| Ref | Part Number | Description |
|---|
| 1 |
121472X |
Wheel, Steering (AYP part number) Price: Call Us |
| 1 |
5-1828 |
DISCONTINUED Price: Call Us |
| 2 |
137094 |
Axle Asm., Front (AYP part number) Price: Call Us |
| 2 |
5-1530 |
DISCONTINUED Price: Call Us |
| 3 |
32964 |
Nut Price: Call Us |
| 3 |
6855M |
Fitting, Grease Price: Call Us |
| 4 |
5-1932 |
DISCONTINUED Price: Call Us |
| 4 |
532161849 |
SPINDLE ASSY LH This part replaces 532136960. Price: $22.99 |
| 5 |
11-3600 |
DISCONTINUED Price: Call Us |
| 5 |
532161848 |
SPINDLE ASM RH This part replaces 532136959. Price: $22.99 |
| 6 |
5-3612 |
DISCONTINUED Price: Call Us |
| 6 |
6266H |
Bearing, Race Thrust Harden Price: Call Us |
| 7 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 7 |
3211-25 |
Screw Price: Call Us |
| 8 |
12000029 |
Ring, Klip #T5304-75 Price: Call Us |
| 8 |
5-1787 |
DISCONTINUED Price: Call Us |
| 9 |
121232X |
Cap, Spindle Price: Call Us |
| 9 |
5-1788 |
DISCONTINUED Price: Call Us |
| 10 |
242-14 |
DISCONTINUED Price: Call Us |
| 10 |
74781044 |
Bolt, Fin Hex 5/8-11 x 2-3/4 Price: Call Us |
| 11 |
154779 |
Bearing Axle STLT/GT Price: Call Us |
| 11 |
5-1994 |
DISCONTINUED Price: Call Us |
| 12 |
6-8730 |
Seat Price: Call Us |
| 12 |
73901000 |
Nut, Lock Flange 5/8-11 Unc Price: Call Us |
| 13 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 13 |
3-6885 |
DISCONTINUED Price: Call Us |
| 14 |
10040600 |
Washer, Lock Hvy Hlcl Spr 3/8 Price: Call Us |
| 14 |
32136-4 |
NUT-HEX,SLOTTED Price: $1.56 |
| 15 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 15 |
7810H |
Nut Lock Center 3/8-24 Unf Price: Call Us |
| 16 |
145103 |
Shaft Asm., Steering Price: Call Us |
| 16 |
3-4685 |
WASHER-TOP THRUST Price: $3.60 |
| 17 |
251-167 |
DISCONTINUED Price: Call Us |
| 18 |
137155 |
Draglink, Ball Joint Solid Vgt (AYP part number) Price: Call Us |
| 18 |
302-14 |
VENT Price: $8.03 |
| 19 |
156011 |
Support Asm., Steering Vgt Price: Call Us |
| 19 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 20 |
3-6886 |
DISCONTINUED Price: Call Us |
| 21 |
100711L |
Adapter, Wheel Steering Price: Call Us |
| 21 |
3220-6 |
NUT-JAM Price: $1.25 |
| 22 |
155105 |
Bushing, Strg. Price: Call Us |
| 22 |
329-8 |
DISCONTINUED Price: $14.39 |
| 23 |
152927 |
Screw Price: Call Us |
| 23 |
222-1 |
DISCONTINUED Price: Call Us |
| 24 |
19133808 |
Washer 13/32 x 2-3/8 x 8 Ga. Price: Call Us |
| 24 |
5-1830 |
DISCONTINUED Price: Call Us |
| 25 |
2-8569 |
DISCONTINUED Price: Call Us |
| 25 |
74780616 |
Bolt, Fin Hex 3/8-16 x 1 Gr. 5 Price: Call Us |
| 26 |
126805X |
Cap, Wheel Steering Price: Call Us |
| 26 |
3219-1 |
NUT-HEX Price: $0.47 |
| 27 |
289-4 |
DISCONTINUED Price: Call Us |
| 27 |
3366R |
Bearing, Col. Strg. Price: Call Us |
| 28 |
17490612 |
Screw Thdrol. 3/8-16 x 3/4 TY-TT Price: Call Us |
| 28 |
224-1 |
DISCONTINUED Price: Call Us |
| 29 |
104239X |
Bearing, Flange Price: Call Us |
| 29 |
304-73 |
FITTING-STRAIGHT Price: $12.59 |
| 30 |
107-9297 |
HOSE-FUEL This part replaces 6-1190. Price: $7.29 |
| 30 |
12000034 |
Ring, Klip Truarc #5304-75 Price: Call Us |
| 31 |
138136 |
Bushing, Nyliner Snap Price: Call Us |
| 31 |
5-1781 |
DISCONTINUED Price: Call Us |
| 32 |
19111610 |
Washer 11/32 x 1 x 10 Ga. Price: Call Us |
| 32 |
3220-5 |
NUT-JAM Price: $0.65 |
| 33 |
10040500 |
Washer, Lock Hvy Hlcl Spr 5/16 Price: Call Us |
| 33 |
3254-4 |
WASHER-LOCK/INT Price: $0.34 |
| 34 |
283-82 |
PIN-CLEVIS This part replaces 283-23. Price: $3.94 |
| 34 |
74760512 |
Bolt, Hex Hd 5/16-18 x 3/4 Price: Call Us |
| 35 |
138059 |
Gear, Sector Steering Price: Call Us |
| 35 |
3-4684 |
DISCONTINUED Price: Call Us |
| 36 |
137156 |
Tie Rod (AYP part number) Price: Call Us |
| 36 |
3-4683 |
DISCONTINUED Price: Call Us |
| 37 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 37 |
73360600 |
Jam Nut RH Thread Price: Call Us |
| 38 |
109850X |
Joint Asm. Ball RH Thread Price: Call Us |
| 38 |
5-1786 |
DISCONTINUED Price: Call Us |
| 39 |
3-5198 |
DISCONTINUED Price: Call Us |
| 39 |
73700600 |
Jam Nut LH Thread Price: Call Us |
| 40 |
109851X |
Joint Asm. Ball LH Thread Price: Call Us |
| 40 |
5-1785 |
DISCONTINUED Price: Call Us |
| 41 |
155246 |
Bracket Switch Inerlock VGT97 Price: Call Us |
| 41 |
5-1784 |
DISCONTINUED Price: Call Us |
| 42 |
17490508 |
Screw Thdrol 5/16-18 x 1/2 TYT Price: Call Us |
| 42 |
3-7761 |
DISCONTINUED Price: Call Us |
| 43 |
3211-5 |
SCREW-HH Price: $0.88 |
| 44 |
282-4 |
SHACKLE Price: $32.98 |
| 45 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 46 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 47 |
3219-3 |
NUT-HEX Price: $0.34 |
| 48 |
3211-13 |
DISCONTINUED Price: Call Us |
| 49 |
3-6750 |
DISCONTINUED Price: Call Us |
| 51 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 52 |
5-1748 |
DISCONTINUED Price: Call Us |
| 53 |
5-1783 |
DISCONTINUED Price: Call Us |
| 54 |
252-6 |
BEARING-NEEDLE Price: $10.72 |
| 55 |
5-1782 |
DISCONTINUED Price: Call Us |
| 57 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 58 |
5-1738 |
DISCONTINUED Price: Call Us |
| 59 |
5-1791 |
DISCONTINUED Price: Call Us |
| 60 |
3211-4 |
SCREW-HH Price: $1.02 |
| 61 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 62 |
5-1801 |
DISCONTINUED Price: Call Us |
