| Ref | Part Number | Description |
|---|
| 1 |
22-330 |
Plug Price: Call Us |
| 2 |
237-42 |
O-RING Price: $2.78 |
| 3 |
22-8340 |
SPRING Price: $19.09 |
| 3 |
532007563 |
WASHER T Price: $6.99 |
| 4 |
22-8350 |
BALL Price: $12.28 |
| 4 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 5 |
22-8370 |
SEAT-VALVE Price: $88.05 |
| 5 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 6 |
22-8360 |
PIN Price: $43.02 |
| 6 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 7 |
532634692 |
HUB.ASSEMBLY.WHEEL.REAR This part replaces 532149176. Price: $42.99 |
| 8 |
22-8420 |
SPOOL Price: $437.22 |
| 8 |
812000034 |
Klip, Ring Price: $2.99 |
| 9 |
596218701 |
Bolts This part replaces 532140080. Price: $2.99 |
| 10 |
22-8380 |
RETAINER Price: $17.86 |
| 10 |
532142509 |
DISC BRAKE Price: $17.99 |
| 11 |
22-8410 |
SPRING Price: $17.61 |
| 11 |
532136927 |
YOKE-BRAKE DISC Price: $9.99 |
| 12 |
22-8390 |
RETAINER Price: $56.56 |
| 13 |
22-8400 |
SPACER Price: $42.41 |
| 13 |
532139419 |
WASHER Price: $4.99 |
| 14 |
22-8480 |
RING-SNAP Price: $49.87 |
| 14 |
532138901 |
BUSHING Price: $4.99 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
532143012 |
SET SCREW Price: $2.99 |
| 17 |
532126909 |
SPRING,ROD BRAKE Price: $4.99 |
| 18 |
532137104 |
BRAKE LEVER Price: $5.99 |
| 19 |
532136926 |
BRAKE DISC CAM Price: $11.99 |
| 21 |
823260412 |
Screw, Flat Head 1/4-28 x 3/4 Price: $3.99 |
| 22 |
532194121 |
LEVER.ASM.SHIFT Price: $64.99 |
| 23 |
532106932 |
KNOB T (3/8 HOLE) Price: $6.99 |
| 24 |
532136925 |
BRAKE PUCK SUPPORT Price: $3.99 |
| 25 |
532136923 |
BRAKE PUCK TOP Price: $14.99 |
| 26 |
532137552 |
RETURN SPRING Price: $4.99 |
| 27 |
874880528 |
Bolt Hex Gr. 8 5/16-18 unc x 1-3/4 Price: Call Us |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
532137213 |
ROD BRAKE ZINC GT Price: $20.99 |
| 30 |
596140201 |
Washers This part replaces 819131616. Price: $2.99 |
| 34 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 35 |
532137648 |
PARKING BRAKE ROD Price: $9.99 |
| 36 |
532149412 |
SPRING DRIVE GROUND Price: $4.99 |
| 37 |
532121749 |
WASHER Price: $2.99 |
| 38 |
532150035 |
NYLINER Price: $3.99 |
| 39 |
874321016 |
Screw, Fin. #10-24 x 1 Price: $2.99 |
| 40 |
532178575 |
ACTUATOR INTERLOCK SWITCH Price: $3.99 |
| 41 |
873931000 |
Nut, Centerlock #10-24 Price: $4.99 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 46 |
532145170 |
RETAINER SPRING Price: $3.99 |
| 47 |
532138228 |
CLUTCH ROD Price: $6.99 |
| 48 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 50 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 51 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 52 |
532139123 |
PULLEY.IDLER.V. Price: $32.99 |
| 54 |
532161590 |
CLUTCH.ARM.ASM.IDLER.98 Price: $18.99 |
| 55 |
532105706 |
BEARING LT (2 2) Price: $5.99 |
| 56 |
532137153 |
V-BELT GROUND DRIVE Price: $59.99 |
| 57 |
532141756 |
BRACKET SHIFT ROD Price: $3.99 |
| 59 |
532122253 |
ROD SHIFT HI LO Price: $14.99 |
| 60 |
532122268 |
CONNECTING LINK Price: $4.99 |
| 61 |
532184787 |
PULLEY.TRANSAXLE Price: $59.99 |
| 62 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 63 |
874780720 |
BOLT, HEX Price: $5.99 |
| 64 |
532154752 |
SHAFT CLUTCH/BRAKE PEDAL Price: $39.99 |
| 65 |
532179613 |
BOLT.SHLDR.3/8-16 Price: $4.99 |
| 66 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 67 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 68 |
532005142 |
ROLL PIN STD Price: $3.99 |
| 69 |
532136327 |
COVER.HUB.BLACK Price: $4.99 |
| 117 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 155 |
812000028 |
RETAINING RING LT Price: $1.99 |
| 156 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
