COVER
Parts (21)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 125-2018 | HOUSING Price: $45.90 |
| 2 | 136-8002 | LIFT ARM #2 Price: $382.73 |
| 3 | 136-8003 | LIFT ARM #3 Price: $382.73 |
| 4 | 63-8410 | WASHER Price: $1.76 |
| 6 | 3234-11 | SCREW-HHF Price: $1.23 |
| 7 | 120-6283 | STUD-SHOULDERED Price: $3.32 |
| 9 | 125-2037 | SHAFT Price: $88.55 |
| 10 | 32144-14 | SCREW-HWHTF Price: $4.29 |
| 11 | 138-1248 | PIVOT YOKE ASM Price: $429.41 |
| 12 | 92-1298 | PIN-LYNCH Price: $2.27 |
| 13 | 76-2980 | WASHER-THRUST Price: $5.08 |
| 16 | 107-7400 | PIN-LYNCH Price: $9.56 |
| 17 | 107-4027 | CAP Price: $12.59 |
| 18 | 110-0922 | HOOP-CHAIN Price: $15.10 |
| 19 | 3296-29 | NUT-LOCK, NI Price: $2.09 |
| 20 | 323-7 | SCREW-HH Price: $0.65 |
| 21 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 22 | 84-2451 | CHAIN-STRAIGHT, 5 LINK Price: $9.25 |
| 23 | 99-5608-03 | SPRING-TORSION, RH Price: $35.46 |
| 24 | 99-5609-03 | SPRING-TORSION, LH Price: $35.46 |
| 25 | 110-5345 | WASHER Price: $2.29 |
