| Ref | Part Number | Description |
|---|
| 1 |
37-7720 |
Shaft Collar R.H. Price: Call Us |
| 1 |
532150546 |
STEERING WHEEL KIT This part replaces 532121472. Price: $59.99 |
| 2 |
37-7660 |
Blade Price: Call Us |
| 2 |
532142033 |
AXLE ASSY Price: $59.99 |
| 3 |
323-7 |
SCREW-HH Price: $0.65 |
| 3 |
532135227 |
Spindle Asm LH (AYP part number) Price: $15.39 |
| 4 |
37-7730 |
Clamp Strap Price: Call Us |
| 4 |
532135228 |
Spindle Asm RH Price: $12.97 |
| 5 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 5 |
532006266 |
WASHER THRUST Price: $5.99 |
| 6 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 6 |
532121748 |
WASHER Price: $1.99 |
| 7 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 7 |
819272016 |
WASHER Price: $2.99 |
| 8 |
812000029 |
RING CLIP Price: $1.99 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN Price: $1.99 |
| 10 |
532130468 |
DRAG LINK Price: $49.99 |
| 11 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 12 |
873680600 |
LOCKNUT This part replaces 873610600. Price: $1.99 |
| 13 |
532110438 |
Spacer, Bearing, Axle, Front (AYP part number) Price: $5.99 |
| 14 |
874011056 |
BOLT.HEX.5/8-11 Price: $4.99 |
| 15 |
583612401 |
LOCKNUT M (1 2) (5 2) This part replaces 873601000. Price: $2.99 |
| 16 |
532132624 |
Pin, Axle 5/8 x 1.55/1.54 LG. (AYP part number) Price: $2.42 |
| 17 |
532156543 |
STEERING SHAFT This part replaces 532128758. Price: $49.99 |
| 18 |
532057079 |
THRUST WASHER Price: $2.99 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $6.99 |
| 20 |
819091016 |
WASHER This part replaces 532126684. Price: $2.99 |
| 21 |
810040400 |
LOCKWASHER Price: $3.99 |
| 22 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871070410. Price: $2.99 |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532124033. Price: $27.99 |
| 24 |
532109816 |
NYLINER T (7283A) Price: $2.99 |
| 25 |
532124036 |
BRKT,STEERING Price: $4.99 |
| 26 |
532126847 |
BUSHING.DRAGLINK (2 2) This part replaces 532120754. Price: $2.99 |
| 27 |
532136874 |
GEAR.SECTOR Price: $49.99 |
| 28 |
819131414 |
WASHER This part replaces 819131416. Price: $3.99 |
| 29 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 30 |
876020412 |
COTTER PIN Price: $3.99 |
| 32 |
532192757 |
ROD.TIE.WIRE.FORM This part replaces 532130465. Price: $12.99 |
| 36 |
532145207 |
BUSHING STRG 3/4 Price: $3.99 |
| 37 |
817541008 |
SCREW Price: $2.99 |
| 38 |
532150546 |
STEERING WHEEL KIT This part replaces 532126805. Price: $59.99 |
| 39 |
532100712 |
Washer 17/32 x 2-1/4 x .160 (AYP part number) Price: $2.42 |
| 40 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 41 |
532100711 |
Adapter Wheel Strg 758/ 753id (AYP part number) Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $1.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $1.99 |
