| Ref | Part Number | Description |
|---|
| 1 |
233-48 |
KNOB Price: $10.92 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 2 |
93-2400-03 |
LOCKUP HANDLE ASM This part replaces 93-2400. Price: $110.85 |
| 3 |
83-0760 |
SPACER-PLATE, LOCKUP Price: $8.77 |
| 4 |
83-0740 |
DISC-FRICTION Price: $12.57 |
| 5 |
68-5130 |
WHEEL-STEERING Price: $124.07 |
| 6 |
107-2561 |
NUT-HEX This part replaces 47-6990. Price: $14.65 |
| 7 |
3274-63 |
SCREW-HSBH Price: $1.09 |
| 8 |
83-0730 |
SPACER-LOCKUP Price: $11.78 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
93-2199 |
SCREW-HH, RH Price: $50.68 |
| 10 |
325-4 |
SCREW-HH Price: $0.95 |
| 11 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 12 |
47-2890 |
BUSHING Price: $3.19 |
| 12 |
586478501 |
ENGINE.PULLEY This part replaces 532405471. Price: $27.99 |
| 13 |
3274-39 |
SCREW-HSBH Price: $4.34 |
| 14 |
94-9628 |
DISCONTINUED Price: Call Us |
| 15 |
529999102 |
TANK ASSY W/CAP 3 GAL CARB This part replaces 532414151. Price: $329.99 |
| 15 |
83-1420 |
COLUMN-STEERING Price: $284.84 |
| 16 |
94-6366 |
COVER-VALVE, STEERING Price: $98.75 |
| 17 |
340-133 |
FITTING-STR Price: $35.33 |
| 18 |
323-4 |
SCREW-HH Price: $1.02 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 This part replaces 532430213. Price: $37.99 |
| 19 |
93-2115-01 |
STEERING ARM ASM This part replaces 93-2115. Price: $326.55 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 20 |
93-8068 |
DECAL-ARM, STEERING Price: $5.09 |
| 21 |
3274-80 |
SCREW-HH Price: $1.76 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 23 |
93-2120 |
DISCONTINUED Price: Call Us |
| 24 |
65-6390 |
WASHER-THRUST, PLAIN Price: $5.02 |
| 25 |
3290-277 |
NUT-SPEED Price: $0.61 |
| 26 |
93-8063 |
DECAL-CAUTION, CE Price: $18.92 |
| 27 |
68-5140 |
CAP-WHEEL, STEERING Price: $15.13 |
| 28 |
32144-21 |
SCREW Price: $0.20 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
237-79 |
O-RING Price: $5.46 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
93-2272 |
HYDRAULIC HOSE ASM Price: $95.00 |
| 31 |
93-2252 |
HOSE ASSY - HYD Price: $119.96 |
| 32 |
117-9471 |
KIT-SERVICE,GR3250-D STEERING This part replaces 93-2269. Price: $105.67 |
| 33 |
93-2270 |
HYD HOSE ASM Price: $91.88 |
| 34 |
93-2271 |
HYD HOSE ASM Price: $80.93 |
| 35 |
237-21 |
O-RING Price: $0.70 |
| 36 |
237-42 |
O-RING Price: $2.78 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 94 |
581880901 |
EXHAUST.TUBE.B&S.28/31 This part replaces 532405450. Price: $19.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
| 113 |
597791601 |
VALVES This part replaces 532414127. Price: $9.99 |
