| Ref | Part Number | Description |
|---|
| 1 |
106-6876 |
SEAL KIT Price: $48.83 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532184991. Price: $149.99 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
60-6240 |
WASHER Price: $15.20 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
94-3004 |
SHAFT-DRIVE, SPLINED Price: $564.48 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 8 |
94-3002 |
SCREW-CAP Price: $7.19 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
137-4286 |
SENSOR-SPEED ASM This part replaces 94-3010. Price: $634.90 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 12 |
94-3003 |
PLATE-VALVE Price: $515.64 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
76-6910 |
ROTATING KIT Price: $2,143.15 |
| 14 |
76-6970 |
INSERT-PLATE, CAM Price: $140.84 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
