| Ref | Part Number | Description |
|---|
| 1 |
108-3158 |
HOUSING-DRIVE, BELT Price: $521.42 |
| 1 |
530016173 |
Bolt-Handle Price: $1.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 2 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 2 |
530047919 |
Assist Handle Price: $2.92 |
| 2 |
631767 |
SPRING This part replaces 631279A. Price: $1.25 |
| 3 |
530091373 |
Nut This part replaces 530016118. Price: $1.99 |
| 3 |
631036 |
SHUTTER Price: $1.20 |
| 4 |
530016179 |
Screw Price: $1.99 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
530047924 |
Throttle Hsg. (Left) Price: $3.99 |
| 5 |
630766 |
SPRING Price: $1.25 |
| 6 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 6 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 7 |
530054159 |
Locator-Left Price: $4.99 |
| 7 |
630973 |
SHAFT & LEV Price: $5.16 |
| 8 |
530071416 |
Drive Shaft Hsg. Ass'y Price: $32.99 |
| 8 |
632045 |
SPRING Price: $1.25 |
| 8 |
65-9560 |
ADJUSTMENT KNOB ASM Price: $190.35 |
| 9 |
530047923 |
Throttle Hsg. (Right) Price: $6.99 |
| 9 |
631582 |
SHUTTER Price: $1.20 |
| 9 |
65-9550 |
CAP Price: $28.33 |
| 10 |
530038682 |
Trigger - Throttle Price: $1.99 |
| 10 |
630748 |
WELCH PLUG Price: $1.17 |
| 10 |
65-8090 |
BLOCK-MOUNT Price: $91.37 |
| 11 |
530055546 |
Assy-Throttle Cable (Type 2,3,4) Price: $8.99 |
| 11 |
530071549 |
Assy-Throttle Cable (Type 1) Price: $8.99 |
| 11 |
631027 |
WELCH PLUG Price: $1.17 |
| 11 |
65-9830 |
RAMP-QUICK UP Price: $128.27 |
| 12 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 12 |
530016193 |
Washer Price: $1.99 |
| 12 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 13 |
530042084 |
Spring-Compression Price: $1.99 |
| 13 |
631022 |
CLIP Price: $1.25 |
| 13 |
65-9810 |
SPRING-ADJUSTMENT Price: $11.26 |
| 14 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 14 |
530047925 |
Actuator Price: $1.99 |
| 14 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 15 |
2410-68 |
COVER-PIN Price: $0.38 |
| 15 |
530054160 |
Locator-Right Price: $6.99 |
| 15 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 16 |
530095853 |
Drive Shaft - Flex Price: $11.99 |
| 16 |
65-9980 |
SPACER Price: $13.03 |
| 16A |
631951 |
FLOAT BOWL Price: $12.35 |
| 17 |
27136A |
DRAIN ASSY Price: $5.96 |
| 17 |
3274-22 |
SCREW-HSH Price: $0.68 |
| 18 |
27554 |
GASKET Price: $1.05 |
| 18 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 18 |
530403949 |
Guide - Line Price: $2.99 |
| 19 |
530054223 |
Assy. - Cap 5/16" Price: $5.99 |
| 19 |
65-9340 |
BOLT-SHOULDER Price: $10.02 |
| 20 |
65-9320 |
IDLER Price: $33.55 |
| 21 |
251-328 |
BEARING-BALL Price: $14.66 |
| 21 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 21 |
530052287 |
Line Limiter Price: $1.99 |
| 22 |
530015814 |
Screw-Line Limiter Price: $1.99 |
| 22 |
631583 |
POWER SCREW Price: $10.18 |
| 22 |
65-8120 |
BOLT-CARR Price: $9.50 |
| 23 |
530015820 |
Bolt-Shield Price: $1.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 23 |
65-9860 |
BEARING Price: $7.60 |
| 24 |
530095574 |
Dust Cup Price: $1.99 |
| 24 |
631838 |
ADJ SCREW Price: $2.71 |
| 24 |
65-9330 |
SPACER Price: $2.58 |
| 25 |
530054459 |
Assy-Wire Guard Price: $3.99 |
| 25 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 25 |
92-3046 |
SPACER Price: $36.62 |
| 26 |
251-327 |
BEARING-BALL Price: $21.22 |
| 26 |
530016179 |
Screw Price: $1.99 |
| 26 |
632527 |
FUEL FITTING This part replaces 631775. Price: $6.03 |
| 27 |
95-5728 |
DISCONTINUED Price: Call Us |
| 28 |
107-8198 |
COVER-HOUSING, DRIVE BELT Price: $112.44 |
| 29 |
65-8110 |
SPACER Price: $6.19 |
| 30 |
108-3153 |
SCREW-HSBH Price: $2.04 |
| 30 |
630738 |
SPRING Price: $1.25 |
| 31 |
3253-12 |
WASHER-LOCK/SP Price: $0.25 |
| 32 |
630739 |
WASHER Price: $1.25 |
| 33 |
323-34 |
SCREW-HH Price: $0.54 |
| 530055350 |
Shaft |
Warning Decal Price: $0.33 530055350 |
| 530086936 |
Operator's |
Manual (Type 2,3,4) Price: $3.33 530086936 |
| 530088896 |
Operator's |
Manual (Type 1) Price: $3.99 530088896 |
