| Ref | Part Number | Description |
|---|
| 1 |
98-7430 |
O-RING Price: $1.95 |
| 2 |
107-9075 |
PLUG-FILLER, OIL This part replaces 98-9449. Price: $7.25 |
| 3 |
98-9455 |
NUT-CAP Price: $4.77 |
| 4 |
98-9454 |
GASKET Price: $1.43 |
| 5 |
98-9492 |
JOINT-PIPE, BREATHER Price: $9.68 |
| 6 |
98-9491 |
PIPE-BREATHER Price: $12.92 |
| 7 |
98-9364 |
SCREW (WITH WASHER) Price: $0.32 |
| 8 |
98-9490 |
SHIELD-OIL, BREATHER Price: $1.28 |
| 9 |
98-9488 |
PLATE-ELEMENT, BREATHER Price: $1.33 |
| 10 |
98-9493 |
ELEMENT-BREATHER Price: $6.10 |
| 11 |
98-9489 |
PLATE-ELEMENT, BREATHER Price: $7.89 |
| 12 |
98-9615 |
GASKET-COVER, HEAD Price: $20.34 |
| 13 |
98-9614 |
CYLINDER HEAD COVER ASM Price: $256.63 |
| 501517201 |
501517201 |
CHAIN GUIDE Price: $4.99 |
| 501527801 |
501527801 |
BUSHING Price: $3.99 |
| 501527902 |
501527902 |
CHOKE CONTROL Price: $7.99 |
| 501528101 |
501528101 |
FELLING DOG Price: $11.99 |
| 501537101 |
501537101 |
CHAIN TENSIONER Price: $14.99 |
| 501626602 |
501626602 |
TANK CAP Price: $11.99 |
| 501626801 |
501626801 |
OILCAP GASKET Price: $3.99 |
| 501779901 |
501779901 |
CRANKCASE CPL Price: $229.99 |
| 501814801 |
501814801 |
PROTECTION PLATE Price: $4.99 |
| 501815701 |
501815701 |
BOLT Price: $4.99 |
| 503212806 |
503212806 |
SCREW Price: $3.99 |
| 503230042 |
503230042 |
WASHER Price: $3.99 |
| 503260204 |
503260204 |
SEALING RING Price: $11.99 |
| 503444401 |
503723101 |
BUSHING This part replaces 503444401. Price: $4.99 |
| 503445001 |
503445001 |
BELLOWS Price: $5.99 |
| 503445701 |
503445701 |
BUMPER Price: $12.14 |
| 503590801 |
503590801 |
FELLING DOG Price: $14.99 |
| 503668403 |
503668403 |
OIL TANK VENT Price: $8.99 |
| 503697601 |
503697601 |
GROMMET Price: $4.99 |
| 503717901 |
503717901 |
SWITCH ON/OFF Price: $12.99 |
| 503723101 |
503723101 |
BUSHING Price: $4.99 |
| 720130710 |
720130752 |
Pins This part replaces 720130710. Price: $4.99 |
| 725532755 |
725532755 |
SCREW MC6S 5X12 Price: $2.99 |
| 725533155 |
525824902 |
SCREW ITXSCM This part replaces 725533155. Price: $2.99 |
| 725533755 |
725533755 |
SCREW MC6S 5X35 Price: $3.99 |
| 725534155 |
725534155 |
SCREW MC6S 5X50 Price: $4.99 |
