| Ref | Part Number | Description |
|---|
| 1 |
486350 |
Belt Cover, 61GC-VRII This part replaces 483227. Price: Call Us |
| 2 |
04029-04 |
Wing Nut, 3/8-16 (Small) Top side Price: Call Us |
| 3 |
483223 |
Cap, Square Vinyl Price: Call Us |
| 4 |
04021-08 |
HEX, NUT, ELASTIC STOP LOCK, 1/4-20 Price: Call Us |
| 5 |
461723 |
Adapter, Blower GC-STC, Price: Call Us |
| 6 |
04040-14 |
Flatwasher, 1/4" (.312 x .750 x .065") Price: Call Us |
| 7 |
48137-04 |
Rubber Strap 7-3/4" Price: Call Us |
| 8 |
04001-59 |
SERR. FLG. HEX HEAD CAPSCREW, 5/16-18 X 3/4 Price: Call Us |
| 9 |
481625-01 |
Knob, w/stud 3/8-16 x 1-1/4" Price: Call Us |
| 10 |
04064-15 |
Clevis Pin, 5/16 x 1-1/2" Price: Call Us |
| 11 |
04069-03 |
Pin, Rue Cotter 5/16 Dia. Price: Call Us |
| 12 |
04067-07 |
Pin, Ring 1/2 x 2-1/4" Price: Call Us |
| 13 |
481547 |
Lanyard, Deck Height Pin Price: Call Us |
| 14 |
482587 |
Pulley, 4.0" Dia. - 1.125" Bore, (STT-52 & STTII-52) Price: Call Us |
| 15 |
04012-04 |
Setscrew, Hex Socket Knurl Cup Pt. 5/16 - 18 (nylock) Price: Call Us |
| 16 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 17 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 18 |
04041-07 |
Flatwasher, 3/8" Special (.391 x .938 x .105) Price: Call Us |
| 19 |
04003-11 |
SHORT SQ. NECK CARRIAGE BOLT, 3/8-16 X 1-1/4" Price: Call Us |
| 20 |
461894 |
Mounting Post Weldment, Blower, (61") Price: Call Us |
| 21 |
462417 |
Belt Cover Assembly, GC-STC-61V w/Cap Price: Call Us |
| 22 |
04029-04 |
Wing Nut, 3/8-16 (Small) Top side Price: Call Us |
| 23 |
04003-23 |
Carriage Bolt, 3/8-16 x 1.0" Price: Call Us |
| 24 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 25 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 (35BV & 37BV-EFI) Price: Call Us |
| 26 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 27 |
452384 |
Baffle Weldment - 61" Deck Price: Call Us |
| 28 |
424212 |
Baffle, Turbo - 61" Deck Price: Call Us |
| 29 |
04024-02 |
Nut, Push-On - 3/8" Dia. Price: Call Us |
| 30 |
04003-22 |
Carriage Bolt, 3/8-16 x 1-1/4" Price: Call Us |
| 59 |
253-83 |
SEAL-OIL Price: $7.87 |
| 60 |
3-1545 |
SPACER-CLUTCH Price: $53.38 |
| 61 |
237-38 |
O-RING Price: $1.94 |
| 63 |
251-139 |
BEARING-BALL Price: $104.98 |
| 64 |
88-8700 |
GEAR-PINION This part replaces 3-0461. Price: $56.31 |
| 65 |
3-0465 |
DISCONTINUED Price: Call Us |
| 66 |
3-0592 |
CLUTCH-REEL, MALE Price: $41.36 |
| 67 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 68 |
3-4494 |
WASHER-THRUST Price: $23.81 |
| 69 |
251-163 |
BEARING-BALL Price: $149.58 |
| 70 |
2-4779 |
UNIVERSAL DRIVER AND PIN ASM Price: $140.36 |
| 71 |
32121-25 |
PIN-ROLL Price: $0.61 |
| 72 |
253-59 |
SEAL-OIL Price: $21.77 |
| 73 |
3-2072 |
SEAL-BEARING Price: $6.74 |
| 74 |
95-1807 |
COVER-BEARING This part replaces 3-2068. Price: $35.00 |
| 75 |
32140-40 |
SCREW-HH Price: $1.11 |
| 76 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 78 |
3-2552 |
Main Leaf Price: Call Us |
| 79 |
3-2078 |
Center Leaf Price: Call Us |
| 80 |
3-2075 |
LEAF-LOWER Price: $66.27 |
| 81 |
3-2077 |
Spring Bracket Price: Call Us |
| 82 |
3-2074 |
SPACER Price: $9.42 |
| 83 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 84 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 85 |
322-8 |
SCREW-HH Price: $1.26 |
| 86 |
95-1810 |
PIVOT-YOKE This part replaces 3-2154. Price: $136.98 |
| 462901 |
Belt |
Cover Assembly, w/Cap (STCII-61V) Price: Call Us 462901 |
