Clutch/Drum & Oiler Pump
Parts (32)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 76-5070 | OIL PUMP ASM Price: $729.22 |
| 2 | 94-3176 | VALVE-RELIEF Price: $5.60 |
| 3 | 76-5090 | SPRING-PISTON Price: $4.54 |
| 4 | 94-3179 | WASHER-SPRING Price: $1.50 |
| 5 | 76-5100 | BOLT-SHOULDER Price: $5.63 |
| 6 | 76-5010 | WASHER-SPRING Price: $0.33 |
| 7 | 94-3124 | SCREW-HH Price: $1.30 |
| 9 | 94-3178 | STRAINER Price: $99.33 |
| 10 | 77-3470 | SCREW Price: $3.37 |
| 11 | 77-3490 | SCREW Price: $4.42 |
| 12 | 94-3177 | PLUG Price: $7.38 |
| 501284101 | 501284101 | CONTROL SCREW Price: $2.19 |
| 501288501 | 501288501 | X-RING Price: $4.99 |
| 501293801 | 501293801 | Screw Price: $3.63 |
| 501293902 | 501293902 | Bushing Price: $16.52 |
| 501519901 | 501519901 | OIL HOSE Price: $8.99 |
| 501544102 | 501544102 | OIL SCREEN Price: $14.99 |
| 501544801 | 501544801 | SPRING Price: $3.99 |
| 503145101 | 503145101 | CLUTCH SPRING Price: $7.99 |
| 503202620 | 503202620 | SCREW Price: $2.99 |
| 503230019 | 503230019 | WASHER 6.6X11 Price: $2.99 |
| 503230058 | 503230058 | WASHER Price: $3.99 |
| 503231002 | 503231002 | WASHER 6.6X11 Price: $2.99 |
| 503253001 | 503253001 | SUPPORT BUSHING Price: $11.99 |
| 503260205 | 503260205 | SEALING RING Price: $11.99 |
| 503557501 | 503557501 | WORM GEAR Price: $8.99 |
| 503625903 | 503625903 | CLUTCH DRUM Price: $44.99 |
| 503698101 | 503698101 | OIL PUMP Price: $119.99 |
| 503698201 | 503698201 | PUMP PISTON Price: $19.99 |
| 503701502 | 503701502 | CLUTCH Price: $74.99 |
| 721420325 | 721420325 | SPRING PIN 3X6 Price: $2.99 |
| 740420100 | 740420100 | O-RING Price: $3.99 |
