| Ref | Part Number | Description |
|---|
| 1 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 1 |
925-04514 |
BATTERY Not Available This part replaces 725-3174. Price: |
| 2 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 2 |
725-3197A |
POITIVE BATTERY CABLE Not Available This part replaces 725-3197. Price: |
| 3 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 3 |
725-3195 |
NEGATIVE BATTERY CABLE Not Available Price: |
| 4 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 4 |
710-3083 |
Screw, Hex Cap, 5/16-18 X 1.38 Lg Price: $3.94 |
| 5 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 5 |
736-0275 |
FLAT WASHER This part replaces 7360275. Price: $5.99 |
| 6 |
3258-19 |
SCREW Price: $0.42 |
| 6 |
703-1823-0716 |
BATTERY HOLD DOWN (CUB YELLOW-99) Not Available This part replaces 703-1823. Price: |
| 7 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 7 |
731-3105 |
TRAY, BATTERY Not Available Price: |
| 8 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 8 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 9 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 10 |
62-6300 |
SLEEVE ASM Price: $31.93 |
| 10 |
925-3001 |
Solenoid This part replaces 725-3001. Price: $54.39 |
| 11 |
33-1270 |
BOWL-CLEAR Price: $10.91 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 11 |
725-3206 |
CABLE-STAR Not Available Price: |
| 12 |
33-1260 |
COVER ASM Price: $36.59 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
759-3653 |
CAP-BATTERY VENT Not Available Price: |
| 13 |
736-3006 |
Washer, Int-Ext, 1/4 Price: $5.32 |
| 13 |
80-3330 |
GASKET Price: $18.48 |
| 14 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 14 |
729-0207 |
FUSE HOLDER Not Available Price: |
| 15 |
583507201 |
TANK.ASSY.XTERNAL.FILL.GT2.TEX This part replaces 532435816. Price: $129.99 |
| 15 |
925-1381 |
Fuse, 20 Amp This part replaces 725-1381. Price: $5.38 |
| 16 |
729-0209 |
CLIP-FUSE HLD MTG Not Available Price: |
| 17 |
710-0473 |
Screw, Truss Mach, #10-24 X .50 Lg Price: $3.90 |
| 18 |
532441462 |
CAP.ASM.FUEL.2.25"TOP.TURN Price: $11.99 |
| 18 |
925-1375 |
RELAY Not Available This part replaces 725-1375. Price: |
| 19 |
710-0473 |
Screw, Truss Mach, #10-24 X .50 Lg Price: $3.90 |
| 20 |
532424341 |
CONTROL.THROTTLE.PRO. Price: $34.99 |
| 20 |
929-3080 |
VOLTAGE SENSOR W/ADAPTER HARNESS Not Available This part replaces 725-3165. Price: |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
936-0147 |
EXTERNAL WASHER #10 Not Available This part replaces 736-0147. Price: |
| 22 |
532187768 |
CONTROL.CHOKE.ERGO.BLACK This part replaces 532189541. Price: $27.99 |
| 22 |
736-0722 |
Washer, Lock, #10 Price: $5.81 |
| 23 |
712-0121 |
Nut, Hex, #10-24 Price: $3.75 |
| 24 |
712-0291 |
Nut, Hex Center Lock, 1/4-20 Price: $3.93 |
| 25 |
710-0653 |
Screw, Hex Wash Hd Tapp, 1/4-20 X .38 Lg Price: $3.78 |
| 26 |
725-3213 |
MAIN HARNESS M18 KOHLER Not Available Price: |
| 27 |
725-3147 |
QUICK CONNECT LUG Not Available Price: |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532192442 |
GASKET.MUFF 806237 NOW 806425 Price: $12.99 |
| 70 |
532191548 |
EXHAUST.TUBE.MUFFLR.LH.VANG Price: $69.99 |
| 71 |
532191549 |
EXHAUST.TUBE.MUFFLR.RH.VANG Price: $39.99 |
| 79 |
532192443 |
SCREW.TUBE.MUFFLER.VANGUARD Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 137 |
532441461 |
SPILL.CUP Price: $7.99 |
