| Ref | Part Number | Description |
|---|
| 1 |
419797X479 |
LOWER TUBE Price: Call Us |
| 1 |
924-3000 |
BRAKE & CLUTCH PEDAL PAD This part replaces 724-3004. Price: $17.21 |
| 1 |
93-6361 |
DISCONTINUED Price: Call Us |
| 2 |
418313X479 |
PIVOT SUPPORT Price: Call Us |
| 2 |
60-6220 |
SCREW-HH This part replaces 93-6362. Price: $5.33 |
| 2 |
703-0845A |
Pedal Assy, Brake Price: Call Us |
| 3 |
428867 |
BOLT 5/16-18 X .750 Price: Call Us |
| 3 |
703-1393 |
BRACKET, PARKING BRAKE Not Available Price: |
| 3 |
93-6363 |
WASHER Price: $3.02 |
| 4 |
920-3019 |
PARKING BRAKE GRIP Not Available This part replaces 720-3019. Price: |
| 4 |
95-2110 |
ADAPTOR Price: $1,026.64 |
| 5 |
736-3001 |
WAVE WASHER Not Available Price: |
| 5 |
93-6364 |
GEROTER-OUTER Price: $152.48 |
| 6 |
712-0324 |
Nut, Hex Insert Lock, 1/4-20 Price: $3.38 |
| 6 |
93-6365 |
GEROTER-INNER Price: $124.40 |
| 7 |
703-2280-0637 |
START SWITCH BRACKET (POWDER BLACK) Not Available This part replaces 703-2280. Price: |
| 7 |
94-9999 |
VALVE-RELIEF This part replaces 93-6366. Price: $768.40 |
| 8 |
710-0216 |
Bolt, 3/8 X 3/4 Type 5 This part replaces 710-3000. Price: $3.93 |
| 9 |
712-3005 |
Nut, Hex Flanged Lock, 3/8-16 GR5 Price: $5.99 |
| 9 |
93-6368 |
DISCONTINUED Price: Call Us |
| 10 |
748-3006 |
BRAKE LEVER ROD Not Available Price: |
| 11 |
932-3010 |
EXTENSION SPRING 7.32LG x .50 O.D. Not Available This part replaces 732-3010. Price: |
| 11 |
99-8704 |
PLATE-VALVE This part replaces 93-6370. Price: $457.47 |
| 12 |
703-0900 |
LEVER, BRAKE Not Available Price: |
| 13 |
747-3109A |
ROD, BRAKE LINK Not Available Price: |
| 13 |
93-6372 |
RING-QUAD Price: $5.92 |
| 14 |
703-1395 |
SHAFT ASSY, BRAKE Not Available Price: |
| 14 |
94-3037 |
RING-RETAINING This part replaces 93-6373. Price: $1.78 |
| 15 |
719-3013 |
Clevis, Adjustment Price: $24.95 |
| 15 |
94-3038 |
ACTUATOR-DUMP VALVE This part replaces 93-6374. Price: $159.36 |
| 16 |
711-3010 |
CLEVIS PIN Not Available Price: |
| 17 |
711-3130 |
BRAKE ROD Not Available Price: |
| 18 |
932-0260 |
Extension Spring .50" O.D. x 6.5" Lg. This part replaces 732-0260. Price: $18.25 |
| 21 |
703-1787 |
BRACKET-BRAKE MTG Not Available Price: |
