| Ref | Part Number | Description |
|---|
| 1 |
532126470 |
CLIP,INSULATOR Price: $3.99 |
| 2 |
532122018 |
BRKT CLUTCH Price: $2.38 |
| 3 |
121-8447 |
CORE-CONDENSER Price: $919.47 |
| 3 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 4 |
121-8459 |
FAN-CONDENSER Price: $288.68 |
| 4 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 5 |
106-8489 |
BUSHING-SLEEVE Price: $3.40 |
| 5 |
532145187 |
CLUTCH LEVER Price: $5.69 |
| 6 |
125-9982 |
BUSHING-FLANGE Price: $1.76 |
| 6 |
532106451 |
BOLT, SHOULDER LT Price: $2.99 |
| 7 |
3256-57 |
WASHER-FLAT Price: $0.41 |
| 7 |
532135371 |
ASSEMBLY MOWER CLUTCH ARM Price: $7.93 |
| 8 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 8 |
874760636 |
BOLT Price: $4.99 |
| 9 |
1-807512 |
BOLT-CARR Price: $1.29 |
| 9 |
532121930 |
BELLCRANK,LIFT Price: $11.99 |
| 10 |
104-7201 |
NUT-HF Price: $0.69 |
| 10 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 11 |
121-8457 |
FILTER-AIR Price: $34.12 |
| 11 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 12 |
107069 |
CLIP Price: $1.79 |
| 12 |
532122027 |
GRIP HANDLE Price: $5.72 |
| 13 |
532139352 |
LIFT HANDLE ASSY Price: $15.88 |
| 13 |
98-8332 |
KNOB Price: $4.89 |
| 14 |
125-9825-03 |
COVER-AIR, FRESH Price: $80.77 |
| 14 |
532123496 |
SPRING COMPRESSIO Price: $2.99 |
| 15 |
3230-9 |
SCREW-CARR Price: $0.68 |
| 15 |
596134901 |
GSPH This part replaces 819131212. Price: $2.99 |
| 16 |
3230-22 |
SCREW-CARR Price: $1.99 |
| 16 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 17 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 17 |
532127359 |
LINK LIFT FRT Price: $19.99 |
| 18 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 18 |
532142028 |
TRUNNION.ADJUSTABLE.3/8-16 Price: $3.99 |
| 19 |
32115-15 |
PUSHNUT-RETAINER, BOLT This part replaces 106-8737. Price: $0.99 |
| 19 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873680400. Price: $3.99 |
| 20 |
130-5871 |
BRACKET-WIPER Price: $42.69 |
| 20 |
874760644 |
BOLT Price: $3.99 |
| 21 |
125-7452 |
WIPER MOTOR ASM Price: $435.07 |
| 22 |
125-7453 |
ARM-WIPER Price: $121.52 |
| 23 |
125-7454 |
BLADE-WIPER Price: $49.61 |
| 23 |
596029601 |
Pins This part replaces 876020416. Price: $1.99 |
| 24 |
125-9621-03 |
BRACKET-MOUNT, FAN Price: $19.17 |
| 24 |
596040101 |
Washers This part replaces 819171612. Price: $2.99 |
| 25 |
32105-15 |
SCREW-HWH Price: $1.79 |
| 25 |
532121933 |
TUBE SPACER Price: $4.28 |
| 26 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 26 |
532141470 |
LIFT ROD Price: $14.65 |
| 27 |
532106932 |
KNOB T (3/8 HOLE) Price: $6.99 |
| 28 |
130-5649 |
SEAL-FOAM, LONG Price: $10.65 |
| 28 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 29 |
130-5661 |
TUBE-SLEEVE Price: $37.14 |
| 29 |
532131655 |
LINK MOWER CLUTCH Price: $4.99 |
| 30 |
3229-30 |
SCREW-CARR Price: $1.39 |
| 30 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 31 |
130-5854 |
BRACE-SEAL Price: $4.07 |
| 32 |
130-5650 |
SEAL-FOAM, SHORT Price: $3.69 |
| 33 |
130-5931 |
SEAL-CONDENSER Price: $3.69 |
| 34 |
130-5647 |
GASKET-FOAM, CONDENSER Price: $21.44 |
