| Ref | Part Number | Description |
|---|
| 1 |
312699 |
Support Bracket 46" Price: Call Us |
| 1 |
82-5510 |
DECAL-WARNING Price: $7.09 |
| 2 |
126211 |
Bolt, 5/16-18 x 5/8 In. Carr. Price: Call Us |
| 2 |
56-4780-03 |
IMPELLER ASM This part replaces 56-4780. Price: $926.99 |
| 3 |
180075 |
Screw, 5/16-18 x .63 In. Price: Call Us |
| 3 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 4 |
1498 |
Nut, 5/16-18 Centerlock Price: Call Us |
| 4 |
77-5820-03 |
MOUNTING PLATE ASM This part replaces 77-5820. Price: $255.76 |
| 5 |
313229 |
Mower Deck 46" Sus.SD Price: Call Us |
| 5 |
80-2820-03 |
BRACKET-PIVOT, REAR This part replaces 80-2820. Price: $51.76 |
| 6 |
312270 |
Quill Assy. Price: Call Us |
| 6 |
77-5440-03 |
DISCONTINUED This part replaces 77-5440. Price: Call Us |
| 7 |
1282 |
Nut, 7/16-20 Wide Fl. Lock Price: Call Us |
| 7 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 8 |
49562 |
Bearing, Ball Price: Call Us |
| 8 |
62-6520 |
KNOB Price: $7.79 |
| 9 |
3257-40 |
KEY Price: $7.99 |
| 9 |
50616 |
Dust Shield Price: Call Us |
| 10 |
53-4530-03 |
GEAR BOX ASM This part replaces 53-4530. Price: $1,650.99 |
| 10 |
56280 |
Spacer Price: Call Us |
| 11 |
312283 |
Quill Pulley Price: Call Us |
| 11 |
77-5630-03 |
GEARBOX PULLEY COVER This part replaces 77-5630. Price: $26.25 |
| 12 |
3255-17 |
WASHER-LOCK, EXT Price: $0.29 |
| 12 |
58128 |
Spacer, LH & RH Quill Price: Call Us |
| 13 |
3290-134 |
SCREW Price: $0.27 |
| 13 |
58162 |
Casting LH Price: Call Us |
| 14 |
302295 |
Saddle & Shaft Assy. Price: Call Us |
| 14 |
323-7 |
SCREW-HH Price: $0.65 |
| 15 |
50634 |
Screw, 5/16-18 x .87 Taptite Price: Call Us |
| 15 |
80-2810-03 |
BRACKET-PIVOT, FRONT This part replaces 80-2810. Price: $56.56 |
| 16 |
312708 |
Bracket Gauge Wheel L.H. Price: Call Us |
| 16 |
3218-3 |
NUT-JAM Price: $0.25 |
| 17 |
180075 |
Screw, 5/16-18 x .63 In. Price: Call Us |
| 17 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 18 |
1498 |
Nut, 5/16-18 Centerlock Price: Call Us |
| 18 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 19 |
312700 |
Bracket Gauge Wheel R.H. Price: Call Us |
| 19 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 20 |
180075 |
Screw, 5/16-18 x .631 n. Price: Call Us |
| 20 |
63-9710 |
SPACER-BEARING Price: $10.24 |
| 21 |
1498 |
Nut, 5/16-18 Centerlock Price: Call Us |
| 21 |
321-3 |
SCREW-HH Price: $0.28 |
| 22 |
13-0269 |
BLOWER HOUSING ASM Price: $579.99 |
| 22 |
312710 |
Baffle 46" Deck Price: Call Us |
| 23 |
180075 |
Screw, 5/16-18 x.63 In. Price: Call Us |
| 23 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 24 |
126211 |
Carriage Bolt, 5/16-18 x 5/8 In. Price: Call Us |
| 24 |
37-6730 |
CUP-BEARING Price: $15.84 |
| 25 |
1498 |
Nut, 5/16-18 Centerlock Price: Call Us |
| 25 |
38-7820 |
BEARING-BALL Price: $13.99 |
| 26 |
312706 |
Baffle RH 46" Deck Price: Call Us |
| 26 |
63-9700-03 |
PLATE-COVER This part replaces 63-9700. Price: $18.43 |
| 27 |
180075 |
Screw, 5/16-18 x 5/8 In. Price: Call Us |
| 27 |
43-0940 |
SPACER Price: $1.25 |
| 28 |
126211 |
Carriage Bolt, 5/16-18 x 5/8 In. Price: Call Us |
| 28 |
3235-22 |
SCREW-HH, LOCK Price: $2.59 |
| 29 |
1498 |
Nut, 5/16-18 Centerlock Price: Call Us |
| 29 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 30 |
312702 |
Bracket Chute Mount Price: Call Us |
| 30 |
43-0960-03 |
BRACKET-CHUTE This part replaces 43-0960. Price: $18.26 |
| 31 |
180075 |
Screw, 5/16-18 x 5/8 In. Price: Call Us |
| 32 |
1498 |
Nut, 5/16-18 Centerlock Price: Call Us |
| 32 |
3290-409 |
RIVET Price: $0.34 |
| 33 |
107-2926 |
DECAL-PLATE, WARNING This part replaces 80-4670. Price: $23.04 |
| 33 |
302868 |
Brace, Skid Price: Call Us |
| 34 |
126211 |
Carriage Bolt, 5/16-18 x 5/8 In. Price: Call Us |
| 34 |
3290-271 |
RIVET-POP Price: $0.25 |
| 35 |
1498 |
Nut, 5/16-18 Centerlock Price: Call Us |
| 35 |
80-3720 |
CHUTE ASM Price: $470.17 |
| 36 |
312705 |
Lift Support Bracket Price: Call Us |
| 37 |
1498 |
Nut, 5/16-18 Centerlock Price: Call Us |
| 38 |
180075 |
Screw, 5/16-18 x 5/8 In. Price: Call Us |
| 39 |
314020 |
Support Bracket Price: Call Us |
| 40 |
120393 |
Flatwasher Price: Call Us |
| 41 |
1498 |
Nut, 5/16-18 Centerlock Price: Call Us |
| 42 |
180075 |
Screw, 5/16-18 x 5/8 In. Price: Call Us |
| 43 |
317071 |
Blade, 16/13 High-Lift Price: Call Us |
| 44 |
2483 |
Washer, Bellville Price: Call Us |
| 45 |
39573 |
Screw, 3/8-24 x 1.00 Nylock Price: Call Us |
| 46 |
1498 |
Nut, 5/16-18 Centerlock Price: Call Us |
| 47 |
312701 |
Clip Price: Call Us |
