| Ref | Part Number | Description |
|---|
| 1 |
591117901 |
SERVICE KIT SVC.WELDMENT.42F This part replaces 582878202. Price: $899.99 |
| 2 |
539112170 |
MANDREL.DECK.ASSEMBLY Price: $69.99 |
| 3 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 5 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 6 |
586918102 |
BLADE.42.FCS.BAGGING.BLADE. This part replaces 586918101. Price: $27.99 |
| 7 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 8 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 9 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 10 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 12 |
587354701 |
SPRING.42.FCS.DEFLECTOR Price: $5.99 |
| 13 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 14 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 17 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 24 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 27 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 28 |
586874002 |
ARM.42"FCS.CLUTCHING.X431 Price: $17.99 |
| 29 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
| 30 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 34 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 40 |
589527301 |
WHEEL.GAUGE.RALLY Price: $8.99 |
| 41 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 42 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 43 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 44 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 46 |
587270101 |
BELT.42.FCS.TRACTOR.DECK.DRIVE Price: $44.99 |
| 47 |
595901601 |
GSPW Bolts This part replaces 539990316. Price: $2.99 |
| 51 |
532199791 |
PULLEY MANDREL 5.0" Price: $22.99 |
| 52 |
588438301 |
SCREW.7/16-14 X 2.125.WASHER Price: $5.99 |
| 53 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 55 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 56 |
587358401 |
SPRING.EXTN.42.FCS.TR.DECK.DRV Price: $6.99 |
| 57 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 61 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 65 |
532110452 |
NUT PUSH M Price: $2.99 |
| 66 |
587305701 |
DEFLECTOR.ASM.42.FCS.ORANGE Price: $69.99 |
| 67 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 68 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $7.99 |
| 69 |
586936805 |
COVER.42".MANDREL.FCS.PNT.498 Price: $7.99 |
| 75 |
582683201 |
BUMPER.42.CLEARCUT.TRIMSDE.ASM Price: $9.99 |
| 77 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 78 |
501808302 |
BRACKET.PNT.GA-WHEEL.FCS.42.RH Price: $19.99 |
| 81 |
582360501 |
BUSHING.NOSE.ROLLER Price: $3.99 |
| 84 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
