| Ref | Part Number | Description |
|---|
| 1 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 1 |
539990071 |
HCS.1/4-20.X1/2 This part replaces 817720408. Price: $1.99 |
| 2 |
532132752 |
Control, Throttle This part replaces 532122014. Price: $17.99 |
| 2 |
58-5460 |
VALVE-SELECTOR Price: $479.05 |
| 3 |
340-22 |
FITTING-TEE Price: $90.38 |
| 3 |
532124136 |
Engine, Briggs and Stratton, Model Number 281707, Type Number 0412-01 Price: Call Us |
| 4 |
115-8017 |
REEL MOTOR KIT This part replaces 93-1412. Price: $1,999.51 |
| 4 |
532192334 |
Screw Socket Hd 5/16-18 x .75 This part replaces 871070512. Price: $2.99 |
| 5 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 5 |
810040500 |
Washer, Lock Heavy Helical Spring 5/16 Price: $2.99 |
| 6 |
532272293 |
Gasket Eng 1 313 Id Tin Plated This part replaces 532125593. Price: $7.99 |
| 7 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 7 |
532121094 |
Bolt, Shoulder 5/16 Price: $2.99 |
| 8 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 8 |
734115201 |
WASHER - M6 This part replaces 819101216. Price: $1.99 |
| 9 |
33014-00 |
NUT-HEX Price: $0.25 |
| 9 |
810040400 |
Washer, Lock Heavy Helical Spring 1/4 Price: $3.99 |
| 10 |
48-9530 |
NUT Price: $1.78 |
| 10 |
874780416 |
Bolt Hex Fin 1/4-20 unc x 1 Gr. 5 This part replaces 874780412. Price: $3.99 |
| 11 |
323-6 |
SCREW-HH Price: $0.66 |
| 11 |
532124097 |
Muffler Price: $58.82 |
| 12 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 12 |
532101326 |
Deflector, Muffler Price: $4.01 |
| 13 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 13 |
532161464 |
Screw Hex WSHD 8-18 x 7/8 This part replaces 817030808. Price: $3.99 |
| 14 |
340-93 |
TEE-ADAPTER Price: $57.05 |
| 14 |
873510600 |
Nut, Keps 3/8-16 UNC Price: $3.99 |
| 15 |
105-9271-01 |
BRACKET-BUMPER Price: $84.53 |
| 15 |
532121851 |
Kit, Spark Arrestor (optional) Price: $26.83 |
| 16 |
48-3280 |
STOP-BUMP Price: $35.14 |
| 16 |
539990118 |
WASHER.3/8 This part replaces 811050600. Price: $1.49 |
| 17 |
60-0090 |
PIN-PIVOT Price: $93.25 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $3.99 |
| 18 |
532126636 |
Keeper, Ground Drive Belt Price: $5.99 |
| 18 |
60-0190 |
STRIP Price: $36.98 |
| 19 |
33114-016 |
SCREW-HH Price: $0.27 |
| 19 |
817490632 |
Screw, Hex. Wsh Thdrol 3/8 - 16 x 2 Price: $2.99 |
| 20 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 20 |
532002751 |
Clip Line Fuel 13/32 Mtg Hole This part replaces 532124996. Price: $2.42 |
| 21 |
60-0100 |
PIN-PIVOT Price: $94.46 |
| 23 |
68-6480 |
BUSHING-FLANGE Price: $3.19 |
| 24 |
115-8048-01 |
NO. 4 LIFT ARM ASM This part replaces 92-9296-01. Price: $986.93 |
| 25 |
325-34 |
SCREW-HH Price: $2.37 |
| 26 |
58-4380 |
PIN Price: $25.11 |
| 27 |
60-1280 |
PIN Price: $3.53 |
| 28 |
60-1350 |
ROD-PUSH Price: $87.82 |
| 29 |
60-1640 |
STRIP Price: $26.76 |
| 30 |
324-6 |
SCREW-HH Price: $0.81 |
| 31 |
115-8049-01 |
NO. 5 LIFT ARM ASM This part replaces 92-9297-01. Price: $924.15 |
| 33 |
323-14 |
SCREW-HH Price: $1.34 |
| 34 |
115-8011 |
CYLINDER-HYD This part replaces 104-5225. Price: $784.12 |
| 35 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 37 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 39 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 40 |
58-2720 |
PIN Price: $49.81 |
| 41 |
115-8045-01 |
NO. 1 LIFT ARM ASM This part replaces 92-9289-01. Price: $977.54 |
| 42 |
58-9210 |
CAM Price: $92.20 |
| 43 |
60-0080 |
BUSHING Price: $14.79 |
| 44 |
53-5940 |
SCREW Price: $2.90 |
| 45 |
60-1340 |
ROD-PUSH Price: $85.25 |
| 46 |
58-3570 |
SPRING Price: $16.80 |
| 47 |
117-8981 |
BUSHING-RUBBER This part replaces 59-7140. Price: $13.27 |
| 48 |
58-9630 |
SLEEVE Price: $123.35 |
| 49 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 50 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 51 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 52 |
93-7331 |
DECAL-WARNING Price: $10.35 |
| 53 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 54 |
3217-6 |
NUT-HEX Price: $1.19 |
| 56 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 57 |
3256-26 |
WASHER-FLAT Price: $0.39 |
