| Ref | Part Number | Description |
|---|
| 2 |
353-481 |
LIFT CHECK ASM Price: $338.44 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
237-54 |
O-RING Price: $1.97 |
| 4 |
353-306 |
WASHER-BACKUP Price: $9.12 |
| 5 |
353-305 |
O-RING Price: $10.91 |
| 7 |
353-302 |
O-RING Price: $10.13 |
| 8 |
353-303 |
WASHER-BACKUP Price: $9.06 |
| 10 |
353-853 |
BOLT Price: $39.87 |
| 11 |
353-668 |
PLATE-COVER Price: $508.66 |
| 13 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 14 |
353-848 |
O-RING Price: $0.89 |
| 15 |
353-957 |
CUP-SEAL Price: $16.26 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
353-958 |
WASHER Price: $13.57 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 18 |
92-2547 |
SEAL-RETAINER Price: $15.10 |
| 19 |
353-733 |
SPACER-BONNET Price: $41.01 |
| 20 |
353-417 |
COLLAR-STOP Price: $10.31 |
| 21 |
353-831 |
SPRING Price: $13.22 |
| 22 |
353-529 |
PLATE-RETAINER, SEAL Price: $15.07 |
| 23 |
92-3148 |
SPRING-TRACTION Price: $13.84 |
| 24 |
353-808 |
COLLAR-SPRING Price: $27.44 |
| 25 |
353-830 |
O-RING Price: $1.41 |
| 26 |
94-4248 |
COLLAR-SPOOL This part replaces 353-829. Price: $58.22 |
| 27 |
68-4240 |
BONNET ASSEMBLY This part replaces 354-26. Price: $42.76 |
| 28 |
354-28 |
SCREW-HS Price: $8.35 |
| 29 |
353-851 |
BODY-RELIEF Price: $180.95 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 30 |
353-392 |
RING-PISTON Price: $13.94 |
| 31 |
353-531 |
POPPET AND RING ASM Price: $229.51 |
| 32 |
353-328 |
SHIM (.040) Price: $3.53 |
| 33 |
353-329 |
SHIM (.020) Price: $2.10 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
353-330 |
SHIM (.010) Price: $3.60 |
| 35 |
353-398 |
SPRING Price: $30.09 |
| 35 |
596874801 |
Rods This part replaces 532401031. Price: $6.99 |
| 36 |
353-334 |
CAP-RELIEF Price: $55.48 |
| 37 |
52-5900 |
SCREW Price: $26.40 |
| 38 |
353-847 |
BONNET Price: $129.59 |
| 39 |
353-849 |
SLEEVE Price: $46.19 |
| 40 |
353-846 |
SPUD Price: $118.09 |
| 41 |
353-845 |
SLEEVE-DETENT Price: $79.50 |
| 42 |
353-730 |
SPRING Price: $18.22 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 43 |
353-731 |
BALL Price: $12.95 |
| 44 |
353-398 |
SPRING This part replaces 353-855. Price: $30.09 |
| 45 |
3274-52 |
SCREW-HSH Price: $3.19 |
| 46 |
353-575 |
BOOT Price: $58.68 |
| 47 |
93-3651 |
RETAINER-BOOT Price: $31.38 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
52-5860 |
COLLAR-SPOOL Price: $13.37 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
354-122 |
DISC-SEAL Price: $6.92 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 54 |
353-953 |
PLUG ASM Price: $182.79 |
| 55 |
353-844 |
PLUG Price: $75.53 |
| 56 |
353-850 |
O-RING Price: $1.17 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 57 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 58 |
3274-84 |
SCREW-HSH Price: $2.51 |
| 59 |
38-0410 |
NUT-HEX Price: $5.77 |
| 60 |
83-1890 |
SWITCH-BALL Price: $63.08 |
| 61 |
354-129 |
ANTICAVITATION CHECK ASM This part replaces 353-483. Price: $152.63 |
| 62 |
353-484 |
RETURN-BALL, CHECK Price: $139.05 |
| 63 |
353-737 |
BALL-CHECK Price: $14.19 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 64 |
92-2546 |
WIPER-SEAL Price: $4.56 |
| 73 |
596136501 |
Bolts This part replaces 874490540. Price: $3.99 |
| 99 |
532415742 |
ROD.SPRING.BYPASS.K46.LT.Z Price: $7.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532448275. Price: $22.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532411484 |
HANDLE.PARKNG BRK.PRED.LT.428 Price: $24.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX Price: $6.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 230 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 325 |
585668505 |
BRACKET TORQUE STRAP This part replaces 585668502. Price: $5.99 |
| 326 |
585670803 |
BRACKET TORQUE STRAP This part replaces 585670802. Price: $4.99 |
| 336 |
587259602 |
Bolts This part replaces 587259601. Price: $3.99 |
