| Ref | Part Number | Description |
|---|
| 1 |
72-9390 |
BELT-SEAT Price: $140.77 |
| 2 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 3 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 4 |
3212-4 |
SCREW-HH Price: $2.73 |
| 5 |
325-14 |
SCREW-HH Price: $2.64 |
| 6 |
92-5518-03 |
DISCONTINUED This part replaces 92-5518. Price: Call Us |
| 7 |
325-5 |
SCREW-HH Price: $1.20 |
| 8 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 9 |
92-5515 |
MOUNT-STRAP, TETHER Price: $28.92 |
| 10 |
324-4 |
SCREW-HH Price: $0.95 |
| 11 |
32128-23 |
NUT-HF Price: $1.51 |
| 12 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 12 |
586478501 |
ENGINE.PULLEY Price: $27.99 |
| 13 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 14 |
322-14 |
SCREW-HH Price: $1.01 |
| 15 |
581290101 |
TANK.ASSEMBL.2.5GAL.NON-EPA Price: $99.99 |
| 15 |
92-5517-03 |
LEFT MOUNT ASM This part replaces 92-5517. Price: $156.29 |
| 16 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 17 |
325-9 |
SCREW-HH Price: $1.87 |
| 18 |
3217-9 |
NUT-HH Price: $0.37 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 19 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 20 |
587242504 |
THROTTLE CABLE This part replaces 587242501. Price: $32.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE Price: $2.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 108 |
583400501 |
COVER.PULLEY.ENGINE.SRD.FRENCH This part replaces 532423041. Price: $89.99 |
