| Ref | Part Number | Description |
|---|
| 1 |
142874 |
Assembly, Housing, LH Price: Call Us |
| 1 |
5-1756 |
DISCONTINUED Price: Call Us |
| 2 |
142875 |
Assembly, Housing, RH Price: Call Us |
| 2 |
5-1755 |
DISCONTINUED Price: Call Us |
| 3 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 4 |
323-5 |
SCREW-HH Price: $0.41 |
| 5 |
251-166 |
BEARING-FLANGE Price: $14.74 |
| 6 |
251-165 |
BEARING-BALL Price: $104.65 |
| 7 |
153765 |
Oil Seal .984 x 1.5 x .25 Price: Call Us |
| 7 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 8 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 9 |
287-5 |
DISCONTINUED Price: Call Us |
| 10 |
5-1743 |
DISCONTINUED Price: Call Us |
| 11 |
3220-7 |
NUT-JAM Price: $4.09 |
| 12 |
3254-7 |
WASHER-LOCK, INT Price: $4.82 |
| 13 |
5-1727 |
DISCONTINUED Price: Call Us |
| 14 |
3211-17 |
SCREW-HH Price: Call Us |
| 15 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 16 |
142876 |
Brake Shaft Assembly Price: Call Us |
| 16 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 17 |
5-1747 |
SPRING-ADJUSTMENT Price: $5.76 |
| 18 |
5-1744 |
DISCONTINUED Price: Call Us |
| 19 |
5-1746 |
DISCONTINUED Price: Call Us |
| 20 |
142877 |
Axie Mounting Horn Assembly Price: Call Us |
| 20 |
5-1730 |
DISCONTINUED Price: Call Us |
| 21 |
142878 |
Washer 1.0 x 1.63 x .08 Price: Call Us |
| 21 |
59-9740 |
FLEX DRAW LATCH ASM This part replaces 2-4939. Price: $36.89 |
| 22 |
142879 |
Washer 1.0 x 2.06 x .09 Price: Call Us |
| 22 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 23 |
3219-3 |
NUT-HEX Price: $0.34 |
| 24 |
5-1752 |
DISCONTINUED Price: Call Us |
| 25 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 26 |
5-1751 |
DISCONTINUED Price: Call Us |
| 27 |
271-10 |
DISCONTINUED Price: Call Us |
| 28 |
3257-14 |
KEY Price: $6.19 |
| 29 |
3-4805 |
DISCONTINUED Price: Call Us |
| 30 |
3-4751 |
DISCONTINUED Price: Call Us |
| 31 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 32 |
22-1080 |
DISCONTINUED Price: Call Us |
| 33 |
142929 |
Brake Yoke Assembly (AYP part number) Price: Call Us |
| 33 |
3258-53 |
Screw Price: Call Us |
| 34 |
5-1758 |
DISCONTINUED Price: Call Us |
| 35 |
142880 |
Brake Arm Price: Call Us |
| 35 |
5-1757 |
DISCONTINUED Price: Call Us |
| 36 |
142882 |
Puck Plate Price: Call Us |
| 36 |
3220-1 |
NUT-JAM Price: $0.99 |
| 37 |
142883 |
Brake Puck Price: Call Us |
| 37 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 38 |
142884 |
Washer 7/8 O.D. x 7/16 x .060 Price: Call Us |
| 38 |
236-1 |
DISCONTINUED Price: Call Us |
| 39 |
142885 |
Nut, Castle 5/16-24 (AYP part number) Price: Call Us |
| 39 |
5-1742 |
DISCONTINUED Price: Call Us |
| 40 |
142886 |
Cotter Pin (AYP part number) Price: Call Us |
| 40 |
3217-6 |
NUT-HEX Price: $1.19 |
| 41 |
142887 |
Brake Actuating Pin Price: Call Us |
| 41 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 42 |
142888 |
Hi Pro Key Price: Call Us |
| 42 |
5-1745 |
DISCONTINUED Price: Call Us |
| 43 |
142889 |
Spacer Price: Call Us |
| 43 |
5-1741 |
DISCONTINUED Price: Call Us |
| 44 |
3230-4 |
BOLT-CARR Price: $0.47 |
| 45 |
142890 |
Brake Disc Price: Call Us |
| 45 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 46 |
142891 |
Bolt 1/4-20 x 1-1/2 Price: Call Us |
| 46 |
321-5 |
SCREW-HH Price: $0.22 |
| 47 |
142892 |
Bolt 1/4-20 x 1 Price: Call Us |
| 47 |
3219-2 |
NUT-HEX Price: $0.37 |
| 48 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 49 |
153766 |
Differential Assembly Price: Call Us |
| 63 |
142894 |
Dowel Pin Price: Call Us |
| 64 |
150818 |
Reduction Gear, 14 Teeth to 38 Teeth Price: Call Us |
| 65 |
142897 |
Final Drive Pinion Assembly Price: Call Us |
| 67 |
142898 |
Jackshaft Price: Call Us |
| 68 |
142899 |
O-Ring Price: Call Us |
| 69 |
142900 |
Washer 5/8 X 1-5/32 Price: Call Us |
| 70 |
142901 |
Washer 7/8 X 1-1/2 Price: Call Us |
| 71 |
142902 |
Bolt, Hex 5/16-18 x 3.5 Price: Call Us |
| 72 |
153767 |
Locknut, Hex 5/16-18 Price: Call Us |
| 73 |
142904 |
Bolt, Hex 5/16-18 x 1-1/2 Price: Call Us |
| 74 |
142905 |
Hex Cap Screw 5/16-18 x 1 Price: Call Us |
| 76 |
142907 |
Shoulder Bolt Price: Call Us |
| 77 |
142908 |
Freewheel Actuating Arm Price: Call Us |
| 78 |
142909 |
Oil Seal .625 x 1.0 x .25 Price: Call Us |
| 81 |
142910 |
Bolt, Hex 5/16-18 x 1-3/4 Price: Call Us |
| 82 |
142911 |
Bolt 5/16-18 x 4-1/2 Price: Call Us |
| 89 |
142912 |
Filter, Spin On (AYP part number) Price: Call Us |
| 91 |
153769 |
Pump, BDU-10L-122 Price: Call Us |
| 95 |
142914 |
Plug, Straight Thread Price: Call Us |
| 103 |
142916 |
Washer Price: Call Us |
| 104 |
142917 |
Vent Cap Assembly Price: Call Us |
| 106 |
342918 |
Fitting O-Ring Assembly (Outside vendor part number) Price: Call Us |
| 108 |
142919 |
Control Arm Price: Call Us |
| 109 |
142920 |
Set Screw Price: Call Us |
| 110 |
142921 |
Filter Head Price: Call Us |
| 111 |
150820 |
Hose 1/2" Price: Call Us |
| 112 |
150823 |
Fitting, 1/2" Beaded 90ø 7/8 SAE Price: Call Us |
| 113 |
150821 |
Fitting, 1/2" Beaded 60ø 9/16 Price: Call Us |
| 117 |
150822 |
Fitting, 1/2" Beaded 90ø 9/16 Price: Call Us |
| 123 |
150824 |
O Ring Price: Call Us |
| 124 |
150825 |
Pinch Clamp Price: Call Us |
