| Ref | Part Number | Description |
|---|
| 1 |
732211801 |
LOCKNUT M8 Price: $3.99 |
| 6 |
94-3940 |
SCREW-HH Price: $7.51 |
| 9 |
100-1356 |
SCREW-HF This part replaces 94-4002. Price: $11.92 |
| 10 |
93-5969 |
NEUTRAL RETURN ASM This part replaces 94-3929. Price: $1,632.47 |
| 15 |
94-3966 |
SWITCH -NSS,WEATH-PACK,NC Price: $69.15 |
| 16 |
94-4045 |
ADJUSTER-THREADED Price: $171.13 |
| 17 |
28-3570 |
O-RING Price: $6.06 |
| 18 |
94-4046 |
PIN Price: $17.49 |
| 19 |
94-4044 |
DISCONTINUED Price: Call Us |
| 20 |
734116441 |
SPACER Price: $3.99 |
| 20 |
94-3943 |
COVER-NEUTRAL Price: $453.70 |
| 21 |
94-9282 |
BRACKET-BALANCE, COUNTER This part replaces 93-5171. Price: $177.15 |
| 22 |
94-3944 |
GASKET-RETURN, NEUTRAL Price: $24.47 |
| 23 |
94-3901 |
DISCONTINUED Price: Call Us |
| 24 |
94-4029 |
RING-RETAINING, INT. Price: $3.22 |
| 25 |
94-3971 |
BEARING-BALL Price: $122.44 |
| 26 |
94-3903 |
PINION-DRIVE, PUMP Price: $387.49 |
| 27 |
94-3994 |
RING-RETAINING Price: $5.51 |
| 28 |
94-3905 |
GEAR-DRIVE, PUMP Price: $829.72 |
| 29 |
94-3953 |
NUT-HEX Price: $27.51 |
| 30 |
94-3924 |
DISCONTINUED Price: Call Us |
| 31 |
251-8 |
BEARING-BALL This part replaces 28-3650. Price: $30.06 |
| 32 |
94-3963 |
RING-RETAINING, EXT Price: $2.73 |
| 33 |
94-3919 |
DISCONTINUED Price: Call Us |
| 34 |
94-3908 |
DISCONTINUED Price: Call Us |
| 35 |
94-3923 |
DISCONTINUED Price: Call Us |
| 36 |
95-2728 |
SPACER-DRIVE, FINAL This part replaces 94-3949. Price: $63.24 |
| 37 |
94-3997 |
RING-RETAINING Price: $7.62 |
| 38 |
84-0310 |
DISCONTINUED Price: Call Us |
| 39 |
94-3960 |
BEARING-BALL Price: $88.70 |
| 40 |
94-3942 |
BEARING-BALL Price: $100.14 |
| 41 |
100-4873 |
BACKPLATE ASM This part replaces 94-3604. Price: $708.08 |
| 42 |
94-3906 |
SHAFT-MOTOR Price: $514.39 |
| 43 |
93-5381 |
BRACKET Price: $40.96 |
| 44 |
94-4004 |
SCREW-HF Price: $8.60 |
| 45 |
725245371 |
SCREW This part replaces 725245351. Price: $4.99 |
| 45 |
95-7038 |
HOUSING-HYD, VARIABLE This part replaces 94-4077. Price: $3,636.82 |
| 46 |
94-3975 |
PIN Price: $5.80 |
| 47 |
94-4058 |
SWASHPLATE-VARIABLE Price: $1,891.63 |
| 48 |
75-0400 |
PLATE-THRUST Price: $41.27 |
| 49 |
94-3921 |
DISCONTINUED Price: Call Us |
| 50 |
94-3956 |
BEARING-BALL Price: $48.55 |
| 51 |
94-3974 |
PIN Price: $1.02 |
| 52 |
94-3957 |
BEARING-NEEDLE Price: $91.74 |
| 53 |
94-3973 |
PLATE-VALVE Price: $837.09 |
| 54 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 55 |
75-0470 |
CYLINDER BLOCK KIT Price: $1,746.91 |
| 56 |
94-3992 |
DISCONTINUED Price: Call Us |
| 57 |
94-3946 |
SHAFT-TRUNNION Price: $168.35 |
| 58 |
32121-91 |
PIN-SPRING This part replaces 28-3620. Price: $0.81 |
| 59 |
94-3967 |
SWASHPLATE-PUMP, VARIABLE Price: $273.27 |
| 60 |
94-4051 |
O-RING Price: $1.89 |
| 61 |
94-3978 |
PLATE-THRUST Price: $128.58 |
| 62 |
94-3934 |
SHAFT-TRUNNION Price: $109.35 |
| 63 |
94-4040 |
BEARING-BALL Price: $56.25 |
| 64 |
94-3932 |
RING-RETAINING Price: $2.27 |
| 65 |
94-4050 |
SCREW-HF Price: $12.78 |
| 66 |
94-4048 |
HOUSING-DIPSTICK Price: $284.76 |
| 67 |
94-4049 |
DISCONTINUED Price: Call Us |
| 68 |
93-5972 |
DISCONTINUED Price: Call Us |
| 82 |
515745046 |
SCREW Price: $3.99 |
| 93 |
516614311 |
DECK PROTECTOR RH Price: $27.99 |
| 94 |
516614411 |
DECK PROTECTOR LH Price: $27.99 |
| 95 |
516509601 |
SLEEVE Price: $5.99 |
| 96 |
516841100 |
Damper Price: $3.04 |
| 102 |
516850511 |
Cover Price: $5.69 |
| 103 |
516850411 |
COVER Price: $10.28 |
| 104 |
516924801 |
SCREW Price: $3.63 |
| 105 |
516924901 |
SCREW Price: $0.99 |
| 106 |
516873907 |
DECK FRONT COVER Price: $11.85 |
| 107 |
516852200 |
COUNTERWEIGHT Price: $10.24 |
| 108 |
516873797 |
Cover Price: $83.09 |
| 109 |
516490201 |
Shaft Price: $6.81 |
| 110 |
512807968 |
BRACKET TOP This part replaces 516702711. Price: $24.99 |
| 111 |
516924400 |
Washer Price: $0.95 |
| 112 |
516612901 |
SPRING Price: $8.99 |
| 113 |
513075400 |
BOTTOM PLATE BRACKET This part replaces 516499501. Price: $1.99 |
| 116 |
516492701 |
Bracket Price: $19.90 |
| 117 |
516848911 |
Cover Price: $19.59 |
| 118 |
516924701 |
SCREW Price: $3.99 |
| 119 |
516873607 |
DECK Price: $359.91 |
| 120 |
511918268 |
LINK ARM COVER This part replaces 516511211. Price: $12.99 |
| 130 |
734114741 |
WASHER Price: $4.99 |
| 131 |
516924000 |
RIVET Price: $1.99 |
| 132 |
516855000 |
PROTECTOR Price: $12.52 |
| 133 |
516627611 |
BRACKET Price: $28.78 |
