| Ref | Part Number | Description |
|---|
| 1 |
131-1236 |
LEFT DECK ASM Price: $2,679.48 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
3296-45 |
NUT-HEX Price: $3.79 |
| 4 |
131-1233-01 |
PLATE-STIFFENER Price: $87.83 |
| 5 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 6 |
132-9421 |
PULLEY-IDLER, FLAT Price: $41.10 |
| 7 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 8 |
108-8076 |
V-BELT, DECK Price: $29.86 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 9 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 10 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 119-4776. Price: $589.65 |
| 11 |
32108-103 |
SCREW-FH Price: $0.68 |
| 12 |
69-9290 |
PAD-BUMPER Price: $9.52 |
| 13 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 14 |
104-2250-01 |
SKID-SIDE Price: $116.02 |
| 15 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 16 |
131-1244 |
PLATE-SPINDLE Price: $62.97 |
| 17 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 18 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 19 |
132-6150-01 |
BRACKET-CASTER Price: $155.45 |
| 20 |
104-3579 |
DECAL-HOC Price: $23.95 |
| 21 |
120-5587 |
PIN-CLEVIS Price: $10.38 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
104-7524 |
SHIM Price: $5.30 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
132-6157-01 |
BRACKET-FORK Price: $59.18 |
| 24 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $7.99 |
| 25 |
3233-2 |
SCREW-CARR Price: $1.49 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 This part replaces 532412895. Price: $7.99 |
| 26 |
106-2047 |
ROD-TENSION Price: $9.83 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
104-0858 |
BOLT-SHOULDER Price: $4.69 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 29 |
920242 |
WASHER-FLAT This part replaces 9202424. Price: $5.19 |
| 30 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
325-7 |
SCREW-HH Price: $1.53 |
| 32 |
32120-72 |
RING-SNAP Price: $2.09 |
| 33 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT This part replaces 532411933. Price: $8.99 |
| 34 |
110-6128 |
IDLER ARM ASM Price: Call Us |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 35 |
32128-14 |
NUT-HF Price: $0.41 |
| 36 |
68-0090 |
SCREW-ADJUSTING Price: $7.49 |
| 37 |
139-1728 |
BOLT-HH FT This part replaces 9114524. Price: $1.29 |
| 38 |
107938 |
SPRING-EXTENSION Price: $9.99 |
| 39 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 40 |
532402167 |
HARNESS IGN. DASH Price: $99.99 |
| 40 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 41 |
70-1160 |
WASHER Price: $3.59 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 45 |
529910801 |
AMMETER This part replaces 532425270. Price: $27.99 |
| 46 |
529910701 |
HOUR METER This part replaces 532425271. Price: $69.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 59 |
596941001 |
Outlets This part replaces 532400303. Price: $11.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 103 |
532421747 |
HARNESS.PIGTAIL.12V.OUTLET. Price: $12.99 |
| 141 |
532421225 |
KIT.G700/G730.ROS 71750 Price: $149.99 |
