| Ref | Part Number | Description |
|---|
| 1 |
121-4698 |
NUT-KEPS This part replaces 32149-5. Price: $1.15 |
| 1 |
532435775 |
IMPELLER Price: $56.99 |
| 2 |
532429659 |
KIT.GEARBOX.SNO This part replaces 532427148. Price: $249.99 |
| 3 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 3 |
532188909 |
BEARING Price: $12.99 |
| 4 |
21-7720 |
WASHER-THRUST Price: $3.39 |
| 4 |
532427146 |
IMPELLER PULLEY Price: $17.99 |
| 5 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 24-8790. Price: $702.98 |
| 5 |
532442438 |
BASE.DISCHARGE.CHUTE This part replaces 532175322. Price: $13.99 |
| 6 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 21-7690. Price: $702.98 |
| 6 |
532436236 |
CORNER BRACKET Price: $2.99 |
| 7 |
21-7730 |
WASHER-THRUST, PINION Price: $2.65 |
| 7 |
532192199 |
CLEAN OUT TOOL Price: $19.99 |
| 8 |
532405400 |
TOOL CLIP Price: $2.99 |
| 9 |
43-6760 |
BEARING-ROLLER, CONE TAPER Price: $113.20 |
| 9 |
539976978 |
NUT.1/4C.NYLOC This part replaces 873800400. Price: $1.49 |
| 10 |
43-6750 |
BEARING-TAPER, CUP Price: $69.64 |
| 10 |
874780426 |
SCREW 1/4-20 X .625 Price: $3.49 |
| 11 |
532427942 |
NUT 5/16-18 Price: $2.99 |
| 12 |
532163183 |
SCREW 5/16-18 X .625 Price: $2.99 |
| 13 |
32144-112 |
SCREW-HWH Price: $0.99 |
| 13 |
532427145 |
IMPELLER HUB Price: $3.99 |
| 14 |
532427154 |
IMPELLER SLEEVE Price: $2.99 |
| 14 |
86-7230 |
GEAR-INPUT, TRANSMISSION Price: $610.12 |
| 15 |
43-6710 |
SHIM-PINION (.003) Price: $2.17 |
| 15 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.69 |
| 16 |
43-6711 |
SHIM-PINION (.005) Price: $3.80 |
| 16 |
532180355 |
CARRIAGE BOLT Price: $3.99 |
| 17 |
43-6712 |
SHIM-PINION (.010) Price: $3.19 |
| 17 |
532194189 |
SCREW 13-16 X .625 Price: $3.99 |
| 18 |
43-6713 |
SHIM-PINION (.030) Price: $6.99 |
| 18 |
532086447 |
Plug This part replaces 532407760. Price: $3.99 |
| 19 |
3210-8 |
SCREW-HH Price: $1.02 |
| 19 |
532427302 |
GEARBOX COVER RH Price: $28.99 |
| 20 |
532427345 |
GASKET Price: $3.99 |
| 20 |
71-4350 |
NUT Price: $3.46 |
| 21 |
532174698 |
SEAL, OIL This part replaces 532407770. Price: $3.99 |
| 21 |
83-5130 |
SPACER-PINION Price: $87.56 |
| 22 |
532174701 |
BUSHING FLANGE 1" This part replaces 532407762. Price: $27.99 |
| 22 |
72-3572 |
SHIM-BEARING, FRONT (.098) This part replaces 72-3570. Price: $23.68 |
| 22 |
72-3573 |
SHIM-BEARING, FRONT (.100) Price: $24.63 |
| 22 |
72-3574 |
SHIM-BEARING, FRONT (.102) Price: $23.68 |
| 22 |
72-3575 |
SHIM-BEARING, FRONT (.104) Price: $22.53 |
| 22 |
72-3576 |
SHIM-BEARING, FRONT (.106) Price: $23.68 |
| 22 |
72-3577 |
SHIM-BEARING, FRONT (.108) Price: $22.53 |
| 22 |
72-3578 |
SHIM-BEARING, FRONT (.110) Price: $22.53 |
| 22 |
72-3580 |
SHIM-BEARING, FRONT (.112) Price: $22.53 |
| 22 |
72-3581 |
SHIM-BEARING, FRONT (.114) Price: $22.53 |
| 22 |
72-3582 |
SHIM-BEARING, FRONT (.116) Price: $22.53 |
| 22 |
72-3583 |
SHIM-BEARING, FRONT (.118) Price: $56.93 |
| 22 |
72-3584 |
SHIM-BEARING, FRONT (.120) Price: $24.63 |
| 22 |
72-3585 |
SHIM-BEARING, FRONT (.125) Price: $22.53 |
| 22 |
72-3586 |
SHIM-BEARING, FRONT (.127) Price: $22.53 |
| 22 |
72-3587 |
SHIM-BEARING, FRONT (.129) Price: $23.68 |
| 22 |
72-3588 |
SHIM-BEARING, FRONT (.131) Price: $22.53 |
| 22 |
72-3590 |
SHIM-BEARING, FRONT (.133) Price: $22.53 |
| 22 |
72-3591 |
SHIM-BEARING, FRONT (.135) Price: $21.44 |
| 22 |
72-3592 |
SHIM-BEARING, FRONT (.137) Price: $22.53 |
| 22 |
72-3593 |
SHIM-BEARING, FRONT (.139) Price: $23.68 |
| 22 |
72-3594 |
SHIM-BEARING, FRONT (.141) Price: $23.68 |
| 22 |
72-3595 |
SHIM-BEARING, FRONT (.143) Price: $22.53 |
| 22 |
72-3596 |
SHIM-BEARING, FRONT (.145) Price: $22.53 |
| 22 |
72-3597 |
SHIM-BEARING, FRONT (.147) Price: $22.53 |
| 22 |
72-3598 |
SHIM-BEARING, FRONT (.149) Price: $24.63 |
| 22 |
72-3600 |
SHIM-BEARING, FRONT (.151) Price: $23.68 |
| 23 |
254-91 |
CONE-BEARING Price: $18.65 |
| 23 |
532007396 |
Thrust Bearing Race This part replaces 532174697. Price: $3.99 |
| 24 |
254-90 |
BEARING-CUP This part replaces 21-8390. Price: $11.29 |
| 24 |
532429659 |
KIT.GEARBOX.SNO This part replaces 532407763. Price: $249.99 |
| 25 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 25 |
532174657 |
SHAFT, AUGER This part replaces 532407764. Price: $39.99 |
| 26 |
532189282 |
SQUARE KEY Price: $3.99 |
| 26 |
93-3619 |
UPPER HOUSING ASM Price: $1,825.32 |
| 27 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 27 |
532174686 |
BUSHING FLANGE 5/8 This part replaces 532407758. Price: $19.99 |
| 28 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 28 |
532174683 |
THRUST WASHER Price: $3.99 |
| 29 |
532427147 |
IMPELLER SHAFT Price: $82.99 |
| 29 |
92-1773 |
SCREW-HHF Price: $3.05 |
| 30 |
32121-15 |
PIN-ROLL This part replaces 21-7710. Price: $1.60 |
| 30 |
532007836 |
ROLL PIN This part replaces 532184205. Price: $3.99 |
| 31 |
21-7700 |
SHAFT-MATE, PINION Price: $54.05 |
| 31 |
532174681 |
THRUST WASHER Price: $9.99 |
| 32 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 32 |
532174684 |
THRUST BEARING Price: $5.99 |
| 33 |
21-7670 |
CASE-DIFFERENTIAL Price: $687.90 |
| 33 |
532407769 |
BEARING Price: $3.99 |
| 34 |
100-3744-03 |
LOWER HOUSING ASM Price: $921.55 |
| 34 |
532407768 |
O-RING Price: $3.99 |
| 35 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 35 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532407767. Price: $2.49 |
| 36 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 36 |
532427317 |
GEARBOX COVER LH Price: $29.99 |
| 37 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 38 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 39 |
72-9420 |
VENT Price: $6.85 |
| 40 |
83-4910 |
COUPLER-PINION Price: $223.04 |
| 41 |
71-4330 |
SEAL Price: $36.26 |
| 42 |
93-3618 |
GEAR AND PINION ASM Price: $1,107.66 |
