| Ref | Part Number | Description |
|---|
| 1 |
237-21 |
O-RING Price: $0.70 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 2 |
322-3 |
SCREW-HH Price: $0.79 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 4 |
538691101 |
SPINDLE.WLDMT.LH.16IN.TEX.X431 This part replaces 532403089. Price: $19.99 |
| 4 |
82-9330 |
BRACKET - SENSOR *R Price: $24.29 |
| 5 |
23-1840 |
BUSHING-TAPERLOCK Price: $92.22 |
| 5 |
538691001 |
SPINDLE.WLDMT.RH.16IN.TEX.X431 This part replaces 532403090. Price: $19.99 |
| 6 |
237-22 |
O-RING Price: $2.43 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
237-42 |
O-RING Price: $2.78 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
58-0070 |
DISC BRAKE ASM Price: $316.73 |
| 11 |
237-118 |
O-RING Price: $1.73 |
| 12 |
58-5430 |
PISTON MOTOR ASM Price: $3,072.75 |
| 13 |
237-81 |
O-RING Price: $2.76 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
92-6058 |
FITTING-STR Price: $105.61 |
| 15 |
237-58 |
O-RING Price: $2.18 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
323-18 |
SCREW-HH Price: $0.82 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 18 |
353-949 |
O-RING Price: $3.49 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
60-6990 |
WASHER Price: $4.62 |
| 20 |
327-3 |
SCREW-HH Price: $1.49 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 21 |
62-6400-03 |
HUB-WHEEL, DRIVE This part replaces 62-6400. Price: $3,397.53 |
| 22 |
3247-10 |
SETSCREW Price: $0.55 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 23 |
3219-5 |
NUT-HEX Price: $1.22 |
| 24 |
58-5610 |
RIM Price: $360.43 |
| 25 |
58-5620 |
TUBE Price: $89.16 |
| 26 |
136-3327 |
TIRE This part replaces 63-4480. Price: $404.86 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 27 |
323-20 |
SCREW-HH Price: $1.28 |
| 28 |
58-3780 |
TUBE-SPACE Price: $25.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
29-1060 |
BRACKET-SECONDARY Price: $135.49 |
| 32 |
58-0110-03 |
BRACKET-CALIPER, BRAKE This part replaces 58-0110. Price: $142.37 |
| 33 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 34 |
29-1070 |
LEVER ASM Price: $64.17 |
| 35 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
60-1740 |
NUT Price: $1.53 |
| 37 |
58-2300 |
LINK-BRAKE Price: $30.30 |
| 38 |
283-67 |
PIN-CLEVIS Price: $2.04 |
| 39 |
29-1080 |
BRAKE PAD Price: $66.87 |
| 40 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 41 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 42 |
82-9280 |
DISC WA Price: $599.98 |
| 43 |
340-90 |
DISCONTINUED Price: Call Us |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
