| Ref | Part Number | Description |
|---|
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $22.99 |
| 1 |
82-2850 |
PLATE Price: $21.91 |
| 2 |
529845601 |
SERVICE KIT SHAFT ASM RH HANDL This part replaces 532159471. Price: $49.99 |
| 2 |
82-9680 |
RIVET Price: $0.98 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 3 |
82-9700 |
SCREW Price: $1.58 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 4 |
82-2730 |
WEAR PARTS KIT Price: $67.73 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 11 |
532145537 |
LIFT LINK LH This part replaces 532139865. Price: $22.99 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $22.99 |
| 12 |
82-2800 |
CUSHION-REST, BACK Price: $418.29 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 13 |
82-2840 |
CUSHION-BOTTOM Price: $555.71 |
| 14 |
82-2790 |
RAIL-ADJUST, LH Price: $212.20 |
| 15 |
532173288 |
LINK.SUSPENSION.FRONT Price: $11.99 |
| 15 |
82-9690 |
SCREW Price: $2.67 |
| 16 |
56-4030 |
DISCONTINUED This part replaces 82-9660. Price: Call Us |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 17 |
532175689 |
TRUNNION This part replaces 532130171. Price: $3.99 |
| 17 |
82-9650 |
NUT Price: $8.89 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 18 |
82-2820 |
SWING ARM ASM Price: $422.94 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 19 |
92-2951 |
RAIL-ADJUST, LH Price: $199.04 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 20 |
82-9710 |
TRIM-BOTTOM Price: $54.09 |
| 21 |
82-2720 |
FRAME-SEAT Price: $1,045.27 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 23 |
82-2810 |
SWITCH ASM Price: $336.01 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 30 |
82-9720 |
TRIM-REST, BACK Price: $39.95 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $5.99 |
| 31 |
82-2860 |
SPRING-SET, TENSION Price: $19.71 |
| 32 |
82-2750 |
DISCONTINUED Price: Call Us |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 35 |
82-2830 |
CLAMP Price: $13.33 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 36 |
82-2770 |
SHOCK ABSORBER ASM Price: $221.09 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 39 |
82-2760 |
BUSHING KIT Price: $9.67 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
532155098 |
IND. HEIGHT STLT Price: $4.99 |
| 41 |
82-2880 |
WEIGHT ADJ. ASM Price: $143.93 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
