| Ref | Part Number | Description |
|---|
| 1 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 1 |
7733J |
SUB= 71673 Price: Call Us |
| 2 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 3 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 4 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 4 |
8883R |
PEDAL COVER T Price: Call Us |
| 5 |
132205 |
BRK ASM CLUT LH Price: Call Us |
| 5 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 6 |
76020312 |
SUB= 3145 Price: Call Us |
| 7 |
19131016 |
WASHER Price: Call Us |
| 8 |
17490508 |
SCREW LT Price: Call Us |
| 9 |
76020412 |
COTTER PIN Price: Call Us |
| 10 |
19131316 |
WASHER Price: Call Us |
| 11 |
106-6895-03 |
BALL JOINT ASM Price: $258.08 |
| 12 |
139934 |
PEDAL ASM CLU/BRK Price: Call Us |
| 12 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 14 |
121987X |
BRACKET, LIFT, SHAFT Price: Call Us |
| 14 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 15 |
133332 |
PVT BRAKE ARM ASM Price: Call Us |
| 15 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 16 |
19251816 |
WASHER T Price: Call Us |
| 16 |
82-9210 |
SHAFT-PIVOT Price: $187.73 |
| 17 |
12000034 |
KLIP RING Price: Call Us |
| 18 |
106888X |
SPRING ROD LT Price: Call Us |
| 19 |
60-3670 |
PIN Price: $12.56 |
| 19 |
73350600 |
NUT Price: Call Us |
| 20 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 20 |
73800600 |
NUT Price: Call Us |
| 21 |
131460 |
SUB= 532131460 Price: Call Us |
| 21 |
58-6520 |
DECAL-GREASE Price: $2.57 |
| 23 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 24 |
48-6660 |
WASHER Price: $5.22 |
| 25 |
48-6640 |
BEARING Price: $10.04 |
| 27 |
136780 |
LINK LIFT REAR LR Price: Call Us |
| 28 |
140777 |
LIFT.ASM.REAR.LR Price: Call Us |
| 28 |
32136-13 |
NUT-SHH Price: $2.85 |
| 29 |
72110506 |
SUB= 72270506 Price: Call Us |
| 30 |
69-9870 |
WIDE WHEEL AND 6-PLY TIRE ASM Price: $513.71 |
| 30 |
73510500 |
NUT Price: Call Us |
| 31 |
133095 |
COUNTER SPRING Price: Call Us |
| 32 |
110-9719-03 |
TIE ROD ASM This part replaces 82-9260-03. Price: $380.21 |
| 32 |
133721 |
LINK LIFT LEVER Price: Call Us |
| 35 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 36 |
340-88 |
FITTING-STRAIGHT Price: $11.24 |
| 37 |
340-54 |
ELBOW-45 DEG Price: $40.72 |
| 44 |
104-5202 |
HOSE ASM Price: $114.43 |
| 45 |
104-5233 |
MOTOR-WHEEL Price: $2,275.70 |
| 47 |
115-8015 |
CYLINDER-HYDRAULIC This part replaces 92-6057. Price: $905.66 |
| 48 |
92-4755-03 |
REAR AXLE ASM Price: $1,618.24 |
| 49 |
86-6560 |
WASHER-THRUST Price: $29.68 |
| 50 |
3274-5 |
SCREW-HSH Price: $4.00 |
| 51 |
92-4779-03 |
LH MOTOR HOUSING ASM Price: $969.47 |
| 52 |
92-4787-03 |
RH MOTOR HOUSING ASM Price: $739.13 |
| 53 |
92-4749-03 |
HUB-WHEEL Price: $96.67 |
| 54 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 55 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 56 |
92-5698 |
HOSE ASM Price: $262.64 |
| 57 |
92-5688 |
HOSE ASM Price: $119.23 |
| 58 |
92-5686 |
HOSE ASM Price: $275.50 |
| 59 |
340-70 |
NUT-LOCK Price: $2.10 |
| 60 |
340-117 |
CAP Price: $10.30 |
| 61 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 62 |
323-4 |
SCREW-HH Price: $1.02 |
| 63 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 64 |
340-115 |
FITTING-TEE, SWIVEL NUT Price: $56.09 |
| 65 |
92-5665 |
HOSE ASM Price: $72.72 |
| 66 |
83-2720 |
BOLT-LUG Price: $3.69 |
| 67 |
340-14 |
FITTING-HYD, 45 DEG Price: $42.29 |
| 68 |
94-8271 |
TRACTION HOSE ASM Price: $127.83 |
| 69 |
94-8272 |
TRACTION HOSE ASM Price: $114.06 |
| 70 |
340-76 |
FITTING-BULKHEAD UNION, STRAIGHT Price: $37.98 |
| 71 |
94-8277-03 |
BRACKET-BULKHEAD Price: $41.95 |
| 72 |
94-8275 |
INNER TUBE ASM Price: $301.27 |
| 73 |
94-8276 |
OUTER TUBE ASM Price: $301.27 |
| 74 |
94-8278 |
CASE DRAIN TUBE ASM Price: $83.72 |
| 75 |
3210-7 |
SCREW-HH Price: $0.61 |
