| Ref | Part Number | Description |
|---|
| 1 |
256-268 |
BUSHING Price: $18.24 |
| 1 |
503200216 |
SCREW Price: $3.99 |
| 2 |
106-9682 |
LIMIT SWITCH TUBE ASM This part replaces 86-9030. Price: $104.04 |
| 3 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 3 |
590324602 |
Caps This part replaces 544076902. Price: $14.99 |
| 4 |
537184901 |
O-RING Price: $3.99 |
| 4 |
80-8270 |
BRACKET-SPEED ADJUST Price: $30.18 |
| 5 |
581756133 |
FUEL HOSE This part replaces 544324933. Price: $5.99 |
| 5 |
80-7870 |
SPRING-EXTENSION Price: $17.55 |
| 6 |
3296-45 |
NUT-HEX Price: $3.79 |
| 6 |
537184901 |
O-RING Price: $3.99 |
| 7 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 7 |
591375401 |
KIT FUEL FILTER This part replaces 503443201. Price: $8.99 |
| 8 |
503230011 |
WASHER 5.3X12 Price: $2.99 |
| 8 |
80-7970 |
TUBE-RETURN Price: $9.85 |
| 9 |
503200216 |
SCREW Price: $3.99 |
| 9 |
80-7960 |
BRACKET-SPRING Price: $14.27 |
| 10 |
93-9367 |
DECAL-WARNING Price: $9.80 |
| 11 |
14-5219 |
LIFT ACTUATOR ASM Price: $1,542.81 |
| 11 |
503221012 |
NUT Price: $2.99 |
| 12 |
537219901 |
HOLDER Price: $5.99 |
| 12 |
80-5140-03 |
LEVER-LIFT This part replaces 80-5140. Price: $163.29 |
| 13 |
32121-66 |
PIN-ROLL Price: $0.68 |
| 13 |
586444901 |
SCREW This part replaces 503217116. Price: $2.99 |
| 14 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 14 |
510208701 |
ANTIVIBRATION ELEMENT Price: $9.99 |
| 15 |
325-22 |
SCREW-HH Price: $4.26 |
| 16 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
323-7 |
SCREW-HH Price: $0.65 |
| 18 |
3230-22 |
SCREW-CARR Price: $1.99 |
| 19 |
86-8690 |
SHAFT-LIFT Price: $394.68 |
| 20 |
111512 |
DISCONTINUED This part replaces 10-6830. Price: Call Us |
| 21 |
117-8251 |
HUB ASM This part replaces 80-6580. Price: $75.98 |
| 22 |
28-3680 |
TIRE Price: $118.18 |
| 23 |
217-60 |
RIM Price: $110.16 |
| 24 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 25 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 27 |
3220-7 |
NUT-JAM Price: $4.09 |
| 28 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 29 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 30 |
254-94 |
BEARING-CONE, TAPERED Price: $8.48 |
| 31 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 32 |
253-129 |
SEAL Price: $21.73 |
| 33 |
93-1663-01 |
ARM-LIFT, MASKED This part replaces 93-1663. Price: $350.82 |
| 34 |
80-5560 |
BUSHING ASM Price: $62.64 |
| 35 |
325-14 |
SCREW-HH Price: $2.64 |
| 36 |
72-4310 |
SWITCH-BALL Price: $84.47 |
