| Ref | Part Number | Description |
|---|
| 2 |
95-5634 |
CARTRIDGE-LOGIC, SPOOL This part replaces 69-4120. Price: $297.27 |
| 3 |
94-8175 |
CONTROL-FLOW, ROTARY Price: $264.64 |
| 4 |
94-3655 |
VALVE-RELIEF Price: $208.08 |
| 5 |
125-2155 |
VALVE-RELIEF, CARTRIDGE This part replaces 104-1200. Price: $302.89 |
| 6 |
94-3657 |
SPOOL ASM Price: $478.74 |
| 7 |
161-8352 |
VALVE AND COIL KIT This part replaces 93-7494. Price: $347.93 |
| 8 |
161-8350 |
COIL ASM This part replaces 83-2010. Price: $111.53 |
| 9 |
106-9084 |
PLUG-ORIFICE (.020 DIA) This part replaces 95-5999. Price: $67.12 |
| 10 |
353-991 |
PLUG-HEX, HOLLOW Price: $10.21 |
| 11 |
353-990 |
PLUG ASM Price: $10.01 |
| 12 |
353-989 |
PLUG-HEX, HOLLOW Price: $21.59 |
| 13 |
94-3660 |
DETENT KIT Price: $309.61 |
| 21 |
94-6378 |
DETENT KIT Price: $397.08 |
| 50468501 |
50468501 |
Price: Call Us |
| 501466901 |
501466901 |
SCREW Price: $7.99 |
| 501468401 |
501468401 |
SPRING Price: $6.99 |
| 501468701 |
501468701 |
SCREW Price: $6.99 |
| 501469601 |
501469502 |
This part replaces 501469601. Price: $5.10 |
| 501469701 |
530035124 |
CHECK VALVE SCREEN This part replaces 501469701. Price: $1.99 |
| 501666101 |
501666101 |
FUEL INLET SCREEN Price: $12.99 |
| 501666201 |
501666201 |
COVER, PUMP SIDE Price: $5.99 |
| 501666901 |
501666901 |
GASKET, PUMP SIDE Price: $14.99 |
| 501667001 |
501667001 |
GASKET, METERING SIDE Price: $6.99 |
| 501667201 |
502254701 |
PUMP DIAPHRAGM This part replaces 501667201. Price: $19.99 |
| 501667301 |
501667301 |
METERING DIAPHRAGM Price: $64.99 |
| 501667601 |
501667601 |
Screw Price: $1.18 |
| 501667701 |
501667701 |
SPRING Price: $7.99 |
| 501667801 |
530035121 |
IDLE SCREW SPRING This part replaces 501667801. Price: $2.99 |
| 501668301 |
501668301 |
LEVER Price: $14.99 |
| 501668401 |
501668401 |
REPAIR KIT DIAPHRAGM SET Price: $17.99 |
| 501799601 |
501799601 |
START LEVER SET Price: $2.14 |
| 501832901 |
501832901 |
BUSHING Price: $2.99 |
| 501875701 |
501875701 |
Throttle Shaft Price: $7.95 |
| 501875801 |
501875801 |
Throttle Flap Price: $2.42 |
| 501876201 |
501876201 |
Throttle Return Spring Price: $3.41 |
| 501876401 |
501876401 |
NEEDLE IDLE Price: $2.41 |
| 501878901 |
501878901 |
Choke Shaft Price: $2.51 |
| 503081801 |
503081801 |
Washer Price: $7.50 |
| 503082001 |
503082001 |
NIPPLE Price: $4.99 |
| 503108701 |
503584601 |
SCREW This part replaces 503108701. Price: $2.99 |
| 503176301 |
503176301 |
COVER METERING DIAPHR. Price: $4.99 |
| 503177101 |
503177101 |
Needle High Speed Price: $2.12 |
| 503281011 |
503281611 |
CARB. HDA-144-1 WALBRO This part replaces 503281011. Price: $99.99 |
| 503562401 |
503562401 |
SPRING Price: $6.99 |
| 503563401 |
503563401 |
INLET NEEDLE Price: $14.99 |
| 504100010 |
530035225 |
CUP PLUG This part replaces 504100010. Price: $2.99 |
| 505316717 |
505316717 |
SCREW Price: $6.99 |
| 505520125 |
505520125 |
FULCRUM PIN Price: $6.99 |
| 5014686013 |
5014686013 |
Price: Call Us |
