TRANSMISSION
Parts (71)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 131-1235 | RIGHT DECK ASM Price: $2,726.27 |
| 2 | 112-1479 | SKID-BUMPER, DECK Price: $95.09 |
| 3 | 3296-45 | NUT-HEX Price: $3.79 |
| 4 | 131-1231-01 | PLATE-STIFFENER Price: $95.51 |
| 5 | 3296-56 | NUT-LOCK, NI Price: $2.09 |
| 6 | 132-9421 | PULLEY-IDLER, FLAT Price: $41.10 |
| 7 | 100-3102 | WASHER-FLAT Price: $3.70 |
| 8 | 108-8076 | V-BELT, DECK Price: $29.86 |
| 9 | 3234-42 | SCREW-HHF Price: $1.10 |
| 10 | 139-1039 | LOW DRIVEN SPINDLE ASM This part replaces 119-4776. Price: $589.65 |
| 11 | 32108-103 | SCREW-FH Price: $0.68 |
| 12 | 506986301 | HYDROSTAT 7A646024070 Price: $1,099.99 |
| 12 | 69-9290 | PAD-BUMPER Price: $9.52 |
| 13 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 13 | 506558302 | BOLT Price: $3.99 |
| 14 | 104-2250-01 | SKID-SIDE Price: $116.02 |
| 14 | 725246751 | Hex Bolt Price: $4.99 |
| 15 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 15 | 734116401 | WASHER BRB 8.4X17 Price: $5.99 |
| 16 | 131-1243 | PLATE-SPINDLE Price: $62.97 |
| 16 | 731231801 | NUT Price: $3.99 |
| 17 | 3256-3 | WASHER-FLAT Price: $0.49 |
| 17 | 506987201 | BRACKET Price: $19.99 |
| 18 | 3290-343 | PIN-HAIR Price: $0.76 |
| 18 | 725245951 | SCREW Price: $4.99 |
| 19 | 132-6150-01 | BRACKET-CASTER Price: $155.45 |
| 19 | 725246251 | SCREW Price: $4.99 |
| 20 | 100-5623 | DECAL-HOC Price: $20.17 |
| 20 | 506599301 | CONNECTOR Price: $5.99 |
| 21 | 120-5587 | PIN-CLEVIS Price: $10.38 |
| 21 | 731231801 | NUT Price: $3.99 |
| 22 | 104-7524 | SHIM Price: $5.30 |
| 22 | 506987403 | ARM Price: $12.99 |
| 23 | 132-6157-01 | BRACKET-FORK Price: $59.18 |
| 23 | 584288604 | Washers This part replaces 506918702. Price: $3.99 |
| 24 | 3231-33 | SCREW-CARR Price: $4.29 |
| 24 | 725245151 | SCREW 8X20 Price: $4.99 |
| 25 | 3233-2 | SCREW-CARR Price: $1.49 |
| 25 | 506987501 | ROD Price: $32.99 |
| 26 | 106-2047 | ROD-TENSION Price: $9.83 |
| 26 | 732211401 | LOCKNUT M5 Price: $2.99 |
| 27 | 3231-22 | SCREW-CARR Price: $0.72 |
| 28 | 104-0858 | BOLT-SHOULDER Price: $4.69 |
| 29 | 920242 | WASHER-FLAT This part replaces 9202424. Price: $5.19 |
| 30 | 3253-7 | WASHER-LOCK Price: $0.27 |
| 30 | 506988201 | Rod Price: $12.71 |
| 31 | 325-7 | SCREW-HH Price: $1.53 |
| 31 | 506834301 | SPRING Price: $3.99 |
| 32 | 32120-72 | RING-SNAP Price: $2.09 |
| 32 | 506988401 | TENSIONER Price: $54.99 |
| 33 | 3-6498 | WASHER-THRUST Price: $4.58 |
| 33 | 588740401 | BELT TENSIONER ARM This part replaces 506988501. Price: $14.99 |
| 34 | 110-6128 | IDLER ARM ASM Price: Call Us |
| 34 | 506946901 | PULLEY Price: $34.99 |
| 35 | 32128-14 | NUT-HF Price: $0.41 |
| 35 | 725245551 | SCREW Price: $3.99 |
| 36 | 68-0090 | SCREW-ADJUSTING Price: $7.49 |
| 37 | 139-1728 | BOLT-HH FT This part replaces 9114524. Price: $1.29 |
| 37 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 38 | 107938 | SPRING-EXTENSION Price: $9.99 |
| 38 | 584288604 | Washers This part replaces 506918702. Price: $3.99 |
| 39 | 32128-26 | NUT-FLANGE Price: $5.89 |
| 39 | 725245151 | SCREW 8X20 Price: $4.99 |
| 40 | 594924101 | Springs This part replaces 506988601. Price: $3.99 |
| 40 | 9136144 | SCREW-HWHTF Price: $6.29 |
| 41 | 70-1160 | WASHER Price: $3.59 |
| 41 | 725246451 | SCREW Price: $5.99 |
| 42 | 506988801 | SCREW Price: $4.96 |
| 43 | 731232001 | Nut This part replaces 731232051. Price: $3.99 |
| 44 | 506989001 | TANK Price: $24.99 |
| 45 | 590324701 | TANK CAP ASSY This part replaces 506988001. Price: $7.99 |
