| Ref | Part Number | Description |
|---|
| 0 |
631795A |
SERVICE CARB This part replaces 631469. Price: $78.81 |
| 1 |
539130841 |
CHUTE W/DECAL ORANGE Price: $219.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 2 |
539106803 |
BAGGER TRAY Price: $109.99 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 3 |
539107242 |
BAG FRAME, BLACK Price: $329.00 |
| 4 |
539106846 |
EXTENDER GREY Price: $84.99 |
| 5 |
539106835 |
SAFETY DOOR ORANGE Price: $149.99 |
| 6 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 7 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 9 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 10 |
630904 |
SHAFT & LEV Price: $5.16 |
| 10 |
874780528 |
SCREW This part replaces 539990669. Price: $4.99 |
| 11 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 12 |
539990588 |
HCS 3/8C X 2 Price: $3.99 |
| 13 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 14 |
31837 |
SHUTTER Price: $1.18 |
| 14 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 15 |
540005464 |
CATCHER BAG Price: $179.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
539108143 |
DECAL, BAGGING GRAPHIC Price: $8.99 |
| 16 |
631807 |
FUEL FITTING Price: $6.03 |
| 17 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 17 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 18 |
539107315 |
SPRING BAGGER Price: $7.99 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 19 |
539005187 |
BLADE Price: $3.99 |
| 20 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 20 |
631838 |
ADJ SCREW Price: $2.71 |
| 21 |
539106827 |
CABLE 46.5" POWER RAKE Price: $24.99 |
| 21 |
630766 |
SPRING Price: $1.25 |
| 22 |
539976856 |
TIE, PLASTIC Price: $4.99 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 23 |
539106848 |
LANYARD Price: $2.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
532429164 |
NUT.PUSH.625 This part replaces 539109304. Price: $4.99 |
| 25 |
539107316 |
SIDESHIELD Price: $9.99 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 26 |
539107244 |
DECAL, HANDLE PIN Price: $3.99 |
| 27 |
539976982 |
WASHER 5/8 FLAT Price: $3.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
539976438 |
COMPRESSION SPRING Price: $3.99 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
539990297 |
COTTER PIN Price: $2.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
539990037 |
COTTER PIN 3/32 X 3/4 Price: $2.99 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
539110865 |
GRIP Price: $3.99 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 32 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 33 |
539990861 |
RHSNB 5/16-18X1 3/4 Price: $2.99 |
| 34 |
539110982 |
BAG CLAMP Price: $12.99 |
| 35 |
539130836 |
BELT-COGGED Price: $12.99 |
| 36 |
539113784 |
PULLEY, 4.5" Price: $37.99 |
| 40 |
31839 |
POWER SCREW Price: $10.89 |
| 41 |
630740 |
O RING Price: $1.49 |
| 42 |
630739 |
WASHER Price: $1.25 |
| 43 |
630738 |
SPRING Price: $1.25 |
| 44 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
