167 |
405257 |
Latch Brake Parking Price: Call Us |
| 170 |
413430 |
Keeper Belt Centerspan Price: Call Us |
| 171 |
72110622 |
Bolt Price: Call Us |
| 183 |
156972 |
Spacer Axle Price: Call Us |
| 184 |
198403X505 |
Handle Parking Brake Price: Call Us |
| 185 |
72110620 |
Bolt Price: Call Us |
| 186 |
194321 |
Spacer Retainer Price: Call Us |
| 187 |
19133210 |
Washer Price: Call Us |
| 188 |
194323 |
Link Clutch Ground Drive Price: Call Us |
| 189 |
194317 |
Bellcrank Ground Drive Price: Call Us |
| 190 |
194318 |
Keeper Bellcrank Ground Drive Price: Call Us |
| 205 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 206 |
197867 |
Bracket Mount Latch Cruise Price: Call Us |
| 207 |
197868 |
Latch Control Cruise Price: Call Us |
| 208 |
197869 |
Gear Sector Control Cruise Price: Call Us |
| 209 |
400769 |
Rod Control Cruise Price: Call Us |
| 210 |
400980 |
Rockr Asm. Pdeal Control Price: Call Us |
| 211 |
120183X |
Bearing Nylon Price: Call Us |
| 213 |
400799 |
X428 Knob control Cruise Price: Call Us 400799 X428 |
| 214 |
197302 |
X428 Pad Pedal Forward Price: Call Us 197302 X428 |
| 215 |
197301 |
X428 Pad Pedal Reverse Price: Call Us 197301 X428 |
| 221 |
403187 |
Retainer Spring Clip Handle Price: Call Us |
| 222 |
79212010 |
Washer 21/32 x 1-1/4 10 Ga. Price: Call Us |
