| Ref | Part Number | Description |
|---|
| 1 |
46-0330 |
NUT-LOCK Price: $0.60 |
| 1 |
532434487 |
DECK.SVC.WELDMNT.30"419272X418 This part replaces 532442048. Price: $219.99 |
| 2 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 2 |
74-6520 |
FLAT WASHER Price: $0.93 |
| 3 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 3 |
94-3162 |
STUD This part replaces 74-6530. Price: $30.04 |
| 4 |
532417645 |
BRACKET.CLUTCH.CABLE Price: $4.99 |
| 4 |
74-6540 |
TAPPET-VALVE Price: $41.87 |
| 5 |
74-6550 |
CUP Price: $4.84 |
| 5 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 6 |
532418863 |
ARMS.SUSP.MOWER.REAR.SRD Price: $17.99 |
| 6 |
74-6560 |
SPRING-VALVE Price: $14.26 |
| 7 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 7 |
74-6570 |
CUP-VALVE SPRING, LOWER Price: $3.36 |
| 8 |
583379801 |
ARM.IDLER.30"SRD This part replaces 532420252. Price: $7.99 |
| 8 |
74-6580 |
INSERT-VALVE (1.65MM) Price: $44.94 |
| 8 |
74-7220 |
INSERT-VALVE (3.925MM) Price: $11.14 |
| 9 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 9 |
74-7240 |
COLLAR-SPLIT Price: $5.39 |
| 10 |
74-7250 |
DISCONTINUED Price: Call Us |
| 10 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 11 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 11 |
74-7260 |
BOLT-HEAD Price: $17.07 |
| 12 |
532400130 |
BRAKE.ARM.LH.38"TEX.COATED This part replaces 532199470. Price: $14.99 |
| 12 |
74-7270 |
WASHER-FLAT Price: $3.60 |
| 13 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 13 |
74-7280 |
PLUG Price: $3.44 |
| 14 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 14 |
74-7840 |
PLUG Price: $2.02 |
| 15 |
2412-119 |
CLAMP-HOSE, WORM DRIVE Price: $1.83 |
| 15 |
593787801 |
PULLEYS This part replaces 532146763. Price: $27.99 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
3253-4 |
WASHER-LOCK This part replaces 68-9420. Price: $0.25 |
| 17 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 18 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 18 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 19 |
532110485 |
BEARING Price: $11.99 |
| 19 |
74-7340 |
DISCONTINUED Price: Call Us |
| 20 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 20 |
74-7350 |
HOSE Price: $41.96 |
| 21 |
532416910 |
KEEPER.BELT.MANDREL.30" Price: $12.99 |
| 21 |
74-7360 |
COLLECTOR TUBE Price: $117.45 |
| 22 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 23 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 23 |
599972501 |
BOLT This part replaces 817490628. Price: $2.99 |
| 24 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 24 |
74-7390 |
DISCONTINUED Price: Call Us |
| 25 |
529311701 |
KEEPER, BELT, BLACK This part replaces 532420253. Price: $4.99 |
| 25 |
74-7400 |
TUBE Price: $46.54 |
| 26 |
583481101 |
COVER.ASM.MANDREL.30" This part replaces 532420255. Price: $49.99 |
| 26 |
74-7410 |
PLUG Price: $6.57 |
| 27 |
532419271 |
V-BELT.DRIVE.MOWER.30" Price: $49.99 |
| 27 |
74-7420 |
BALL Price: $1.11 |
| 28 |
532417344 |
SHIELD.DEFLECT.MWR.30S.BLACK Price: $37.99 |
| 28 |
74-7430 |
CHAMBER-TURBULENCE Price: $119.14 |
| 29 |
593885101 |
Rods This part replaces 532420895. Price: $5.99 |
| 29 |
74-7450 |
DISCONTINUED Price: Call Us |
| 30 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 30 |
74-7480 |
VALVE-INTAKE Price: $55.79 |
| 31 |
532110452 |
NUT PUSH M Price: $2.99 |
| 31 |
74-7470 |
EXHAUST VALVE Price: $85.90 |
| 32 |
532401872 |
SPRING RETURN Price: $4.99 |
| 32 |
74-7490 |
INTAKE VALVE SEAT Price: $29.47 |
| 33 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 33 |
74-7510 |
DISCONTINUED Price: Call Us |
| 34 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 34 |
74-7530 |
SEE BUL #03-02 Price: Call Us |
| 35 |
532419273 |
BLADE, MULCH.LRV30 Price: $29.99 |
| 35 |
74-7550 |
SCREW - CAP HEX HD Price: $0.66 |
| 36 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 36 |
74-7560 |
LOCKWASHER Price: $0.67 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
77-3890 |
BRACKET - HOOD STOP *B Price: $40.20 |
| 38 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 38 |
74-7580 |
PLATE Price: $14.96 |
| 39 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 39 |
74-7590 |
DISCONTINUED Price: Call Us |
| 40 |
532419270 |
KEEPER.BELT.ENGINE.LH.LT.SRD Price: $14.99 |
| 40 |
74-7600 |
PLUG (BALL) Price: $6.93 |
| 41 |
532419265 |
KEEPER.BELT.ENGINE.RH.LT.SRD Price: $11.99 |
| 41 |
92-7797 |
CYLINDER HEAD KIT This part replaces 74-7610. Price: $4,804.68 |
| 42 |
74-7620 |
PLUG Price: $26.15 |
| 42 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 43 |
525568002 |
PULLEY.MANDREL 6.5" PULLEY This part replaces 532416877. Price: $24.99 |
| 43 |
74-7630 |
GASKET-COVER, VALVE Price: $30.06 |
| 44 |
74-7640 |
COVER-VALVE Price: $171.54 |
| 45 |
74-7650 |
WASHER-FLAT Price: $1.03 |
| 46 |
33113-025 |
SCREW-HH This part replaces 48-7640. Price: $1.97 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $32.99 |
| 76 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 78 |
583394901 |
GUARD.DECK.SRD.ARM.CLUTCH This part replaces 532422566. Price: $9.99 |
| 81 |
583419401 |
SHIELD.ASM.SUSP.FRENCH.30S/30R This part replaces 532425367. Price: $5.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. Price: $29.99 |
