| Ref | Part Number | Description |
|---|
| 1 |
127-6472 |
DECK ASM This part replaces 108-9907. Price: $3,946.90 |
| 2 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 2 |
122018X |
BRKT CLUTCH Price: Call Us |
| 3 |
74780408 |
BOLT Price: Call Us |
| 4 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 4 |
73680600 |
SUB= 73690600 Price: Call Us |
| 5 |
132552 |
CLUTCH LEVER AS Price: Call Us |
| 6 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 7 |
135110 |
MWR CLUT ARM ASM Price: Call Us |
| 7 |
325-18 |
SCREW-HH Price: $3.19 |
| 8 |
74930624 |
BOLT Price: Call Us |
| 9 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 10 |
76020412 |
COTTER PIN Price: Call Us |
| 11 |
140-5847 |
PULLEY-IDLER This part replaces 01-268-0160. Price: $98.46 |
| 12 |
132929 |
LIFT LEVER HANDLE Price: Call Us |
| 13 |
132558 |
SUB= 136662 Price: Call Us |
| 13 |
68-6710 |
ROLLER Price: $59.98 |
| 14 |
133939 |
COMP CLUTCH SPRNG Price: Call Us |
| 14 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 104-3532. Price: $589.65 |
| 15 |
108-1993 |
SCREW-HSBH Price: $3.66 |
| 15 |
19131616 |
WASHER HYT Price: Call Us |
| 16 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 17 |
68-6840 |
SHAFT-ROLLER Price: $64.07 |
| 18 |
107-4767 |
PULLEY Price: $234.90 |
| 18 |
135107 |
TRUNNION Price: Call Us |
| 19 |
108-1924 |
SPACER-IDLER Price: $11.13 |
| 19 |
73680400 |
SUB= 73690400 Price: Call Us |
| 20 |
140-7079 |
IDLER ARM ASM This part replaces 110-3564. Price: $49.85 |
| 20 |
74760644 |
BOLT Price: Call Us |
| 21 |
110-9595 |
BELT-V Price: $64.81 |
| 22 |
132561 |
LIFT LEVER BRKT Price: Call Us |
| 23 |
132-9421 |
PULLEY-IDLER, FLAT This part replaces 110-9596. Price: $41.10 |
| 23 |
76020312 |
SUB= 3145 Price: Call Us |
| 24 |
139-1038 |
HIGH DRIVEN SPINDLE ASM This part replaces 104-3531. Price: $691.39 |
| 24 |
7672J |
WASHER Price: Call Us |
| 25 |
121933X |
TUBE SPACER Price: Call Us |
| 25 |
139-1037 |
DOUBLE DRIVEN SPINDLE ASM This part replaces 104-3530. Price: $724.15 |
| 26 |
108-1926 |
WASHER Price: $5.30 |
| 27 |
106932X |
KNOB T(3/8 HOLE) Price: Call Us |
| 27 |
108-1921 |
SPRING-TORSION Price: $28.33 |
| 28 |
140-7078 |
IDLER ARM ASM This part replaces 108-1930. Price: $49.85 |
| 29 |
32120-84 |
RING-SNAP, EXTERNAL Price: $0.61 |
| 30 |
135039 |
ROD TENSION CLUTC Price: Call Us |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 31 |
110-9594 |
BELT-V Price: $76.64 |
| 31 |
73930600 |
LOCKNUT Price: Call Us |
| 32 |
133435 |
SPRING EXT Price: Call Us |
| 32 |
3296-45 |
NUT-HEX Price: $3.79 |
| 34 |
29-4820 |
ROLLER Price: $14.88 |
| 34 |
73680500 |
SUB= 73690500 Price: Call Us |
| 35 |
133603 |
VINYL CAP RED Price: Call Us |
| 35 |
325-14 |
SCREW-HH Price: $2.64 |
| 36 |
3218-5 |
NUT-JAM Price: $0.27 |
| 36 |
72140506 |
BOLT Price: Call Us |
| 39 |
9136144 |
SCREW-HWHTF Price: $6.29 |
